Summary of Contents for Shoe-Box DM-406
- Page 1 OWNER’S MANUAL OWNER’S MANUAL Shoe-Box DM-406, DM-408, DM-410 Digital Dimmers 805.541.8292\\805.541.8293 805.541.8292\\805.541.8293 DOVE LIGHTING SYSTEMS INC.\\3563 SUELDO STREET UNIT E DOVE LIGHTING SYSTEMS INC.\\3563 SUELDO STREET UNIT E SAN LUIS OBISPO\\ CA 93401 SAN LUIS OBISPO\\ CA 93401...
-
Page 2: Table Of Contents
OWNER’S MANUAL OWNER’S MANUAL :Table of Contents :Receiving Your Unit As soon as you have received your equipment, open the boxes //Receiving your equipment\\ and examine the contents. If the equipment in the carton does not //Features\\ match with your order or the packing slip, contact the factory //Installation\\ 05-06 immediately and we will be happy to help you. -
Page 3: Installation
Power input to the pack is via a flush-mount male connector either specialty interface boxes for this purpose. motor base u-ground inlet (DM-406) for regular extension cords, 20A 125v twist lock NEMA L520 (DM-408), or a 30A 125V twist lock NEMA L530 (DM-410) which is mounted on the back panel. -
Page 4: Control
OWNER’S MANUAL OWNER’S MANUAL :CONTROL Here is an example: -Set the thumbwheel switch to 600 for local control. A// Starting Channel: The starting channel is set on a thumbwheel switch. When the switch reads 001, the dimmer pack runs on channels 1 - 4. -Set the second to 1 to control the lamp on channel one. -
Page 5: In Case Of Trouble
OWNER’S MANUAL OWNER’S MANUAL :In Case of Trouble ****Be sure to check all wiring and lamps for shorts. Shorts in power cables, lamps can cause reoccurring major malfunctions. Most commonly blown SSR modules and Triacs. A// Troubleshooting: In some instances it may burn out the motorbase or the wiring. A review of the following paragraphs may save you a long distance phone call a tip to the service center, or the cost of shipping &/or repair. - Page 6 OWNER’S MANUAL OWNER’S MANUAL Users with further technical questions may call the factory at (805)541-8292. NOTE: DOVE SYSTEMS DIMMER PACKS USE TRADE SECRET AND PROPRIETARY CIRCUITY. FOR THIS REASON, SCHEMATICS CANNOT BE RELEASED FOR THIS PRODUCT. To obtain service, pack the unit with the original packing materials or crushed newspaper and return it, freight prepaid, Dove Lighting Systems 3563 Sueldo Street Unit E...
