Inalsa DuoClean Instruction Manual

Hide thumbs
1
2
3
4
5
6
7
8
9
Table of Contents

Advertisement

Quick Links

Duo Clean
Vacuum
Cleaner
Instruction Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DuoClean and is the answer not in the manual?

Questions and answers

Related Manuals for Inalsa DuoClean

Summary of Contents for Inalsa DuoClean

  • Page 1 Duo Clean Vacuum Cleaner Instruction Manual...
  • Page 2 Your INALSA Vacuum Cleaner has a lot of thoughtful features built in to make your cleaning convenient. Please read these instructions carefully, so that you may get the best out of the power packed features in your INALSA Vacuum Cleaner.

  • Page 3: Parts Identification

    Parts Identification Part No. Parts Name Suction inlet Dust container Push button to release dust container Hole to attach shoulder strap On/Off switch Handle Blower outlet Blower attachment Outlet cover Cord plug Curved tube Pressure adjustment slider Extension tube (3 nos.) Crevice nozzle cum Upholstery brush Floor cum Carpet brush 12a.

  • Page 4: Technical Specifications

    Technical Specifications* Model DuoClean Wattage 1000W Voltage 230V, 50Hz, AC Cord Plug PVC cord, 5m length, 2 Pin plug Dust Bag Capacity 0.4 L * Due to continuous improvements in product, specifications are subject to change without prior notice. Attachments 1.
  • Page 5 Assembly 1. To open the dust container (2) push the button (3) and pull out the dust container. Verify that the dust bag filter (16) is inside, then attach the dust container to the vacuum cleaner. While using the vacuum side, close the blower cover. 2.
  • Page 6 5. To use the blower feature, remove the cover (7b) and attach the blower (7a). Depending on the usage, blower can be used with/without attachments. 6. To take off the motor protection filter of air input(from suction side) for washing when it is dirty, push button to release the dust container, take out filter and wash gently and place it back.

  • Page 7: Cleaning And Maintenance

    Cleaning & Maintenance 1. Always unplug the appliance from the electrical outlet before cleaning. Clean the outer body and attachments with damp cloth. 2. To open the dust container, press push button and pull out the dust container. 3. Remove the dust-bag filter and empty the dust from it. 4.
  • Page 8 READ THE FOLLOWING INSTRUCTIONS CAREFULLY BEFORE USING YOUR VACUUM CLEANER : Do not leave appliance when plugged in. Unplug from outlet when not in use and before opening the dust container. Use only as described in this manual & use only recommended attachments. Do not use with damaged cord or plug.

  • Page 9: Troubleshooting Guide

    TROUBLE SHOOTING GUIDE PROBLEM POSSIBLE CAUSES PROBLEM SOLUTIONS 1. Power cord not firmly VACUUM CLEANER 1. Plug in unit firmly. plugged into outlet. NOT OPERATING 2. No power in wall outlet. 2. Check Power. 3. Stop while working 3. Overheated, leave it for 10 minutes before restarting.
