XMP-120/130 SaaS Media Player
Quick Start Guide
This printed quick guide provides a quick walkthrough of the set up process.
For complete documentation, please visit www.digisignage.com
Box Contents
Main Unit
AC Power Adapter
Quick Start Guide
(this guide)
USB Keyboard required
Mounting and Installation
The player can be attached to mounting
posts on the back of screens or inside
cabinetry with the built in 140mm x
75~100mm (variable) mounting flange
(For XMP-130 only) ATTACH the wireless
antenna as shown in physical views. Screw
the antenna clockwise onto the antenna post
12V DC output
A USB keyboard is required to change system settings.
3.5 mm to
RCA AV Cable
Ethernet Cable
(XMP-130 only)
Wi-Fi Antenna
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for digisignage SaaS XMP-120
- Page 1 XMP-120/130 SaaS Media Player Quick Start Guide This printed quick guide provides a quick walkthrough of the set up process. For complete documentation, please visit www.digisignage.com Box Contents 3.5 mm to Wi-Fi Antenna Main Unit AC Power Adapter Ethernet Cable...
- Page 2 Physical views System setup (for Composite video only; Skip to step 2 for HDMI or VGA) SET the output switches to NTSC or PAL CONNECT the player to your display with an HDMI, VGA, or supplied 3.5mm composite AV cable, and switch your display on to the corresponding input mode.
- Page 3 Settings are now retained even if you remove the power → For advanced player configuration, such as static IP, proxy server, time server, display option, and security settings, visit http://www.digisignage.com for more information. Content Management Please consult the software documentation for information specific to your...
- Page 4 Troubleshooting Why is there no video output? Please verify your DIP switch configuration and see if you are using the correct output mode. When using HDMI/VGA with an LCD TV/monitor, typically 16:9 ratio works best; when using a CRT TV set, 4:3 works best. What video outputs are active simultaneously? VGA &...
