Arrow Master 6P18 Operation, Maintenance And Parts Manual

Air powered chain saw
Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

AIR POWERED CHAIN SAW
6P18 and 6P24
OPERATION, MAINTENANCE
and PARTS MANUAL
MODEL NUMBER:
SERIAL NUMBER:
SOLD & SERVICED BY:
Publication 56963
(Revised 10/00)
ARROW-MASTER, INCORPORATED
1201 Seventh Street East Moline, IL 61244

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6P18 and is the answer not in the manual?

Questions and answers

Summary of Contents for Arrow Master 6P18

  • Page 1 AIR POWERED CHAIN SAW 6P18 and 6P24 OPERATION, MAINTENANCE and PARTS MANUAL Publication 56963 (Revised 10/00) MODEL NUMBER: SERIAL NUMBER: SOLD & SERVICED BY: ARROW-MASTER, INCORPORATED 1201 Seventh Street East Moline, IL 61244...

  • Page 2: Illustrated Parts List

    A. The model number, specification number, and manual. serial numbers found on the unit nameplate. B. Quantity. C. Part name and number. (Use part numbers from the parts listings. Do Not refer to the key numbers.) AIR POWERED CHAIN SAW 6P18 and 6P24 56963 10/00...
  • Page 3 Transmission Assembly (See Figure 7-6) M48678 Model 6P18 Blade Bar Assembly (Includes Item 5) M48369 Model 6P24 Blade Bar Assembly (Includes Item 5) M48545 Sprocket Nose Assembly M48676 Model 6P18 - Chain, .404 Pitch M48677 Model 6P24 - Chain, .404 Pitch 56963 10/00...

  • Page 4: Motor Assembly

    Page 7-3 Figure 7-2 MOTOR ASSEMBLY (44745A Ref.) 56963 10/00...
  • Page 5 Page 7-4 MOTOR ASSEMBLY ITEM PART NO. DESCRIPTION 44709A Adapter 44708 Pin, Grooved 44736 Motor Housing Assembly M46704 Motor Sub-assembly (See Figure 7-3) M48453 Clutch Assembly 19064 Hose Coupling 44751 Handle Cover 77403 Insert (Part of Item 3) 45014 Gasket, Housing 45073 Gasket, Fiber 44721...
  • Page 6 Page 7-5 Figure 7-3 MOTOR SUB-ASSEMBLY (M46704 Ref.) ITEM PART NO. QTY DESCRIPTION ITEM PART NO. QTY DESCRIPTION M48462 Assembly, Front End Plate 44722 Motor Cylinder (See Figure 7-4) 44726 Back End Plate 44728 Motor Rotor 20032 Ball Bearing 44729 Rotor Blade 56963 10/00...

  • Page 7: Index Assembly

    Page 7-6 Figure 7-4 FRONT END PLATE ASSEMBLY (M48462 Ref.) ITEM PART NO. QTY DESCRIPTION ITEM PART NO. QTY DESCRIPTION 44727 Front End Plate SF5-2.5K Set Screw, 5/16"-24 x 5/16" 20032 Ball Bearing SC2-1.5 Set Screw, #8-32 x 3/16" 44866 A/R Shim, .001"...
  • Page 8 Page 7-7 (43180 Ref.)
  • Page 9 Page 7-8 TRANSMISSION ASSEMBLY ITEM PART QTY DESCRIPTION ITEM PART NO. QTY DESCRIPTION 5212 Grease Plug 40 42806A HH Cap Screw, 5/16"-24 x 2-1/4" 21994 Retainer Gasket, .003" 41 42808 Nut, Heavy; 5/16"-24 21994A Retainer Gasket, .01" 42 43101 Retaining Ring 21994B Retainer Gasket, .02"...
