DEVA Broadcast DB9000-STC Instruction Manual
Dsp-based stereo generator with rds/rbds encoder
Hide thumbs
Also See for DB9000-STC:
- Maintenance and operation instruction manual (59 pages) ,
- Quick user manual (7 pages)
Related Manuals for DEVA Broadcast DB9000-STC
Summary of Contents for DEVA Broadcast DB9000-STC
- Page 1 MAINTENANCE AND OPERATION INSTRUCTION MANUAL DB9000-STC DSP-Based Stereo Generator with RDS/RBDS Encoder Publish Date: 26-Nov-2012...
-
Page 2: Table Of Contents
Heat Dissipation ........................... 14 Panel Indicators and Appointments ....................15 Front View ............................. 15 Rear View ............................16 Connecting of DB9000-STC ......................17 Analog Audio Inputs ........................17 Digital Audio Input ........................17 LAN Port ............................17 RS-232 COM Port ......................... 17 Operation ............................ - Page 3 Injection Levels ......................... 28 Phase Adjustment ........................29 MPX Limiter ..........................29 Output Levels ..........................29 Audio Enhancement Configuration ....................30 Automatic Gain Control Settings ....................30 Audio Equalizer Settings ......................31 RDS Encoder Configuration ......................32 RDS Encoder Settings ....................... 32 Program Station Name Settings ....................
- Page 4 THIS PAGE IS INTENTIONALLY LEFT BLANK...
-
Page 5: Introduction
Since 2003 DEVA Broadcast Ltd. has been ISO 9001 certified . The contractors of DEVA Broadcast Ltd. are satisfied with the permanent business comfort and to their own confession they owe it to a great extent as well as their prosperity to the loyal partnership of our company. -
Page 6: General Information
Automation Systems and offers an ASCII protocol for broadcast song/artist information. Another great feature of the DB9000-STC is that it can fight the dreaded dead air problem. The DB9000-STC provides additional uncompromising security in case of loss of audio at the audio inputs. -
Page 7: Product Features
65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria Tel: +359 56 820027, Fax: +359 56 836700 E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com Product Features • Fully Digital 32 bits DSP Stereo Encoder • Excellent Audio Performances • Digital Volume Control of all Audio Inputs •... -
Page 8: Technical Specifications
65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria Tel: +359 56 820027, Fax: +359 56 836700 E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com TECHNICAL SPECIFICATIONS ANALOG AUDIO INPUT Connector 2 x XLR, Stereo Type Balanced 600Ω or High Impedance Impedance Level +6dBu / +12dBu, user selectable Sample rate 96 kHz;... - Page 9 65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria Tel: +359 56 820027, Fax: +359 56 836700 E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com PHONES AUDIO OUTPUT Connector 1/4” (6.3mm) Phone Jack, Stereo Type Headphones USER INTERFACE Indicators 4 LEDs on front panel, 2 LEDs on rear panel Web interface Full control and status information RS-232...
-
Page 10: Block Diagram
COMPOSITE MPX LIMITER EQUALIZER Because of the all-digital, minimalist-discrete-component nature of device circuitry, we have not provided schematic diagrams of the DB9000-STC in this Manual. Please, note that: NO USER-SERVICEABLE COMPONENTS INSIDE. REFER ALL SERVICING TO QUALIFIED TECHNICAL PERSONNEL. - 10 -... -
Page 11: Safety Precautions
DEVA Broadcast Ltd. declines all responsibility if any one of the safety rules given herein is not observed. DEVA Broadcast Ltd. declines all responsibility if the end-user resells the product. -
Page 12: Before You Start
AC mains connector on the encoder circuit board. With power disconnected, use a small screwdriver to set the switch for 115VAC or 230VAC operation. Be sure to install the appropriate fuse, DB9000-STC is equipped at the factory with 1A fuse. POWER CORD The detachable IEC-type power cord is supplied with the unit. -
Page 13: Operating Recommendations
• We do not recommend installation in rooms with high humidity, dusty places or other aggressive conditions. • Although it is expected that a DB9000-STC will be installed close to exciters (or transmitters of even higher-power!), please practice reasonable care and common sense in locating the unit away from abnormally high RF fields. -
Page 14: Unpacking And Inspection
Warranty! Mounting RACK REQUIREMENT The DB9000-STC mounts in a standard 19-inch equipment rack and requires only 1¾ inches (1U) of vertical rack space. The use of plastic washers is recommended to protect the painted finish around the mounting holes. -
Page 15: Panel Indicators And Appointments
Audio signal identical to that of the outputs audio; 2 - Power LED Indicator; 3 - Status LED Indicator. Blinking frequency of this LED is indication of DB9000-STC state: Fast blinking – in process of connection; Approximately twice per second – data buffering;... -
Page 16: Rear View
65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria Tel: +359 56 820027, Fax: +359 56 836700 E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com REAR VIEW RS-232 FUSE COM PORT RESET SD CARD RIGHT LEFT AES/EBU 1 - RDS only output - BNC, Unbalanced; 2 - MPX ouput - BNC, Unbalanced; 3 - Factory Defaults Reset Button;... -
Page 17: Connecting Of Db9000-Stc
– either analog or digital one. Selecting the preferred input can be performed under CONFIGURATION menu (see “Audio Input” on page 28). LAN PORT For normal operation it is necessary DB9000-STC to be connected to a local network or Internet by cable with RJ-45 connector. RS-232 COM PORT Using standart DB-9 cable connect DB9000-STC to any RS-232 compatible equipment. -
Page 18: Operation
E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com Operation DB9000-STC is controlled through the built-in web server and a standard web browser can be used to monitor its status or make some adjustments. To connect to the device you need to know its IP address and follow the next steps: •... - Page 19 65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria Tel: +359 56 820027, Fax: +359 56 836700 E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com The picture below is illustrating STATUS page opened: NOTE: As shown on the picture below a Username and Password may be requested if the Access Control is turned on and a page other then STATUS is selected (see “WEB Server Settings”...
-
Page 20: Status
Tel: +359 56 820027, Fax: +359 56 836700 E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com STATUS On the picture below is shown the page with current device status: This page contains information regarding current status of DB9000-STC as follows: • Audio Status; • Backup Audio Status; • Network Status •... - Page 21 If the stream is in uncompressed format (PCM) then what is displayed for Sample rate and Bitrate is what is set in the Configuration page. Under Other are displayed DB9000-STC date and time. In the upper right corner is located LIVE DATA icon. Clicking on the icon will toggle live data...
-
Page 22: General Configuration
Must be in hh:mm:ss format. Example: 23:10:00. Applying New Settings In order new settings to take effect, it is necessary to press the SAVE button. Please keep in mind that some of the new settings can reset DB9000-STC. - 22 -... -
Page 23: Network Configuration
65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria Tel: +359 56 820027, Fax: +359 56 836700 E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com NETWORK CONFIGURATION General Network Settings DHCP – As DHCP Client is used to automatically obtain the Network Settings it can be enabled or disabled. -
Page 24: Ip Voice Announcement
E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com IP Voice Announcement IP Address – Enable or disable voice announcement of DB9000-STC’s IP Address. This future is useful when the IP address is unknown, for example when it is obtained from the DHCP Server. Default is Enabled. -
Page 25: Backup Audio Configuration
E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com BACKUP AUDIO CONFIGURATION DB9000-STC has built-in backup audio player. It plays tracks from SD Card storage in case of main audio signal loss. These tracks can be preloaded on the SD Card or be uploaded through the built-in FTP server while DB9000-STC is operational. -
Page 26: Mp3 Audio Player Settings
The playlist file must be named playlist.m3u. Applying New Settings In order new settings to take effect, it is necessary to press the SAVE button. Please keep in mind that some of the new settings can reset DB9000-STC. - 26 -... -
Page 27: Rs-232 Com Port Configuration
Tel: +359 56 820027, Fax: +359 56 836700 E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com RS-232 COM PORT CONFIGURATION DB9000-STC also acts as Ethernet to RS-232 redirector. You can connect any RS-232 compatible equipment to DB9000-STC and communicate with it over the Internet. RS-232 Settings Baud rate –... -
Page 28: Stereo Encoder Configuration
65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria Tel: +359 56 820027, Fax: +359 56 836700 E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com STEREO ENCODER CONFIGURATION General Settings Stereo Mode – Switch between Stereo and Mono Mode for MPX signal. Mono Mode disables the 38 kHz sub-carrier. Emphasis –... -
Page 29: Phase Adjustment
E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com Phase Adjustment Phase of the Pilot Tone, L-R sub-carrier (38 kHz) and RDS sub-carrier (57 kHz) are factory adjusted. Additional adjustments can be made by the user providing more flexibility in DB9000-STC settings. MPX Limiter Enable – Enable or Disable the MPX Limiter. -
Page 30: Audio Enhancement Configuration
65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria Tel: +359 56 820027, Fax: +359 56 836700 E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com AUDIO ENHANCEMENT CONFIGURATION Automatic Gain Control Settings Enable – Enable or Disable the Automatic Gain Control. Preset – There are three factory and two user configurable presets available. Users can set their own AGC presets changing the following parameters: - Attack time –... -
Page 31: Audio Equalizer Settings
To avoid audio distortion the overall level of this frequency must not exceed 0dB. Applying New Settings In order new settings to take effect, it is necessary to press the SAVE button. Please keep in mind that some of the new settings can reset DB9000-STC. - 31 -... -
Page 32: Rds Encoder Configuration
65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria Tel: +359 56 820027, Fax: +359 56 836700 E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com RDS ENCODER CONFIGURATION RDS Encoder Settings Enable – General Enable or Disable RDS Encoder. Program Station Name Settings PS Static – The 8-character PS field is for the “street name” of the station. This will appear on the radio faceplate whenever a dynamic, scrolling –... -
Page 33: Radio Text Settings
65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria Tel: +359 56 820027, Fax: +359 56 836700 E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com or received as ASCII text from station automation. Very short words are sent together in groups. For instance, THIS IS constitutes seven characters that can be sent as a group. The same would hold true for OF THE or NOW HERE. -
Page 34: Trafic Information
65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria Tel: +359 56 820027, Fax: +359 56 836700 E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com that carries the same variety of music, though not the very same program, as provided by AF switching. The PTY function of RDS helps a broadcaster catch ‘transient audience’ share. Under some programming circumstances, the PTY identifier may be made ‘dynamic,’... -
Page 35: Decoder Information
65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria Tel: +359 56 820027, Fax: +359 56 836700 E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com Decoder Information DI – Decoder Information: This is one of several ‘flags’ that convey yes/no or other very basic data. This particular flag tells the receiver whether the broadcast is monaural, or is being transmitted in any of several methods of stereo or binaural broadcasting. -
Page 36: Console Settings
For more information about the RDS console see chapter “RDS Console”. Applying New Settings In order new settings to take effect, it is necessary to press the SAVE button. Please keep in mind that some of the new settings can reset DB9000-STC. - 36 -... -
Page 37: Af List Configuration
65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria Tel: +359 56 820027, Fax: +359 56 836700 E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com AF LIST CONFIGURATION On the above picture is displayed Alternative Frequencies List Configuration Page, consisting of 25 AF settings: AF xx – Select alternative frequency of current program. You can choose from 207 standard AF list options as defined in the RDS/RBDS standard. -
Page 38: Factory Defaults Settings
Tel: +359 56 820027, Fax: +359 56 836700 E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com FACTORY DEFAULTS SETTINGS On the above picture is shown the Factory Defaults page. Restoring DB9000-STC to its Factory Defaults can be done by following the next steps: •... -
Page 39: General Default Settings
65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria Tel: +359 56 820027, Fax: +359 56 836700 E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com Upon completion of the process DB9000-STC settings will have the following values: General Default Settings Device Alias: • Alias: DB9000-STC Date and Time: •... -
Page 40: Com Port Default Settings
65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria Tel: +359 56 820027, Fax: +359 56 836700 E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com COM Port Default Settings RS-232 Settings: • Baud rate: 9600 Ethernet to RS-232 Redirector: • Port: 8001 • Password: blank (empty) Stereo Encoder Default Settings General Settings : •... -
Page 41: Rds Encoder Default Settings
RDS Encoder Settings: • Enable: Enabled Program Station Name Settings: • PS Static: DB9000 • PS Dynamic: DB9000-STC Stereo Coder & RDS Encoder • DPS Scroll Step: 0 – centered • DPS Scroll Speed: 0 – DPS off Radio Text Settings: •... -
Page 42: Hardware Reset
Tel: +359 56 820027, Fax: +359 56 836700 E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com HARDWARE RESET This process will fully restore DB9000-STC to its Factory Defaults, including the Network settings. Hardware Reset can be done by following the next steps: • Disconnect the power supply cable from the unit. -
Page 43: Rebooting
65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria Tel: +359 56 820027, Fax: +359 56 836700 E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com REBOOTING On the above picture is shown the Reboot page. Rebooting of DB9000-STC can be done by following the next steps: • Press the “Reboot” button. -
Page 44: Firmware Update
65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria Tel: +359 56 820027, Fax: +359 56 836700 E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com FIRMWARE UPDATE On the above picture is shown the Firmware Update page. To update the device firmware, please follow the next steps: •... -
Page 45: Rds Console
65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria Tel: +359 56 820027, Fax: +359 56 836700 E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com RDS Console CONNECTING TO THE RDS CONSOLE The RDS Console is used to edit RDS settings in real time. For example it can be used by automation software. -
Page 46: List Of Available Rds Console Commands And Responses
Command properly formatted but data not understood. Console has been inactive for more than 30 minutes and the connection will be dropped. User needs to connect again to enter more commands. (NO RESPONSE) Data sent is ignored by DB9000-STC. - 46 -... -
Page 47: Upnp Discovery In Local Networks
E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com UPnP discovery in Local Networks DB9000-STC implements UPnP which lets you easily find it in your local network. For this purpose your system should have UPnP enabled (see “UPnP Activation” on page 48). To discover the device follow the next steps: •... -
Page 48: Upnp Activation
65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria Tel: +359 56 820027, Fax: +359 56 836700 E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com UPnP Activation NOTE: The following explanations apply to Windows XP SP2 or SP3! If you use another operating system, please contact your system administrator. Open “My Network Places”. -
Page 49: Warranty Terms And Conditions
A. Equipment will not be accepted for Warranty or other repair without a Return Authorization (RA) number issued by DEVA Broadcast Ltd. prior to its return. An RA number may be obtained by calling the factory. The number should be prominently marked on the outside of the shipping carton. -
Page 50: Product Registration Card
Your signature* *Signing this warranty registration form you are stating that all the information provided to DEVA Broadcast Ltd. are truth and correct. DEVA Broadcast Ltd. declines any responsibility for the provided information that could result in an immediate loss of warranty for the above specified product(s).
