Tritton AX51 Quick Start Manual

AX51 Quick Start Guide
PACKAGE CONTENTS
Thank you for choosing the
Please verify your package contains
the following:
A - AX51 5.1 Headset with In-Line Audio
Control Box
B - Removable Microphone
C - AC Power Supply
D - Soft Carrying Case
Images not to scale.
B
C
AUDIO BOX CONTROLS
AX51
4 3
8
8
5 6
1
Master Volume Up & Down
2
Master Volume Mute
3
Front Channel Volume Control
4 Surround (Rear) Channel
Volume Control
5
Subwoofer Channel Volume Control
6
Center Channel Volume Control
7
Microphone Mute
8
Status Indicator Light
a. Blue during normal use
b. Purple when Microphone is muted
DEVICE INSTALLATION AND CONFIGURATION
51
AX
.
Warning!
The AX51 is capable of playing sound at a
high volume level. Do not use headphones
for prolonged amounts of time at a loud
volume. Always use caution when using
any headsets.
Before putting the
all volume levels at 0 then work your way
up to an acceptable volume level. Failure
to do this may lead to permanent hearing
damage.
A Getting Started
1. Unpack AX51.
2. Turn all volume knobs to zero (3) (4) (5) (6).
3. In order to avoid damage to your headset,
and/or your computer, read your sound card
manual. Determine which 3.5mm headphone
style jacks correspond to Front, Center,
Rear, and Mic on your soundcard. Although
we color-code our audio plugs, there are
many different color standards used by the
industry for 5.1 audio jacks
4. Plug in the
D
Color
Green
Black
Orange
Pink
1
2
Black
5. Adjust sound card settings
to output 5.1 audio
NOTE: These settings vary based upon the
7
sound card you are using, and the operating
system you are running. For PC, usually the
sound configuration is located under control
panel\sound. Please refer to your soundcard
manual for this configuration.
6. With headset on head, adjust volume to a
comfortable listening level
7. If you wish to use the microphone, un-mute
it by pressing the mute/un-mute button (7).
By default, the microphone mute may be
selected during startup
AX51
on your head, start
AX51
cables.
Description
Front Channel
Rear Channel
Center/Subwoofer
Microphone
AC Power
Connecting to PC sound card.
Connecting to TRITTON AX360.
Connecting to music player.
Ipod and Ipod symbols are copyright © 2007 Apple Inc. All rights reserved.
