- Page 1 OWNER’S MANUAL !!PLEASE NOTE!! THIS MANUAL MUST BE GIVEN TO THE HOMEOWNER TO ENSURE WARRANTY COVERAGE Aqua Comfort Technologies, LLC - "Aqua Comfort" P.O. Box 1520, Sykesville, MD 21784-1520 Tel: (410) 549-6083 / Fax: (410) 549-6082 www.comfortchlor.com Models: CC-350 and CC-550...
-
Page 2: Table Of Contents
Safety First... General ... Cell... Flow Sensor... Control Box ... Wiring... **Before Adding Salt/Minerals ... Adding Salt ... How Much Salt to Add ... **Note: There are many types of acceptable Salts, some which contain other minerals and additives to improve their quality and performance. -
Page 3: Welcome
Congratulations on the purchase of your new Comfort-Chlor Chlorine Generator. Your purchase will minimize the efforts needed to maintain your pool and maximize your enjoyment for many years. Before installation or operation, please read these instructions carefully. This manual contains easy to follow step-by-step procedures to properly install and operate your system. -
Page 4: Cell
I N S T A L L A T I O N I N S T R U C T I O N S The system comes in three sections, the Control Box, Cell and Flow Sensor. They are manufactured from the latest corrosion resistant materials to give you years of trouble free use, and installing them in the most sheltered position from sun and water will protect them from extreme weather conditions for years to come. -
Page 5: Flow Direction
CONFIRM LAYOUT: Lay out equipment pieces to be sure there is enough pipe space between the last piece of apparatus and the tees in the return line to fit the Flow Sensor and the Cell. A Vertical installation may be used to save space (see diagrams above). 1. -
Page 6: Power Cord
M o u n t t h e C o n t r o l B o x 1. The Control Box must be mounted vertically on a flat surface and a minimum of 5 ft (1.5m) horizontal distance (or more, if local codes require) from the pool/spa. -
Page 7: Wiring
W i r i n g t h e C o n t r o l B o x t o S t a n d a r d T i m e r CAUTION: Check whether your chlorine generator operates on 120 volts or 240 volts (see label on the left side of the Control Box), and be sure to wire the system accordingly. - Page 8 240Volt Circulation Pump With 240 Volt Chlorine Generator 120Volt Circulation Pump With 120 Volt Chlorine Generator...
- Page 9 220Volt Circulation Pump With 220 Volt Chlorine Generator 120Volt Circulation Pump With 240 Volt Chlorine Generator A 240 Volt Chlorine Generator may NOT be connected to a system with a 120 Volt circulation pump. Connect the two black wires from the Control Box to the two metal studs on the sides of the Cell and tighten firmly with a screwdriver by hand.
-
Page 10: Startup
BEFORE ADDING THE SALT Balance the chemicals. See the titled “Understanding the Chemistry” for recommended water balance. Also, add 1 quart of metal remover and 1 quart of non-copper based algaecide to the pool, according to the manufacturer’s instructions. This will ensure that the transition to the Comfort-Chlor system will be quick and trouble-free. -
Page 11: Calculating The Size Of The Pool
S A L I N I T Y D E M A N D T A B L E 1051 1109 1168 1226 1284 1343 1401 1460 Locate the current salt concentration at the top of the chart (e.g. 1000ppm). Then locate the size of your pool on the left (e.g. -
Page 12: Basic Operation
O P E R A T I N G I N S T R U C T I O N S Comfort-Chlor is a chlorine generator for pool and/or spa sanitation. It is the workhorse of chlorine generators. The system uses a very low concentration of salt, less than the concentration in a human teardrop, and converts it into free chlorine that kills algae and bacteria in your pool. -
Page 13: Controls
Control Knob (1) – The Control Knob is used to adjust chlorine production and to turn the unit on or off. To increase chlorine production, turn the Control Knob up (clockwise). To decrease chlorine production, turn the Control Knob down (counterclockwise). To turn the unit off, turn the Control Knob down (counterclockwise) until it clicks. - Page 14 Salinity Indicator – To check the salt level, turn the Control Knob clockwise to full power and check the light reading. 100% reading indicates that the salt level is sufficient. Return the Control Knob to the desired chlorine production setting depending on the chlorine level in your pool (10% to 100% production rate).
-
Page 15: Cleaning With Optional Cleaning Cap
Maintaining your Natural Generator requires minimal work but will maximize the performance and life of the system. POOL WATER TESTING: Pool water should be tested weekly. Cell Maintenance Our clear Cell allows for easy regular inspections for calcium build up. Visually check the Cell periodically, and clean it as necessary (1 to 2 times per year). -
Page 16: Cleaning Without Optional Cleaning Cap
Cleaning Without Optional Cleaning Cap: 1. Remove the cell from the line by undoing the electrical connections from the Cell and the barrel unions from the cell ends. 2. Remove the black o-rings on the ends of the Cell. 3. Soak entire cell either in undiluted white distilled vinegar or in a solution of diluted muriatic acid (10 parts water to 1 part muriatic acid). -
Page 17: Understanding The Chemistry
U N D E R S T A N D I N G T H E C H E M I S T R Y Below is a table showing the recommended balance levels followed by a more detailed explanation of the factors affecting water chemistry. - Page 18 lower total alkalinity and add baking soda (sodium bicarbonate) to raise total alkalinity. Be sure to read and follow the respective manufacturer’s instructions. Stabilizer (cyanuric acid) is necessary in most outdoor pools to maintain appropriate levels of chlorine. Chlorine stabilizer helps give an appropriate residual chlorine reading of the pool water. Without stabilizer, UV radiation from the sun destroys most chlorine within 2 hours, but excessive amounts of stabilizer can decrease the effectiveness of chlorine.
-
Page 19: Saturation Index
Test the water for pH, Alkalinity, Calcium Hardness, and Temperature, then follow the simple steps below: 1. Write your pool’s pH level here: 2. Find your Alkalinity level in the chart below, and write the corresponding Alkalinity Factor here: Pool Alkalinity Factor 3. -
Page 20: Troubleshooting
Note: evaluating the possible causes for each problem from top to bottom (first to last) will avoid extra labor. PROBLEM POSSIBLE CAUSES System is turned off. Control Knob is set too low in relation to chlorination demand (e.g. higher number of bathers, warmer weather, increased debris in pool). - Page 21 Note: evaluating the possible causes for each problem from top to bottom (first to last) will avoid extra labor. PROBLEM POSSIBLE CAUSES Dirty Cell Loose connection with the Cell’s connection pegs. 9. Salinity Low Not enough salt due to heavy rain, initial miscalculation, etc.
-
Page 22: Date Of Installation
13. Power Meter not responding, system automatically shuts down but On/Off light is the Power Meter when the salt level is extremely low or extremely high. needs to be cleaned approximately 14. Scale twice/year. build-up inside Cell 15. White flakes in the water cleans itself. -
Page 23: Ten (10) Year Limited Warranty
Models: CC-350 and CC-550 WARRANTY This warranty applies to all CC-350 and CC-550 chlorine generators and their factory-supplied components (the “System”) when purchased from an authorized dealer and used for residential swimming pools or spas. Aqua Comfort Technologies, LLC (“Aqua Comfort”) warrants the System to be free from defects in materials and workmanship in the manufacturing process for a period of ten... -
Page 24: Return Address
RETURN ADDRESS ______________________________ ______________________________ ______________________________ AQUA COMFORT TECHNOLOGIES, LLC ATTN: WARRANTY DEPT. (AC) P.O. BOX 1520 SYKESVILLE, MD 21784-1520...
