INSTALLER: LEAVE THESE INSTRUCTIONS WITH THE APPLIANCE THIS TERMINAL IS SERVING.
CONSUMER: RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
THESE INSTRUCTIONS ARE TO BE USED IN CONJUNCTION WITH THE APPLIANCE AND PVA INSTRUCTIONS.
CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS: ANSI Z21.88 CSA 2.33 FOR VENTED GAS FIREPLACE HEATERS
GAS POWER VENT
(GPV)
GENERAL INFORMATION
These Installation Instructions must be used in conjunction
with the appliance and appropriate PVA adapter kit Installation
Instructions. Clearances listed in these Instructions supersede
those in the appliance's Installation Instructions.
Power venting of direct vent appliances may result in the
reduction of efficiencies by as much as ten percent. Consider
this in making any venting and heating decisions in any
installation application.
SELECTING AND INSTALLING THE FIREPLACE
When selecting a gas appliance for use with the GPV, take into
consideration the various requirements and limitations in the
venting installation section for the following models:
Models Equipped with an Intermittent Pilot Ignition (I.P.I.)
It is recommended that the GPV be used with a gas appliance
equipped with an Intermittent Pilot Ignition (I.P.I.). Downward
vertical vent runs are permitted with an I.P.I. system. See
venting section in appropriate PVA Installation Instructions.
Models Equipped with Millivolt/ Standing Pilot
Downward vertical vent runs are not permitted with a standing
pilot system. See venting section in appropriate PVA Installation
Instructions.
INSTALLATION TO BE DONE BY A QUALIFIED INSTALLER
to conform with local codes. In absence of local codes install
to the current National Building Code in Canada or to regional
building codes in the United States. It must be electrically
connected and grounded in accordance with local codes. In
the absence of local codes, use the current CSA C22.1
CANADIAN ELECTRICAL CODE in Canada or the ANSI/NFPA
70 NATIONAL ELECTRIC CODE in the United States.
The GPV operates on 120 VAC 60 HZ electrical service which is
supplied at the firebox junction box.
$10.00
INSTALLATION
INSTRUCTIONS
AND ANSI Z21.50 CSA 2.22 FOR GAS FIREPLACES.
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 4Y8 Canada /
103 Miller Drive, Crittenden, Kentucky, USA, 41030
The GPV is a Direct Vent Terminal
designed to allow installation of
gas appliances where typical vent
configurations cannot be achieved.
1
C E R T I F I E D
W415-0682 / B / 06.10.10
Advertisement
Table of Contents
Related Manuals for Napoleon GPV
Summary of Contents for Napoleon GPV
-
Page 1: General Information
SELECTING AND INSTALLING THE FIREPLACE When selecting a gas appliance for use with the GPV, take into consideration the various requirements and limitations in the venting installation section for the following models: Models Equipped with an Intermittent Pilot Ignition (I.P.I.) -
Page 2: Table Of Contents
RESTRICTOR PLATE INSTALLATION WIRING DIAGRAM AND INSTALLATION 1.6.1 SIT IPI 885 PROFLAME COMPLETE WITH GPV POWER VENT TERMINAL 1.6.2 SIT MILLIVOLT 820 NOVA COMPLETE WITH GPV POWER VENT TERMINAL 1.6.3 SIT IPI 880/886 PROFLAME COMPLETE WITH GPV POWER VENT TERMINAL 1.6.4 DEXEN IPI 6003-3V COMPLETE WITH GPV POWER VENT TERMINAL... -
Page 3: Installation Overview
INSTALLATION OVERVIEW Reducer, refer to A typical vent power vent configuration adapter kit (PVA) for specific vent- ing instructions where applicable. 0 I l l u s Firestop t r a t Spacer Electrical Box Gas Power (velcro to base) Vent Terminal Frame Assembly Terminal... -
Page 4: Vent Terminal Clearances
VENT TERMINAL CLEARANCES COVERED BALCONY APPLICATIONS ††* = 3 feet = 2 x ACTUAL feet INSTALLATIONS CANADA U.S.A. 12” 12” Clearance above grade, veranda porch, deck or balcony. 12” Δ 9” Δ Clearance to windows or doors that open. 12” * 12”... -
Page 5: Vent Lengths
Insert the wiring through the electrical access plate and engage the conduit bush- ing. Re-secure this plate. NOTE: The GPV includes a 20 foot wire 10 1/4” harness cable. If this cable does not reach the appliance, then it may be cut and a splice added. -
Page 6: Power Vent Installation
1.4.2 POWER VENT INSTALLATION Stretch the inner fl ex pipe to the required length taking into account the additional length needed for the fi n- CAULKING ished wall surface. Slip the vent pipe a minimum of 3” over the inner sleeve of the terminal and secure with 3 #8 screws. -
Page 7: Electrical Box Installation
1.4.4 ELECTRICAL BOX INSTALLATION NOTE: Before fi nishing in the appliance, the power vent must be installed. BX SNAP BUSHING POWER VENT CONTROL 20’ POWER MODULE VENT CABLE LH D5 0 Illu st ra te d SPLIT BUSHING REQUIRED Start by removing the pre-fi nishing access panel or opening lower louvre. Position the Power Vent Control Module in a convenient location (not on top of the heat shield in the LHD50) and Velcro it to the base of the appliance. -
Page 8: Restrictor Plate Installation
NOTE: The GPV includes a 20 foot wire harness. If this harness does not reach the appliance, then it may be cut and a splice added. These connections must conform with local codes or, in the absence of local codes, use the current CSA C22.1 Canadian Electrical Code in Canada or the ANSI/NFPA 70... - Page 9 POWER 120 VOLT AUX OUT RED / FCM-COM WHITE GREY / FCM-COM PURPLE / FCM-COM BLACK GREEN BROWN / MOTOR BLACK / MOTOR YELLOW / MOTOR ORANGE / MOTOR PINK BLUE BLACK YELLOW / GREEN W415-0682 / B / 06.10.10...
-
Page 10: Sit Millivolt 820 Nova Complete With Gpv Power Vent Terminal
1.6.2 SIT MILLIVOLT 820 NOVA COMPLETE WITH GPV POWER VENT TERMINAL NOTE: Must use double pole switch (supplied) or double pole thermostat (not supplied) with specifi c power vent adaptor kit. 1. Connect the jumper wire to tabs 1 and 3 on the gas valve. -
Page 11: Sit Ipi 880/886 Proflame Complete With Gpv Power Vent Terminal
1.6.3 SIT IPI 880/886 PROFLAME COMPLETE WITH GPV POWER VENT TERMINAL NOTE: Must use double pole switch (supplied) or double pole thermostat (not supplied) with specifi c power vent adaptor kit. Connect the jumper wires to the wire labeled ON/OFF (Green/White) and the wire labelled TH (Green). -
Page 12: Dexen Ipi 6003-3V Complete With Gpv Power Vent Terminal
1.6.4 DEXEN IPI 6003-3V COMPLETE WITH GPV POWER VENT TERMINAL NOTE: Must use double pole switch (supplied) or double pole thermostat (not supplied) with specifi c power vent adaptor kit. Connect the Brown wires from the Ignition module to the yellow wires from the Power vent control module. -
Page 13: Adjustments
WITH THIS APPLIANCE MAY • Finish RESULT IN PROPERTY DAMAGE OR * IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED. FOR PERSONAL INJURY. FURTHER INFORMATION, CONTACT YOUR AUTHORIZED DEALER. 41.1 COMPONENTS GPV PART NO. DESCRIPTION W062-0026 BLOWER W660-0056 SWITCH, VACUUM W750-0195 WIRE HARNESS, TERMINAL W750-0209 20’... -
Page 14: Trouble Shooting
4.0 TROUBLE SHOOTING WARNING ALWAYS LIGHT THE PILOT WHETHER FOR THE FIRST TIME OR IF THE GAS SUPPLY HAS RAN OUT, WITH THE GLASS DOOR OPEN OR REMOVED. IN SOME INSTANCES THE SYSTEM MAY NOT LIGHT PILOT/BURNER WITH THE DOOR OPEN/ REMOVED. - Page 15 5.0 NOTES 44.1 W415-0682 / B / 06.10.10...
- Page 16 44.1 W415-0682 / B / 06.10.10...
