Connect one end of a coaxial cable to the coaxial wall outlet and connect
1.
the other end to the "CABLE IN" port on the Digital Adapter.
Connect one end of another coaxial cable to the "TO TV" port on the
2.
Digital Adapter and the other end to the input port on the TV.
Connect the power cord to the electrical wall outlet and the "+5V DC IN"
3.
port on the Digital Adapter.
Make sure the channel 3/4 switch on the back of the Digital Adapter
4.
matches the channel on your television. If your Digital Adapter is set to
channel "3", make sure that your television is also on channel "3".
Cable In
To TV
Digital Adapter

User Guide

Ch 3/4
+5V DC In

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Digital Adapter and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Summit Broadband Digital Adapter

  • Page 1: User Guide

    Connect one end of another coaxial cable to the “TO TV” port on the Digital Adapter and the other end to the input port on the TV. Connect the power cord to the electrical wall outlet and the “+5V DC IN”...
  • Page 2 4. Press the MENU button (allow a few seconds for the menu to display) 5. Enter the pairing code displayed in blue on the pairing code pop-up screen Once your remote control is paired to a specific Digital Adapter, it will not control any other Digital Adapter in your home.
  • Page 3 Audio Language • Select AUDIO LANGUAGE • Press the OK button on your remote control • Scroll to select the desired audio language Close Captioning • Select CLOSED CAPTIONING • Press OK to change the status from ON/OFF • Select APPLY to change the setting Locks Setup The first time you enter Locks Setup, it will prompt you to Create Locks PIN.
  • Page 4 1. Press and hold the SETUP button until the LED indicator turns green 2. Press the VOLUME UP button on the remote control or press the VOLUME DOWN button to force the remote control to send the vol- ume control commands to the Digital Adapter.
