Seanix SE1908W SERVICE MANUAL 19” LCD MONITOR SE1908W THESE DOCUMENTS ARE FOR REPAIR SERVICE INFORMATION ONLY. EVERY REASONABLE EFFORT HAS BEEN MADE TO ENSURE THE ACCURACY OF THIS MANUAL; WE CANNOT GUARANTEE THE ACCURACY OF THIS INFORMATION AFTER THE DATE OF PUBLICATION AND DISCLAIMS RE LIABILITY FOR...
Seanix SE1908W Revision List Version Date Revision History TPV Model Name Jun-28-06 Initial Release T982KM2NKBSEN Feb-07-07 Add different parts list in Item 11 T96MM2NKWCSENP...
Seanix SE1908W 2. LCD Monitor Description The LCD MONITOR will contain a main board, an inverter board, a key board and an adapter board which house the flat panel control logic, brightness control logic and DDC. The Inverter board will drive the backlight of panel and DC-DC conversion.
Seanix SE1908W 3. Operating Instructions 3.1 General Instructions Press the power button to turn the monitor on or off. The other control buttons are located at front panel of the monitor. By changing these settings, the picture can be adjusted to your personal preferences.
Seanix SE1908W 3.3 Adjusting The Picture OSD Table: Main Sub Menu Main Menu Item Menu Menu Description Item Icon Icon Contrast Contrast from Digital-register. Luminance Brightness Backlight Adjustment Focus Adjust Picture Phase to reduce Horizontal-Line noise Image Setup Clock Adjust picture Clock to reduce Vertical-Line noise.
Page 8
Seanix SE1908W H. Position Adjust the horizontal position of the OSD. OSD Setup V. Position Adjust the vertical position of the OSD. OSD Timeout Adjust the OSD timeout. Language Language Select the language you like. Show the resolution, H/V frequency and input port of...
Seanix SE1908W 4. Input/Output Specification 4.1 Input Signal Connector 1. D-SUB connector Pin No. Description Pin No. Description Red Video Green Video Detect Cable Blue Video Ground Ground DDC-Serial Data Ground H-Sync Red Ground V-Sync Green Ground DDC-Serial Clock Blue Ground 15 - Pin Color Display Signal Cable 2.
Seanix SE1908W 4.2 Power Supply Requirement A/C Line voltage range : 100 V ~ 240 V : 50 ± 3Hz, 60 ± 3Hz A/C Line frequency range Input Current : 1.5A max at 100V; 0.8A max at 240 V Peak surge current : <...
Seanix SE1908W 4.4 Panel Specification 4.4.1 General Description - Wide viewing angle. - High contrast ratio - Super fast response time - High color saturation - WXGA+ (1440 x 900 pixels) resolution - DE (Data Enable) only mode - LVDS (Low Voltage Differential Signaling) interface - RoHS Compliance 4.4.2 Display Characteristics...
Page 14
Seanix SE1908W REMARK: 1) MCU initialize. 2) Is the EEprom blank? 3) Program the EEprom by default values. 4) Get the PWM value of brightness from EEprom. 5) Is the power key pressed? 6) Clear all global flags. 7) Are the AUTO and SELECT keys pressed? 8) Enter factory mode.
Seanix SE1908W 5.3.2 Inverter/Power Board Bridge Rectifier AC input Transformer Rectifier diode EMI filte r and Filter Start Circuit: R903、R904 CN102 Feedback Over Voltage Control IC Circuit Protect ON/OFF OSC and MOSFET DC Convert Output Q203/Q204 Circuit Circuit Lamp Feedback...
Seanix SE1908W 8. Maintainability 8.1 Equipments And Tools Requirement Voltmeter. Oscilloscope. Pattern Generator. DDC Tool with an IBM Compatible Computer. Alignment Tool. LCD Color Analyzer. Service Manual. User Manual.
Seanix SE1908W 8.2 Trouble Shooting 8.2.1 Main Board No power No power Press power key and look if the picture is normal Please reinsert and make sure the AC of 100-240 is normal Reinsert or check the Adapter/Inverter section Measure U201 PIN2=1.8V U202 PIN2=3.3V...
Page 37
Seanix SE1908W No picture (LED orange) No picture The button if X601 oscillate Replace X601 under control waveform is normal Check reset circuit of Check Correspondent component U601 is normal Measure U201 PIN2=1.8V U202 PIN2=3.3V Replace U601 Replace U201, U202...
Page 38
Seanix SE1908W White screen White screen Measure Q204 base X601 oscillate waveform is normal is high level? Replace X601 Check Q204, Q203 are Check reset circuit of broken or CN503 solder? U601 is normal Check Correspondent Check Correspondent component. component.
Seanix SE1908W 8.2.2 Power/Inverter Board W / LED, No Backlight Check CN102 pin5=12V Check adapter or Main Board Check ON/OFF signal Check Main Board Check U201 pin9=12V Change Q201 or Q202 Check U201 PIN1 have the output of square wave at short time Change U201 Check D203 (-)/ D204 (-) have the output of square wave at short time.
= 313±20, y = 329 ±20, Y =180 cd/m 3. Into factory mode of Seanix SE1908W Turn on power, press the MENU button, pull out the power cord, and then plug the power cord. Then the factory OSD will be at the left top of the panel.
Page 41
Seanix SE1908W C. Adjust sRGB color-temperature 1. Switch the chroma-7120 to RGB-Mode (with press “MODE” button) 2. Switch the MEM.channel to Channel 4(with up or down arrow on chroma 7120) 3. The LCD-indicator on chroma 7120 will show x = 313 ±20, y = 329 ±20, Y = 180 cd/m 4.
Seanix SE1908W 11. Different Parts List Diversity of T96MM2NKWCSENP compared with T982KM2NKBSEN Location Part No. for TPV Description 026G 800504 6 BARCODE LABEL E089A 089G 715CAA D2 SIGNAL CABLE D-SUB COMLINK E089A 089G 715HAA D2 SIGNAL CABLE E750L 750GLM90A1211N PANEL LCD 19" A1-L02 CMO...
