8059 RF receiver ● users guide
DoorKing's 8059 receivers can be used as stand-alone or Wiegand applications. Stand-alone
applications can store up to 80 MicroCLIK transmitter codes activating its internal relay when
a valid transmitter code is received. Wiegand applications will output transmitter codes in
Wiegand format to an external Wiegand controller.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DoorKing 8059 RF
Summary of Contents for DoorKing 8059 RF
- Page 1 8059 RF receiver ● users guide DoorKing’s 8059 receivers can be used as stand-alone or Wiegand applications. Stand-alone applications can store up to 80 MicroCLIK transmitter codes activating its internal relay when a valid transmitter code is received. Wiegand applications will output transmitter codes in...
-
Page 2: Receiver Programming
1. INPUT POWER COMMON 2. INPUT POWER 12-24 VOLT AC or DC 3. RELAY NORMALLY OPEN 4. RELAY NORMALLY CLOSED 5. RELAY COMMON 6. WIEGAND COMMON 7. WIEGAND DATA 0 7. WIEGAND DATA 0 8. WIEGAND DATA 1 8. WIEGAND DATA 1 PROGRAMMING BUTTON PROGRAMMING LED WIEGAND PROGRAMMING LED’s... - Page 3 Stand-Alone Wiring 1. Connect 12-24 Volt AC or DC power to terminals 1 and 2. If DC power is used, terminal 1 is NEGATIVE and terminal 2 is POSITVE. Use minimum18 AWG wire to power the receiver. 2. Connect the receiver relay contacts to the device to be activated. Terminal 3 is NORMALLY OPEN (N.O.), terminal 4 is NORMALLY CLOSED (N.C.) and terminal 5 is COMMON (C).
- Page 4 LED sequence as shown. This will erase all regular and master transmitters. DKS DoorKing, Inc 8059-065-D-07-07 Designed by DKS, DoorKing in California 120 Glasgow Avenue, Inglewood, Ca. 90301, 310.641.1589...
