WARNING
If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury or death.
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage. Refer to
this manual. For assistance or additional information consult
a qualified installer, service agency or the gas supplier.
Installation and service must be performed by a qualified installer,
service agency or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable, combustible or
corrosive vapors and liquids in the vicinity of this or any other
appliance. Doing so may result in an explosion or fire.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch or use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone.
• Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
• Do not return to your building until authorized by the gas supplier or
fire department.
Distributed Exclusively By
Akwakai
7683 SE 27th St., #294
Mercer Island, WA 98040
(800) 247-3619
Infinion C13
Installation and
Operation Manual
NOTICE TO INSTALLER
Affix these instructions adjacent to the Infinion
Keep these instructions for future reference. For
additional information, call 1 (800) 247-3619.
NOTICE TO OWNER
.
Advertisement
Table of Contents
Summary of Contents for Infinion C13
-
Page 1: Operation Manual
Infinion C13 Installation and Operation Manual NOTICE TO INSTALLER Affix these instructions adjacent to the Infinion NOTICE TO OWNER Keep these instructions for future reference. For additional information, call 1 (800) 247-3619. WARNING If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or death. -
Page 2: General Safety Precautions
If you have any problems understanding the instructions in this manual, STOP, and get help from a qualified installer or service technician, the gas supplier or Infinion technical support at (800) 247-3619. -
Page 3: Liquid Propane
Other conditions, such as "Odorant Fade", which causes the odorant Gas Odor to "fade", or diminish in intensity can also hide or camouflage a gas leak. Infinion C13 Installation and Operation Manual Page 3... -
Page 4: Fuel Type
Risk is highest for children and thermometer. disabled or elderly people. See Operation Manual for help on setting safe water temperature. Page 4 Infinion C13 Installation and Operation Manual... - Page 5 Temperature continued Adjust the outlet water temperature of the heater by setting the temperature dial on front of the Infinion. The illustration below shows the approximate water temperature for each position of the temperature dial.
-
Page 6: General Installation Guidelines
Do not use this appliance if any part has been underwater. Immediately call a qualified service technician to inspect the appliance and to replace any part of the control system that has been underwater. Page 6 Infinion C13 Installation and Operation Manual... - Page 7 Confirm that your Infinion is venting properly when all these other appliances are running. See section on venting. Do not obstruct the flow of combustion and ventilation air to the appliance.
- Page 8 √ 1000 Btu/hr capacity of the heater if all air is taken from inside the building (105 square inches for the Infinion C13). √ 2000 Btu/hr if all air is taken from the outside by horizontal ducts (52.5 square inches for the Infinion C13).
- Page 9 General Installation Guidelines Allow Proper Clearances The Infinion is designed for installation on a combustible wall and for installation in an alcove with the minimum clearances to combustible and non - combustible construction listed below • Top - 12 inches ( 305 mm) •...
- Page 10 • Do not grasp the sides of the heater casing when lifting the Infinion out of the box. Lift the heater by the foam end pieces. Along with the heater, the box contains the following hookup parts: •...
- Page 11 (77 for LPG and 120 for Natural Gas). Mount the Infinion to the Wall The Infinion C13 mounts on a wall. • Do not install this appliance on a carpeted wall or above floor covering which is combustible, such as carpet.
- Page 12 • Note: The burners of an instantaneous water heater such as the Infinion are only on at the time that you are using hot water. Consequently, the vent may be cold except for short durations when hot water is used, so it is very...
-
Page 13: Connect The Gas
CGA B149INSTALLATION CODES and /or local installation codes. • NOTE: The Infinion C13 comes with a gas pressure regulator that must be installed on the heater before attaching the gas supply line. See figure 4. The regulator supplied with the heater is preset for the gas shown on the rating plate to the correct pressure. - Page 14 Take these readings while the heater is operating at full input - i.e. maximum water flow with the temperature dial selector turned all the way clockwise. i t l Maximum Inlet Gas Pressures Page 14 Infinion C13 Installation and Operation Manual...
- Page 15 Installing Your Infinion Connect the Water Connect the hot and cold water lines to the Infinion using the accessory fittings as illustrated in the drawing on the next page. • Regardless of the type of water piping in your structure, use copper piping (for at least three feet before and after) to connect to the heater.
-
Page 16: Gas And Water Connections
Installing Your Infinion Gas and Water Connections Note -- Use the fiber washers as shown in the illustration. Do not use any pipe dope or teflon tape on those connections. Page 16 Infinion C13 Installation and Operation Manual... - Page 17 • The water heater is now ready to start. To start the Infinion, follow the instructions on the front cover of the heater. The instructions are also shown below. Infinion C13 Installation and Operation Manual...
- Page 18 Set the Water Temperature The Infinion has a gas control that adjusts burner input in response to flow. Its purpose is to ensure that the hot water temperature will remain steady, although the water flow demand might vary.
- Page 19 If after adjusting the outlet water temperature, the water is still too hot, you can further lower the temperature by reducing the input gas capacity of the Infinion. Turn the upper control knob clockwise to any one of the four detent positions.
