Summary of Contents for ebpromotion mystere mws
- Page 1 Eb P R Om o t i o n , E r i c h B r ö n n i m a n n , C i t é R o b i n s o n 1 0 , 2 0 7 4 M a r i n , S w i t z e r l a n d Tel +41 (0)32 763 05 63, Fax +41 (0)32 763 05 64 http :\\:www.ebpromotion.ch, E-mail : erich@ebpromotion.ch...
-
Page 2: Dear Customer
Tests, realised with different people, have shown that the eight pages can be read before fatigue has a chance to overcome you. PROmotion, Cité Robinson10 2074 Marin, Schweiz www.ebpromotion.ch Tel +41(0)32 763 05 63 Fax +41 (0)32 763 05 64 e-mail: erich@ebpromotion... -
Page 3: Front Panel
When using a V-mount (or similar) adapter for lock-on batteries with information about remaining capacity, the mixer can use this information for its display. (e.g. IDX Endura) PROmotion, Cité Robinson10 2074 Marin, Schweiz www.ebpromotion.ch Tel +41(0)32 763 05 63 Fax +41 (0)32 763 05 64 e-mail: erich@ebpromotion... - Page 4 LED is 1 dB. The intensity of the LEDs brightness can be dimmed by setting the switch "Brightness" on the control panel. PROmotion, Cité Robinson10 2074 Marin, Schweiz www.ebpromotion.ch Tel +41(0)32 763 05 63 Fax +41 (0)32 763 05 64 e-mail: erich@ebpromotion...
- Page 5 Selector for Limiter „ON“ channel separated, „0“ off, „LINK“ channel-linked 6. MASTER LINK Switch to gang master outputs 7. BRIGHTNESS Switch to change intensity of the displays brightness. PROmotion, Cité Robinson10 2074 Marin, Schweiz www.ebpromotion.ch Tel +41(0)32 763 05 63 Fax +41 (0)32 763 05 64 e-mail: erich@ebpromotion...
-
Page 6: Input Panel
5. PHONES Headphone output (Jack ¼“) 6. DC OUT Two additional power-outlets allowing to supply external accessories. Transmitter, Receiver or else. PROmotion, Cité Robinson10 2074 Marin, Schweiz www.ebpromotion.ch Tel +41(0)32 763 05 63 Fax +41 (0)32 763 05 64 e-mail: erich@ebpromotion... - Page 7 Unbalanced low level outputs L/R on RCA connectors ; level 0 or –40 d 3. LOW / HIGH Selector for level on RCA output LOW –40dBu, HIGH 0 dBu PROmotion, Cité Robinson10 2074 Marin, Schweiz www.ebpromotion.ch Tel +41(0)32 763 05 63 Fax +41 (0)32 763 05 64 e-mail: erich@ebpromotion...
- Page 8 Allows to cascade two Mystère. The mixed signal is injected as a group into the second mixers bus. Each mixer can be designed as Master or Group mixer. PROmotion, Cité Robinson10 2074 Marin, Schweiz www.ebpromotion.ch Tel +41(0)32 763 05 63 Fax +41 (0)32 763 05 64 e-mail: erich@ebpromotion...
- Page 9 (ballistics of the display, level of the reference tone, etc). Equally all necessary test points for checking the mixer are on this board. PROmotion, Cité Robinson10 2074 Marin, Schweiz www.ebpromotion.ch Tel +41(0)32 763 05 63 Fax +41 (0)32 763 05 64 e-mail: erich@ebpromotion...
- Page 10 5. Connect the cable again, close the cover and secure it with the two screws. 6. Switch on the unit. PROmotion, Cité Robinson10 2074 Marin, Schweiz www.ebpromotion.ch Tel +41(0)32 763 05 63 Fax +41 (0)32 763 05 64 e-mail: erich@ebpromotion...
-
Page 11: Battery-Control
To be able to adapt the mixer to any battery, used by the camera definitely helps you to keep your budget. PROmotion, Cité Robinson10 2074 Marin, Schweiz www.ebpromotion.ch Tel +41(0)32 763 05 63 Fax +41 (0)32 763 05 64 e-mail: erich@ebpromotion... -
Page 12: Internal Dip Switch Configuration
-18 dB Limiter attaque time 10ms 1 = OFF 2 = OFF 3 = OFF Reference tone level -18 dB PROmotion, Cité Robinson10 2074 Marin, Schweiz www.ebpromotion.ch Tel +41(0)32 763 05 63 Fax +41 (0)32 763 05 64 e-mail: erich@ebpromotion... - Page 13 3 and 4 against the pair of 1 and 2. The 32 non utilised contacts are kept in reserved for future applications. PROmotion, Cité Robinson10 2074 Marin, Schweiz www.ebpromotion.ch Tel +41(0)32 763 05 63 Fax +41 (0)32 763 05 64 e-mail: erich@ebpromotion...
