Page 1: Service Manual
Service Manual LCD TV For 237-T11 FM Number.： ： ： ： FM1 FM1- - - - 037000EGS25 037000EGS25 037000EGS25 037000EGS25 Model Number: 237T Model Name:237-T11 FM Number.： ： ： ： FM1 FM1- - - - 037000EGS36 037000EGS36 037000EGS36 037000EGS36 Model Number: 237T Model Name:237-T11 FM Number.：... - Page 2 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 2/72 Hans Chung Jill kao 2007/11/19 2007/11/19 Company Confidential-DRAFT...
- Page 3 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 3/72 Document change / update record Update date Version Page Update record Updated Parts list(LPL WX1-SL01 /LPLWX1-SLA1) 2007/07/03 V1.1 Updated Parts list(LPL WX4-SLA1) 2007/11/19 V1.2 Company Confidential-DRAFT...
-
Page 4: Table Of Contents
Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 4/72 Table of Contents 1. Introduction……………………………………………………………….………………………………..4 1-1 P e face……………………………….……………….……………………….…………………………..4 1-2 Caution…………………………………………………..……………………………..………………….4 1-3 Warning………………………………………………………..…………………………….……………4 1-4 Important………………………………………………………..…………………………………………4 2. Specifications…………………………………..……………….……………………………………………5 3. Diagram………….…………….………………………………………………………………….………….6 3-1 Wiring Diagram……………………..……………………………………………….……………………6 3-2 System Block Diagram V ideo ………………………………………………………..…………………7 （... - Page 5 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 5/72 Company Confidential-DRAFT...
-
Page 6: Introduction
Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 6/72 1. Introduction 1-1 Preface This service manual describes module-level LCD TV repair for qualified service personnel. This service manual also includes selected production troubleshooting information for electronic technicians and engineers. -
Page 7: Specifications
Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 7/72 2. Specifications PRODUCT SPECIFICATIONS LCD Panel 37" TFT 37" TFT(LPL-WX4) ＜ ＜ ＜ ＜ 1W ＜ ＜ ＜ ＜ 1W Power Management (Standby Mode) Displayable Resolution VGA 1360*768 max. VGA 1366*768 max. - Page 8 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 8/72 Company Confidential-DRAFT...
-
Page 9: Diagram
Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 9/72 3. Diagram 3-1 Wiring Diagram Company Confidential-DRAFT... - Page 10 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 10/72 3-2 System Block Diagram (Video) Company Confidential-DRAFT...
-
Page 11: System Block Diagram A Udio
Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 11/72 3-3 System Block Diagram (Audio) Company Confidential-DRAFT... -
Page 12: Trouble Shooting Flow Chart
Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 12/72 4. Trouble shooting flow chart 4-1 Display Problems Note: Refer to the Wiring Diagram during troubleshooting for a visual of inter-connections when indicated by this symbol. Trouble Condition Check Item Replace Material Test... -
Page 13: Abnormal Power On/Off
Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 13/72 4-2 Abnormal Power On/Off Replace Material Trouble Condition Check Item Test Abnormal Power On/Off Step1: Fail Check Power Supply, Con. Replace Power No Power J101–pin 1 to ground = 5V supply Con CN1 pin 3 to ground = Note: Before... -
Page 14: Problem
Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 14/72 4-3 LED is Malfunctioning、 、 、 、 Keypad Problem Trouble Condition Replace Material Check Item Test Step1 ： Check CN 10 on system Fail Secure connection board to CN 1 on LED is not working or replace cable Keypad board for a... - Page 15 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 15/72 Company Confidential-DRAFT...
-
Page 16: Image Abnormal Display
Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 16/72 4-4 Image Abnormal Display Replace Material Trouble Condition Check Item Test 1. Reconnect cable Step1 ： No picture through Fail 2. Replace cable component 1. Check video cable 3. -
Page 17: Audio Abnormal Output
Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 17/72 4-5 Audio Abnormal Output Replace Material Trouble Condition Check Item Test Fail Check switches on the Can’t adjustment Replace Keypad Audio Problems keypad board Volume board Step1 ：... -
Page 18: The Other Abnormal Display
Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 18/72 4-6 The Other Abnormal Display Replace Material Trouble Condition Check Item Test Step1 ： Fail Sometimes picture Check Con. J11 to Replace LVDS flashes panel LVDS connect wire onnection Other display problems Step2... -
Page 19: Disassembly
Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 19/72 5. Disassembly 5-1 Stand Screw T4*45-PH-Cross-Black Screw T4*25-PH-Cross-Black 1. Loosen and remove 8 screws. 2. Safely remove the Stand. 5-2 Back Cover SCREW T4 X 12 Screw MT4x8-PH-Cross-Black 1. -
Page 20: System Board
Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 20/72 5-3 System Board Screw MT4x8-PH-Cross-Black Screw M4x8-PH-CETW-NI Screw T3*8 MT3*6-PH-CROSS-Black 1. Loosen and remove 24 screws 2. Take off the WALLMOUNT Module Company Confidential-DRAFT... - Page 21 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 21/72 3. Loosen and remove 5 screws and safely remove connectors as indicated by red circles 4. Take off the System Board. Company Confidential-DRAFT...
-
Page 22: Power Module For Lpl-Wx1
Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 22/72 5-4 Power Module for LPL-WX1 MT3*6-PH-CROSS-Black 1. Loosen and remove 6 screws and safely remove connectors indicated by red circles. 2. Safely remove the Power module. Company Confidential-DRAFT... - Page 23 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 23/72 Company Confidential-DRAFT...
-
Page 24: Power Module For Lpl-Wx4
Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 24/72 5-5 Power Module for LPL-WX4 MT3*6-PH-CROSS-Black Loosen and remove 6 screws and safely remove connectors indicated by red circles. Safely remove the Power module. Company Confidential-DRAFT... -
Page 25: Panel Module
Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 25/72 5-6 Panel Module Screw M4x12-Black Screw MT4x8-PH-Cross-Black MT3*6-PH-CROSS-Black 1. Loosen and remove 18 screws. 2. Take off the 37C_Support Metal Assy_MDA3 Company Confidential-DRAFT... - Page 26 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 26/72 3. Safely remove the LVDS wire indicated by red circles. 4. Remove the Panel Module Company Confidential-DRAFT...
-
Page 27: Speakers
Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 27/72 5-7 Speakers Screw MT4x10-W-H 1. Loosen and remove 4 screws. 2. Gently remove the speaker connectors that are indicated by a red circle. 3. Safely remove speakers. Company Confidential-DRAFT... - Page 28 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 28/72 Company Confidential-DRAFT...
-
Page 29: Keypad Board
Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 29/72 5-8 Keypad Board Screw T3*8 Black MT3*6-PH-CROSS-Black 1. Loosen and remove 7 screws and safely remvoe connector indicated by a red circle. 2. Safely remove the Keypad board. 6. - Page 30 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 30/72 Company Confidential-DRAFT...
-
Page 31: Firmware Upgrade
This process installs a new version of firmware that fixes or enhances your TV. What products does this instruction apply to? Model: Olevia 237, 437, 537 and 542 What do you need before installing? 1. A USB A to B cable. - Page 32 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 32/72 Firmware Necessary for Interface Tool Interface Tool to run. Firmware Download USB Driver Instructions 4. Connect USB cable from your computer to the TVs firmware upgrade port located in the back of the unit.
- Page 33 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 33/72 5. Once you finish installing the USB driver, open the Interface Tool to begin downloading the firmware. Mtk_DL_V1.4 A_20060601.exe 6. Turn On the Television. Company Confidential-DRAFT...
- Page 34 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 34/72 7. Press Step 1 to begin downloading the Firmware. (Note: Will take roughly 15 seconds to begin loading firmware at which TV will turn off.) 8. When step 1 is complete, a message will prompt you to disconnect and connect the power cord. (Press OK after you plug in the power cord.) Company Confidential-DRAFT...
- Page 35 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 35/72 9. Connect Power Cable and continue to power on the television. (Press the OK button after the television turns on.) 10. Press Step 2 to continue firmware loading. (Note: Will take roughly 15 seconds to begin loading firmware.) Company Confidential-DRAFT...
- Page 36 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 36/72 11. When step 2 is complete, a message will prompt you to disconnect and connect the power cord. (Press OK after you plug in the power cord.) 12.
- Page 37 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 37/72 13. Turn TV ON and check that firmware was successfully loaded. (Press Menu to activate the On Screen Display – Scroll UP/DOWN to SET UP and press Enter –...
-
Page 38: Edid Write In And Adc Correction And Parameter Adjustment
Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 38/72 8. EDID write in and ADC correction and Parameter Adjustment 8-1 EDID write in 8-1.1 EDID tools 1. PC（Notebook） 2. Software（EDID Write EEprom20060816.exe）and confirm Personal computer hard disk Have 2 files (1. -
Page 39: Adc Correction And Parameter Adjustment
Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 39/72 that change next set. 8-2 ADC correction and Parameter adjustment Photo 1 ADC correction and Parameter adjustment tools： 1. PC（Notebook） 2. CHROMA 2325 3. MINOLTA CA-210 4. Software（Gamma Calculator6A_Jason.exe） 8-2.1 ADC correction 1. - Page 40 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 40/72 Company Confidential-DRAFT...
-
Page 41: 8-2.2 Parameter Adjustment
Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 41/72 8-2.2 Parameter adjustment Photo 4 1. Click the icon on the desk "Gamma Calculator" (please Photo 1), and then Photo 2 would show up. 2. Click the icon "Gamma Calculator" of Photo 2, and then... -
Page 42: Exploded View
Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 42/72 9.Exploded view Company Confidential-DRAFT... -
Page 43: Parts List And Photo
SCREW /T4*10/Ni MS0-WA14010G000 TV barcode label ML0-0000016G000 S/N lebel 15*44mm ML0-0000015G000 RIBBON MX0-0000000G000 Heatproof tape MP2-0000175G000 237T Marketing Label_GP ML0-1000155G000 537_542 tech label-Dolby ML0-0000314G002 MD1 40" keypad wire+Magnet buckle SX0-0000446G000 37C_Speaker_Module_R+ Magnet buckle SX0-0000441G000 37C_Speaker_Module_Left+ Magnet buckle SX0-0000442G000 Power on Label-2 ML0-0000438G000 37"... - Page 44 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 44/72 37C_CUSHING-TOP MP2-1000031G000 37C EPE Bag MP2-0000162G000 TEAM LIFT Label ML0-0000393G000 Drawing paper 1080x910 MX0-0000079G000 37C3_B_PROTECTION PAPER MX0-0000100G000 RFID tag for Target models ML0-0000455G000 BARCODE W90mm*60mm ML0-0000195G000 Barcode ribbon transfer paper ML0-0000017G000 237-T11 Carton w /weee logo MX0-3000326G000...
- Page 45 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 45/72 10-2 PARTS PHOTO For LPL WX1-SL01 (See 10.1 Parts list ) Item NO：1 Item NO：2 Parts name：537 MDA3 power module Parts name：LG 37" LCD panel (w/AI) Parts NO. ：ELP-37WX1SLG000 Parts NO.
- Page 46 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 46/72 Item NO：7 Item NO：8 Parts name：Flat Cable Clip_FAA51-PG Parts name：32_37C_KEYPAD_BUTTON Parts NO ：EEC-FCFAA51G000 Parts NO. ：MP0-0000497G000 Item NO：9 Item NO：10 Parts name：Graphic Label for MDA3 Parts name：37C_Support Metal Assy_MDA3 Parts NO.
- Page 47 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 47/72 Item NO：13 Item NO：14 Parts name：SCREW T4 X 12 Parts name：SCREW /NI/MT4*8 Parts NO. ：MS0-WA34012G000 Parts NO. ：MS0-FA14008G000 Item NO：15 Item NO：16 Parts name： Parts name：SCREW T3*8 Black Parts NO.
- Page 48 Parts name ： Heatproof tape Parts NO. ： MX0-0000000G000 Parts NO. ： MP2-0000175G000 Item NO ： 23 Item NO ： 24 Parts name ： 237T Marketing Label_GP Parts name ： 537_542 tech label-Dolby Parts NO. ： ML0-1000155G000 Parts NO. ： ML0-0000314G002 Company Confidential-DRAFT...
- Page 49 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 49/72 Item NO ： 25 Item NO ： 26 Parts name ： Parts name ： MD1 40" keypad wire+Magnet buckle 37C_Speaker_Module_R+ Magnet buckle Parts NO. ： SX0-0000446G000 Parts NO. ： SX0-0000441G000 Item NO ：...
- Page 50 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 50/72 Item NO ： 31 Item NO ： 32 Parts name ： Screw T4*25-PH-Cross-Black Parts name ： 37C_STAND_COVER_2nd Parts NO. ： MS0-BA34025G000 Parts NO. ： MP0-0000535G001 Item NO ： 34 Item NO ：...
- Page 51 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 51/72 Item NO ： 37 Item NO ： 38 Parts name ： Condnctive shielding foam Parts name ： Magnet buckle-B15-UH-13x23x7 Parts NO. ： EEC-EM22033G000 Parts NO. ： EEC-PLB15UHG000 Item NO ：...
- Page 52 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 52/72 Item NO ： 43 Item NO ： 44 Parts name ： Drawing paper 1080x910 Parts name ： 37C3_B_PROTECTION PAPER Parts NO. ： MX0-0000079G000 Parts NO. ： MX0-0000100G000 Item NO ：...
- Page 53 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 53/72 Item NO ： 49 Item NO ： 50 Parts name ： AC Power Cord Parts name ： LT23HVT remote control Parts NO. ： ECB-0318AW8G000 Parts NO. ： EEC-RC0CG37G000 Item NO ：...
- Page 54 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 54/72 Item NO ： 55 Item NO ： 56 Parts name ： QSG-En-Fr_MTK_237_Target-1 Parts name ： OSD Tree Guide Parts NO. ： MK0-QS00097G000 Parts NO. ： MK0-QS00092G000 Item NO ： 58 Item NO ：...
-
Page 55: Parts List For Lpl Sla1
SCREW/T4*10/Ni MS0-WA14010G000 TV barcode label ML0-0000016G000 S/N label 15*44mm ML0-0000015G000 RIBBON MX0-0000000G000 Heatproof tape MP2-0000175G000 237T Marketing Label_GP ML0-1000155G000 537_542 tech label-Dolby ML0-0000314G002 MD1 40" keypad wire+Magnet buckle SX0-0000446G000 37C_Speaker_Module_R+ Magnet buckle SX0-0000441G000 37C_Speaker_Module_Left+ Magnet buckle SX0-0000442G000 Power on Label-2 ML0-0000438G000 37"... - Page 56 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 56/72 37C_CUSHING-TOP MP2-1000031G000 37C EPE Bag MP2-0000162G000 TEAM LIFT Label ML0-0000393G000 Drawing paper 1080x910 MX0-0000079G000 37C3_B_PROTECTION PAPER MX0-0000100G000 RFID tag for Target models ML0-0000455G000 BARCODE W90mm*60mm ML0-0000195G000 Barcode ribbon transfer paper ML0-0000017G000 237-T11 Carton w /weee logo MX0-3000326G000...
- Page 57 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 57/72 10-4 PARTS PHOTO For LPL WX1-SLA1 (See 10.3 Parts list ) Item NO ： 1 Item NO ： 2 Parts name ： 271W power module Parts name ： Parts NO.
- Page 58 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 58/72 Item NO ： 7 Item NO ： 8 Parts name ： Flat Cable Clip_FAA51-PG Parts name ： 32_37C_KEYPAD_BUTTON Parts NO ： EEC-FCFAA51G000 Parts NO. ： MP0-0000497G000 Item NO ： 10 Item NO ：...
- Page 59 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 59/72 Item NO ： 13 Item NO ： 14 Parts name ： SCREW T4 X 12 Parts name ： SCREW /NI/MT4*8 Parts NO. ： MS0-WA34012G000 Parts NO. ： MS0-FA14008G000 Item NO ：...
- Page 60 Parts name ： Heatproof tape Parts NO. ： MX0-0000000G000 Parts NO. ： MP2-0000175G000 Item NO ： 23 Item NO ： 24 Parts name ： 237T Marketing Label_GP Parts name ： 537_542 tech label-Dolby Parts NO. ： ML0-1000155G000 Parts NO. ： ML0-0000314G002 Company Confidential-DRAFT...
- Page 61 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 61/72 Item NO ： 25 Item NO ： 26 Parts name ： Parts name ： MD1 40" keypad wire+Magnet buckle 37C_Speaker_Module_R+ Magnet buckle Parts NO. ： SX0-0000446G000 Parts NO. ： SX0-0000441G000 Item NO ：...
- Page 62 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 62/72 Item NO ： 31 Item NO ： 32 Parts name ： Screw T4*25-PH-Cross-Black Parts name ： 37C_STAND_COVER_2nd Parts NO. ： MS0-BA34025G000 Parts NO. ： MP0-0000535G001 Item NO ： 34 Item NO ：...
- Page 63 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 63/72 Item NO ： 37 Item NO ： 38 Parts name ： Condnctive shielding foam Parts name ： Magnet buckle-B15-UH-13x23x7 Parts NO. ： EEC-EM22033G000 Parts NO. ： EEC-PLB15UHG000 Item NO ：...
- Page 64 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 64/72 Item NO ： 43 Item NO ： 44 Parts name ： Drawing paper 1080x910 Parts name ： 37C3_B_PROTECTION PAPER Parts NO. ： MX0-0000079G000 Parts NO. ： MX0-0000100G000 Item NO ：...
- Page 65 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 65/72 Item NO ： 49 Item NO ： 50 Parts name ： AC Power Cord Parts name ： LT23HVT remote control Parts NO. ： ECB-0318AW8G000 Parts NO. ： EEC-RC0CG37G000 Item NO ：...
- Page 66 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 66/72 Item NO ： 55 Item NO ： 56 Parts name ： QSG-En-Fr_MTK_237_Target-1 Parts name ： OSD Tree Guide Parts NO. ： MK0-QS00097G000 Parts NO. ： MK0-QS00092G000 Item NO ： 58 Item NO ：...
-
Page 67: Parts List For Lpl Wx4
MS0-A133006G000 SCREW/T4*10/Ni MS0-WA14010G000 TV barcode label ML0-0000016G000 S/N label 15*44mm ML0-0000015G000 RIBBON MX0-0000000G000 Heatproof tape MP2-0000175G000 237T Marketing Label_GP ML0-1000155G000 537_542 tech label-Dolby ML0-0000314G002 MD1 40" keypad wire+Magnet buckle SX0-0000446G000 37C_Speaker_Module_R+Magnet buckle SX0-0000441G000 37C_Speaker_Module_Left+Magnet buckle SX0-0000442G000 Power on Label-2 ML0-0000438G000 37"... - Page 68 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 68/72 37C_CUSHING-TOP MP2-1000031G000 37C EPE Bag MP2-0000162G000 TEAM LIFT Label ML0-0000393G000 Drawing paper 1080x910 MX0-0000079G000 37C3_B_PROTECTION PAPER MX0-0000100G000 RFID tag for Target models ML0-0000455G000 BARCODE W90mm*60mm ML0-0000195G000 Barcode ribbon transfer paper ML0-0000017G000 237-T11 Carton w /weee logo MX0-3000326G000...
-
Page 69: Parts Photo For Lpl Wx4
Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 69/72 10-6 PARTS PHOTO For LPL WX4 –SLA1 (See 10.5 Parts list ) Item NO ： 1 Item NO ： 2 Parts name ： AEP013 37" power supply Parts name ：... - Page 70 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 70/72 Item NO ： 7 Item NO ： 8 Parts name ： Flat Cable Clip_FAA51-PG Parts name ： 32_37C_KEYPAD_BUTTON Parts NO ： EEC-FCFAA51G000 Parts NO. ： MP0-0000497G000 Item NO ： 10 Item NO ：...
- Page 71 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 71/72 Item NO ： 13 Item NO ： 14 Parts name ： SCREW T4 X 12 Parts name ： SCREW /NI/MT4*8 Parts NO. ： MS0-WA34012G000 Parts NO. ： MS0-FA14008G000 Item NO ：...
- Page 72 Parts name ： Heatproof tape Parts NO. ： MX0-0000000G000 Parts NO. ： MP2-0000175G000 Item NO ： 23 Item NO ： 24 Parts name ： 237T Marketing Label_GP Parts name ： 537_542 tech label-Dolby Parts NO. ： ML0-1000155G000 Parts NO. ： ML0-0000314G002 Company Confidential-DRAFT...
- Page 73 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 73/72 Item NO ： 25 Item NO ： 26 Parts name ： Parts name ： MD1 40" keypad wire+Magnet buckle 37C_Speaker_Module_R+ Magnet buckle Parts NO. ： SX0-0000446G000 Parts NO. ： SX0-0000441G000 Item NO ：...
- Page 74 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 74/72 Item NO ： 31 Item NO ： 32 Parts name ： Screw T4*25-PH-Cross-Black Parts name ： 37C_STAND_COVER_2nd Parts NO. ： MS0-BA34025G000 Parts NO. ： MP0-0000535G001 Item NO ： 34 Item NO ：...
- Page 75 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 75/72 Item NO ： 37 Item NO ： 38 Parts name ： Condnctive shielding foam Parts name ： Magnet buckle-B15-UH-13x23x7 Parts NO. ： EEC-EM22033G000 Parts NO. ： EEC-PLB15UHG000 Item NO ：...
- Page 76 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 76/72 Item NO ： 43 Item NO ： 44 Parts name ： Drawing paper 1080x910 Parts name ： 37C3_B_PROTECTION PAPER Parts NO. ： MX0-0000079G000 Parts NO. ： MX0-0000100G000 Item NO ：...
- Page 77 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 77/72 Item NO ： 49 Item NO ： 50 Parts name ： AC Power Cord Parts name ： LT23HVT remote control Parts NO. ： ECB-0318AW8G000 Parts NO. ： EEC-RC0CG37G000 Item NO ：...
- Page 78 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 78/72 Item NO ： 55 Item NO ： 56 Parts name ： QSG-En-Fr_MTK_237_Target-1 Parts name ： OSD Tree Guide Parts NO. ： MK0-QS00097G000 Parts NO. ： MK0-QS00092G000 Item NO ： 58 Item NO ：...
-
Page 79: Menu Wheel
LCD TV For 237-T11 Page 79/72 11.Menu wheel Press the MENU button on the Remote Control to the Olevia TV .The MENU WHEEL appears. Select one of the menus as shown below and on the following pages: Picture,Setup, Audio or Screen. Picture... - Page 80 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 80/72 Audio Treble Bass Balance Language English, Francais, Espanol MTS (Multi-channel Mono, SAP, Stereo Television Sound) Mute On, Off Speaker On, Off iDIVA Off, Rock, POP, Live, Classic, Soft, Concert, Living Room, Hall, Arena, Church Lip Sysc...
- Page 81 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 81/72 Screen Adjustment H.Position V.Position Fine Tune Auto Sync Aspect Ratio Aspect, Full Screen, Panoramic, Zoom 1, Zoom 2, 1:1 Mode Cropping On, Off (Off, Minimum, Medium, Maximum) View Full Screen, PIP, Split Screen Low Right, Low Left,...
- Page 82 Doc No. SM_237-T11_19Nov07 Service Manual TITLE Version LCD TV For 237-T11 Page 82/72 Setup Channel Setup Favorite, Skip, Name Auto Channel Search Cable Standard, Air Channel Add Closed Caption Analog Type CC1~4, T1~4 Digital Type Off, CS1~6 Font As Broadcaster, Stype1~7 Size As Broadcaster, Large, Medium, Small...
