Summary of Contents for Polar Bear PWD9800f
- Page 1 PB-PWD9800f Installation Manual Issued: 02/11/2009 Polar Bear Solutions reserves the right to alter specifications without notice at any time. For full warranty information, refer to the Instruction Manual(s) associated with your Product(s).
-
Page 2: Polar Bear Solutions Limited Warranty And Disclaimer
This includes any lost profits, lost savings, incidental damages, or consequential damages. POLAR BEAR SOLUTIONS is not liable for any claim made by a third party or by a POLAR BEAR SOLUTIONS Dealer for a third party. This limitation of liability applies whether damages are sought, or a claim is made, under this warranty or as a tort claim (including negligence and strict product liability), a contract claim, or any other claim. -
Page 3: Table Of Contents
Wired Ethernet ..........................7 Tech Specification: .......................... 7 Contact: Polar Bear Solutions Ltd.................... 7 Polar Bear Solutions reserves the right to alter specifications without notice at any time. For full warranty information, refer to the Instruction Manual(s) associated with your Product(s). -
Page 4: What's Included
Installation The PWD9800f caddy is fitted to the back of the TSU9800 to form a secure mounting base for the control panel to be then fitted into the wall. Take the TSU9800 and place it face down on a clean soft surface, on the back remove the four rubber bungs located on the rear of the TSU9800 control panel. - Page 5 A suitable Torx adapter bit has been included in the product for convenience. Once these screws have been removed, place the PB-PWD9800f caddy over the back of the TSU9800 and secure in place with the new screws provided. The caddy has a small amount of movement to allow for aligning the front frame.
- Page 6 Once the caddy is secured in the wall the frame can be clipped in place. The reset stylus can be used to reset the TSU9800 if required without needing to remove the controller from the wall. Polar Bear Solutions reserves the right to alter specifications without notice at any time. For full warranty information, refer to the Instruction Manual(s) associated with your Product(s).
-
Page 7: Power Supply
250 x 176.5mm (W x H) Contact: Polar Bear Solutions Ltd Web site: http://www.PolarBearSolutions.com/ Email: sales@polarbearsolutions.com Polar Bear Solutions reserves the right to alter specifications without notice at any time. For full warranty information, refer to the Instruction Manual(s) associated with your Product(s).
