Rob Pleas Photography GH-13 User Manual

Gimbal head
Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Quick Links

Download this manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the GH-13 and is the answer not in the manual?

Questions and answers

Summary of Contents for Rob Pleas Photography GH-13

  • Page 2 INTRODUCTION Thank you for purchasing the GH-13 Gimbal Tripod Head from Rob Pleas Photography. To get the most out of your tripod head, please read this user's manual thoroughly before use. This user's manual explains the GH-13’s functions, operation methods, and specifications. In addition, keep your camera’s user’s manual handy for quick...

  • Page 3: User Notice

    USER NOTICE Your GH-13 Gimbal head has been designed for years of maintenance free use. Please follow the guidelines below to ensure the best performance, reliability, and durability expected from your product. 1. Do not exceed the maximum specified load capacity (see product specification chart or visit www.robpleasphotography.com).
  • Page 4 Keep out of the reach of children. 9. Remove camera lens and all gear from the GH-13 Gimbal head and any tripod or monopod when transporting. 10. You may notice marks on the finish where the lock-pins engage. This is normal and...
  • Page 5 5. If you do not have a quick-release plate, use the included bolt and carefully attach your lens to swing bracket B. Hand-tighten the bolt only. 6. With the lens securely attached to the GH-13 Gimbal, carefully attach the camera body to the lens.

  • Page 6: Operation

    OPERATION 1. With your left hand securely holding the foot of the camera lens, pull the handle of lock-pin D upwards with your right finger(s) and rotate the handle 90°. This will release the locking mechanism of the lock-pin and allow the tripod head to rotate.
  • Page 7 This is an advanced process that requires hand tools and is not recommended due to the possibility of damage to the GH-13 and/or your camera equipment! If you feel you must change the bearing tension, a simple crescent wrench and hex wrench can be used to increase or decrease tension on the bearings.
  • Page 8 GH-13 PARTS DIAGRAM A “L’ Frame B Inner Swing Bracket C Lower Shaft D Lower Lock-Pin E Upper Lock-Pin F Lower Bearing Stack G Upper Bearing Stack...

  • Page 9: Specifications

    SPECIFICATIONS Weight 1 lb 10 oz.. Max. Dimensions 9 3/8”H x 1”W x 5 1/2”L Maximum Specified Load Capacity 13 lbs Robco, LLC. dba Rob Peas Photography E-mail: robpleasphoto@earthlink.net Fax: (253) 537-3558 www.robpleasphotography.com Specifications and design are subject to change without notice. All tradenames, logos, and brand references are the respective trademarks of their owners.
