Preface Thanks for using this HD Video Conferencing Camera. This manual introduces the function, installation and operation of the HD camera. Prior to installation and usage, please read the manual thoroughly. Precautions This product can only be used in the specified conditions in order to avoid any damage to the camera: ...
Note Electric Safety Installation and operation must accord with electric safety standard. Caution to transport Avoid stress, vibration and soakage in transport, storage and installation. Polarity of power supply The power supply of the product is +12V, the max electrical current is 2A .Polarity of the power supply plug drawing as follows.
Supplied Accessories When you unpack, check that all the supplied accessories are included: Camera ........1PC AC power adaptor ....... 1PC Power cord ........1PC VISCA cable ....... 1PC Remote controller ......1PC User manual ......1PC...
Quick Start Step1. Please check connections are correct before starting...
Page 7
Step2. Setting of the bottomswitches Set both of the switch1 and switch2 to ‘OFF’. That is ‘Normal Working Mode’. SW-1 SW-2 Modes Normal Working Mode Software Update Mode Factory Debug Mode None Step3. Setting of the system select switch The option of video format: VIDEO SYSTEM 1080p60 720p30...
Page 8
Step4. Press the Switch ON/OFF button on the rear of the camera, the power lamp light. Step5. Pan-Tilt will rotate to the maximum position of top right after the camera started, then it return to the center, the process of initialization is finished. (Note: If the position preset 0 has been stored, the position preset 0 will be called up after initialization) Step6.
Features 1. Integrated 72.5 degree wide-angle lens for the first time, Optical 12x. 2. Camera provides a high performance in low illumination situations, particularly suitable for which room's lighting is not very well. 3. With maximum resolution of 1920 x 1080 and output frame rate up to 60 or 50 frames / sec, this camera provides high-definition as well as fluent video.
Main Unit 1. Lens 2. Sensor for the Remote Commander 3. Power lamp 4. Standby lamp 5. Bottom switches 6. Tripod screw hole 7. Fixing screw whole 8. System select switch 9. RS232 in jack 10. RS232 out jack 11. HD-SDI video jack (Optional) 12.
IR Remote Controller Explanation 0. Standby Button Press this button to enter standby mode. Press it again to enter normal mode. (Note: Power consumption in standby mode is approximately half of the normal mode) 1. Position Buttons To set preset or call preset 2.
Page 13
become dark. In this case, press the backlight ON / OFF button. To cancel this function, press the backlight ON / OFF button. 5. Focus Buttons Used for focus adjustment. Press [AUTO] adjust the focuses on the center of the object automatically. To adjust the focus manually, press the [MANUAL] button, and adjust it with [Focus+] (Focus on far object) and [Focus-] (Focus on near object) 6.
USE IR Remote Controller When the camera is working, you can use Move up: Press [ ] remote controller to perform panning, tilting, Move down: Press [ ] zooming and focusing, store and call back preset Move left: Press [ ] positions.
Page 15
effective in full auto exposure mode) 3. Focus Control 5. Presets Set/Clear Focus Far: Press [FOCUS+] button(NOTE: Effective only in manual focus mode) Focus Near: Press [FOCUS-] button(NOTE: Effective only in manual focus mode) Press and hold the button, the action of focus continues and stops as soon as the button is released.
Page 16
7. Camera Selection Press [#]+[#]+[#] will erase all preset positions in the memory. 6.Recalling the Preset Press the button corresponding to the camera you want to operate. 8. Camera IR Address Set Press any of the numeric buttons 0-9directly to [*]+[#]+[F1]: Address1 recall stored preset positions and settings.
RS-232CInterface Camera Windows DB-9 1.DTR 1.CD 2.DSR 2.RXD 3.TXD 3.TXD 4.GND 4.DTR 5.RXD 5.GND 6.GND 6.DSR 7.IR OUT 7.RTS 8.NC 8.CTS 9.RI Camera Mini DIN Function 1.DTR 1.DTR 2.DSR 2.DSR 3.TXD 3.TXD 4.GND 4.GND 5.RXD 5.RXD 6.GND 6.GND IR OUT 7.IR OUT 7.NC 8.NC...
Serial Communication Control In default working mode, the camera is able to connect to a VISCA controller with RS232C serial interface. The parameters of RS232C are as follows: Baud rate: 2400/4800/9600 bit/s. Start bit: 1 bit. Data bit: 8 bits. Stop bit: 1bit.
Page 20
VISCA Command List Part 1 Camera-Issued Messages Ack/Completion Message Command Command Packet Comments z0 41 FF Returned when the command is accepted. Completion z0 51 FF Returned when the command has been executed. z = Camera Address+8 Error Messages Command Command Packet Comments Returned when the command format is different or when a...
Menu Setting 1.MENU EXPOSURE Press [MENU] button to display the main menu Mode Auto on the normal screen,using arrow button to move the cursor to the item to be set.Press the [HOME] button EVLevel to enter the corresponding sub-menu. G.Limit MENU Exposure Flicker...
Page 33
60Hz COLOR Iris: .Optional items:F1.8,F2.0, Aperture value WB-Mode Auto F2.4,F2.8,F3.4,F4.0,F4.8,F5.6,F6.8,F8.0,F9.6,F11.0, RTuning Close(Effective only in Manual,AAE mode) BTuning Shutt:Shutter value.Optional items:1/2,1/4, Sat. 110% 1/8,1/15,1/30,1/60,1/90,1/100,1/125,1/180,1/250,1/35 AWBSens Normal 0,1/500,1/725,1/1000,1/1500,1/2000,1/3000,1/4000,1 /6000,1/10000(Effective only in Manual,SAE mode) Stren:WDR strength. Optional items: 0~6(Effective only in WDR mode) Select Item Meter:Metering mode,Optional items: Global, Change Value...
Page 34
AWBSens:The white balance sensitivity, Contrast:Contrast adjustment. Optional items: -5 Optional items:Low,Normal,High ~ +5 Hue:Automatic white balance is tonal,Optional Sharpness:Sharpness adjustment. Optional items: items:-7 ~ +7, Default 0(Effective only in Manual 0 ~ 15 mode) B&W-Mode:Black and white mode switch. Optional items: On, Off Flip-H:Image flipped horizontally.Optional...
Page 35
Optional items:On,Off NOISE REDUCTION SpeedByZ On:Zoom PTZ the larger of the focal NR2D-Level 4 length,camera P / T moving more slowly. NR3D-Level 3 Set:Reverse setting remote control,Optional D-HotPixel items:STD,REV(When set to REV, remote control or DarkDetail reverse) AF-Zone:Interested in focusing area,Optional items: Center,Bottom,Top AF-Sense:Automatic...
Page 36
menu and press [HOME] button,SETUP menu according to the agreement,can be set up under the appears,as shown in the following figure. VISCA items:1 ~ 7,P - P and P- D can be set up:0 ~ SETUP AddrFix:If I can change through the serial port Language of infrared switch,Optional items:On,Off(When set to ColorSys...
Page 37
RESTORE DEFAULT Restore? Change Value [Home] OK [Menu] Back Restore:Confirm restore factory settings. Optional items:Yes,No.Press [HOME] 3s restore factory settings. Note:Restore factory settings can restore all parameter,Include IR Remote Controller address and serial address.
Maintenance and Troubleshooting Camera Maintains If camera will not be used for a long time, please turn off the power switch,disconnect AC power cord of AC adaptor to the outlet. Use soft cloth or tissue to clean the camera cover. ...
