E-Lins M100 Quick Start Manual

Cellular modem
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
M100 Cellular Modem Quick Start
E-Lins Cellular Modem QuickStart
E-Lins Technology Co.,Limited
Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China
PHONE: +86-755-83700465
WEB: www.szelins.com
E-mail: sales@szelins.com
E-Lins Technology Co.,Limited
Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China
Tel: +86-755-83700465 E-mail: sales@szelins.com www.szelins.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M100 and is the answer not in the manual?

Questions and answers

Related Manuals for E-Lins M100

Summary of Contents for E-Lins M100

  • Page 1 M100 Cellular Modem Quick Start E-Lins Cellular Modem QuickStart E-Lins Technology Co.,Limited Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China PHONE: +86-755-83700465 WEB: www.szelins.com E-mail: sales@szelins.com E-Lins Technology Co.,Limited Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China Tel: +86-755-83700465 E-mail: sales@szelins.com www.szelins.com...

  • Page 2: Table Of Contents

    VPDN ································································································································· 4 ETTING Chapter1 Prologue This document is suitable for the following products, it will show how to setup an E-Lins Cellular Modem and helps you to use it. E-Lins Technology Co.,Limited Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China...

  • Page 3: Version

    Notice E-Lins is a registered trademark of E-Lins Technology Co.,Limited. The copyright of the document belongs to E-Lins Technology Co.,Limited. Copying of this document and modifying it and the use or communication of the contents thereof, is forbidden without express. Authority and Offenders are liable to the legal sanction E-Lins Technology Co.,Limited...

  • Page 4: Getting Started

    M100 Cellular Modem Quick Start Chapter2 Getting Started Connect to products Please connect antenna and cable with our products, make sure the port COM1 or COM2? Insert SIM Card Open the back cover. insert into SIM card as below E-Lins Technology Co.,Limited Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China Tel: +86-755-83700465 E-mail: sales@szelins.com www.szelins.com...

  • Page 5: Note: Hyper Terminal

    M100 Cellular Modem Quick Start Note: Hyper Terminal Open the HyperTerminal and input ***( any) as follows Choose a right port E-Lins Technology Co.,Limited Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China Tel: +86-755-83700465 E-mail: sales@szelins.com www.szelins.com...
  • Page 6 M100 Cellular Modem Quick Start The right configuration as following When your start-up Hyper Terminal, if it is not connected successfully, you can see the red mark of follow picture without any number. Please follow the following steps to make it work.
  • Page 7 M100 Cellular Modem Quick Start Second, click “attribute” tab First, disconnect existing connection No baud rate 10. click the “configure”, and make sure again of you modify configure 11. make sure your modify configure again, click “OK” E-Lins Technology Co.,Limited Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China Tel: +86-755-83700465 E-mail: sales@szelins.com www.szelins.com...
  • Page 8 M100 Cellular Modem Quick Start 12. Then you can see it appeared baud rate on white label, then click the black label to make call If the button of the window show “9600 8-N-1”, click this button to make call for...

  • Page 9: Test At Command

    If you succeed in testing command, at now, you can begin to SMS Chapter3 Refer to the related SMS manual. Please contact E-Lins to get SMS manual or download from website. The follow SMS Info is just for CDMA modem with ZTE module. 3.1 Select message server...
  • Page 10 41 54 2B 43 4D 47 53 3D 22 31 33 36 33 32 36 30 38 38 33 3422 //second-step, send aim telephone and length of parameter by Unicode >0D 501A592979D16280001A // content of message by Unicode code is “E-Lins Technology”, end as (ctrl+z/Esc) +CMGS: 1 +CDS:2,1,"13798257916",129,"07/01/15,17 :37 :08","07/01/15,17 :37 :13",32768...
  • Page 11 M100 Cellular Modem Quick Start +CNMI : “MT”3 //when <MT> equal 1,SMS message format AT+CNMI=2,2,0,0,0 //<MT>=2 ,receive a new message, +CMT:"13798257916","07/01/15, 18:40:54", 129, 0, 2, 0," 13798257916", 2 Helloworld //when <MT>equal 2, SMS Message format AT+CNMI=2,0,0,1,0 //when fourthly value is <ds>=1 //response “ok”...

  • Page 12: Csd

    GSM system has the encryption function. It can connect with the line Modem, Getting started Connect two E-Lins M100 modem with each two computers’ cable and open up Hyper Terminal Setting E-Lins M100 Modems baud rate 115200bps Register the CSD function.

  • Page 13: Test

    When Callee receive a ring , it answer automatically. Both them will show connect 9600and enter data state .then you can used CSD. There is a simple test course, it is suitable for E-Lins GSM /GPRS products, and fit for E-Lins GSM/GPRS wireless modem connect with line modem...

  • Page 14: Dial

    M100 Cellular Modem Quick Start Chapter5 Dial-up Notice: the Dial-up function is not support the E-Lins101 GSM Modem, it Suit for the following products Products type Description M100g - 201 GPRS Modem M100g - 209 GPRS Modem M100c-305 CDMA1x Modem...
  • Page 15 M100 Cellular Modem Quick Start Tap “Don’t detect my modem; I will select it from a list “,and then click “Next” to continue When appear “install New Modem” dialog box, choose “standard Modem Type”in the left manufacturer, and choose “Standard 19200 bps Modem”in the right Models E-Lins Technology Co.,Limited...
  • Page 16 M100 Cellular Modem Quick Start Select COM port and choose the right port( it depends your computer, may be not “COM1”.), and click “next” then you will finish installation. When appear Following Frame, Click “Finish” to succeed your modem installation.

  • Page 17: Configure 19200 Modem

    M100 Cellular Modem Quick Start Configure 19200 Modem Click “Phone and Modem Options” from “Control Panel”, Click “Modems” tab; select the modem that choose the” Standard 19200 bps modem”, and then click “Properties” button. At “Modem” tab, set the “Maximum Port Speed” to “115200”.
  • Page 18 M100 Cellular Modem Quick Start Choose “Diagnostics” tab, click the “Query Modem, if Baud rate setting and so on is right, there are automatic indication that it is have pass Next, click “Advanced” tab, Here, you can add or change settings by filling in Extra initialization commands at “Advanced”...
  • Page 19 M100 Cellular Modem Quick Start network provider before configing the initialization commands. （this picture is the example to M100g-201 GPRS modem） （example to M100g-209 GPRS modem） E-Lins Technology Co.,Limited Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China Tel: +86-755-83700465 E-mail: sales@szelins.com www.szelins.com...
  • Page 20 M100 Cellular Modem Quick Start （example to M100c-309/305 CDMA modem） NOTICE: “CMNET” is China Mobile APN setting; you should change it in accordance with the information provided by your local service provider. E-Lins Technology Co.,Limited Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China...

  • Page 21: Create A Dial-Up Network

    M100 Cellular Modem Quick Start Create a Dial-up network After you succeed for set-up a Modem as following picture, click “next “and start to set-up your GPRS/CDMA Dial-up network, Open “Network Connections”. Double click “network Connection”, click “Next” to continue E-Lins Technology Co.,Limited...
  • Page 22 M100 Cellular Modem Quick Start The Network Connection Wizard opens. Click”Next”to continue. Put a check mark on Connect to the Internet and click Next. Select the option Set up my connection manually and click Next.. Select Connect using a dial-up modem and click “next” button to continue E-Lins Technology Co.,Limited...
  • Page 23 M100 Cellular Modem Quick Start Select the modem driver that you want to use for the dial-up connection. Click Next to continue. Type an appropriate Connection name and click Next E-Lins Technology Co.,Limited Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China...
  • Page 24 M100 Cellular Modem Quick Start AS showing below picture, Depending on the network, input ISP phone number in “phone number” box, if modem type is M100g-201/ M100g-209 that standard phone number is”*99***1#”, if modem type is M100c-305/M100c-309 that standard phone number is”#777”...
  • Page 25 M100 Cellular Modem Quick Start （M100c-305/M100c-309phone number） In following “Internet Account Information” Frame. You may be required to put a User name and a Password for the dial-up connection if modem type is M100g-201/ M100g-209 that user name and password both are “WAP”, if modem type is M100c-305/ M100c-309 that user name and password both are “CARD”.
  • Page 26 Click “next” button , as showing below picture ,Click “Finish” to succeed your new Connection installation Notice: E-Lins modem may be initialized for Chinese market options. If it is, it should be changed with your local operator initializations. Every newly created dial-up connection should be configured before using it to establish a PPP connection.
  • Page 27 M100 Cellular Modem Quick Start Select a right device as you just have setup modem. Example to “modem standard 19200 bps modem (com 1). then click “configure “button to continue Setting Maximum speed(Bps) is 115200 and click “ok” to finish modem configured E-Lins Technology Co.,Limited...

  • Page 28: Login On Network

    M100 Cellular Modem Quick Start Login on network （M100g-201/ M100g-209 GPRS （M100c-305/M100c-309 CDMA Modem） Modem） E-Lins Technology Co.,Limited Add:Bld22, Longxi Garden, Nonglin Road, Futian, Shenzhen, 518000, China Tel: +86-755-83700465 E-mail: sales@szelins.com www.szelins.com...
  • Page 29 M100 Cellular Modem Quick Start Dblclick new network connection, dial up directly, depend on the network ,input user name and password both, if modem type is M100g-201/ M100g-209 that user name and password both are “WAP”, if modem type is M100c-305/ M100c-309 that user name and password both are “CARD”.

  • Page 30: Setting Apn

    M100 Cellular Modem Quick Start Chapter6 Setting APN or VPDN Notice: The APN IS CHIAN Mobile Network, it is suit for M100gs and M100g-209. VPDN IS CHINA UNICOM Network, it Is suit for the M100c-305 M100c-309 Setting APN Extra initialization commands:...
  • Page 31 M100 Cellular Modem Quick Start （example to M100g-209 GPRS modem） it showing below picture, .you may be required to put a User name and a Password for the dial-up connection, setting the APN user name and password both are “wap” and save it （M100g-201/ M100g-209）...

  • Page 32: Setting Vpdn

    M100 Cellular Modem Quick Start Setting VPDN VPDN Extra initialization commands: AT&D2 // suitable for M100c-305/309 （example to M100c-309/305 CDMA modem） Double click new network connection, dial up directly, depend on the network ,input VPDN user name and password both are “card”。...
  • Page 33 M100 Cellular Modem Quick Start （example to M100c-305/ M100c-309 modem） Notes: before setting, please get the correct APN info from the sim card / network provider because different provider get different APN infos. For example of China Mobile and China Unicom:...
