  • Page 1 FS100 All-in-One System Lite / Pro User ’s Manual...
  • Page 2 Preface About this Manual Thank you for purchasing our FS100 All‐in‐One System. This terminal offers  highly enhanced features, with easy connection to various optional devices  for optimal performance. This user manual describes how to setup and  connect your terminal.     Copyright © Copyright 2006   All rights reserved. This product and related documentation are protected  by copyright and are distributed under licenses restricting their use,  copying, and distribution. No part of this documentation may be   reproduced in any form by any means without prior written authorization  of the manufacturer and its licensors, if any.     Safety notices Before You Proceed ▪  Read the safety notices and the User Manual carefully before using the   product.   ▪ Keep the box and packaging in case the product needs to be shipped in   the future.   ▪ Follow the product and warning label instructions.   ▪ Any changes or modifications that do not follow the instructions in this   manual will void this productʹs warranty.     Power Supply Safety Notes ▪ To avoid electric shocks, disconnect the power cord from the electrical   outlet before relocating the system.  ...
  • Page 3 Preface Operating Instructions ▪ Keep this manual for future reference.   ▪ Keep this equipment from moisture and dust.   ▪ Place the equipment on a stable surface before setting it up.  If there is any  ▪ If the following situation arise, notify a qualified service   technician immediately:   The power cord or plug is damaged.  Liquid has been spilt on to the equipment.  The equipment has been dropped and damaged.   The equipment does not function normally.   ▪ Do  not  block  any  ventilation  openings  to  prevent  the  equipment  from     overheat.   ▪ Do not leave the equipment in a non air‐conditioned environment     where the storage temperature may go above 60°C (140°F), as this can     cause damage to the equipment.     Maintenance ▪ Gently wipe screen with a clean soft hair lens brush, or a lint‐free cloth.  Do  not apply pressure to the screen while cleaning.  ...
  • Page 4 Preface Federal Communications (FCC Statement) This device complies with FCC Rules Part 15. Operation is subject to the  following two conditions:   ▪ This device may not cause harmful interference.  ▪ This device must accept any interference received including     interference that may cause undesirable operation.   This equipment has been tested and found to comply within the limit of a   Class A digital device, pursuant to Part 15 of the FCC Rules. These limits   are designed to provide reasonable protection against harmful interference   in a residential installation. This equipment generates, uses and can radiate   radio frequency energy and, if not installed and used in accordance with   the manufacturer’s instructions, may cause harmful interference to radio   communications. However, there is no guarantee that interference will not   occur in a particular installation. If this equipment does cause harmful   interference to radio or television reception, which can be determined by   switching the equipment on and off, the user is encouraged to try to correct   the interference by one or more of the following measures:   ▪ Reorient or relocate the interference receiving antenna.   ▪ Increase the distance of separation between the equipment and         interference receiver.   ▪ Connect  the  equipment  to  a  power  outlet  on  a  circuit  different  from         that to which the interference receiver is connected.  ...
  • Page 5: Table Of Contents

    Content Chapter 1   Welcome ...  Overview of FS100...  ...1 Rear View ...  ...2 OSD Control Buttons ...  Features ...  Unpacking ...  Chapter 2  Getting Started ...  ...6 Pre‐installation Notice...  Default Setting ...  Limitations ...  Hardware Installation ...  Installing the Adapter and Internet for Lite type ...  Installing the Adapter and Internet for Pro type...  Installing the Customer Display for Lite type ...  Installing the Customer Display for Pro type ...  ..10 Installing the 2nd display (for Pro type only)...  ..11 Installing the MSR ...  ..12 LCD Operating Angle ...  ..12 Appendix  Technical Information...  Specifications ...  ..13 Frequently Asked Questions (FAQ) ...  ...15...
  • Page 6: Welcome

    Chapter 1 Chapter 1 apter 1 Welcome Congratulations  on  your  purchase  of  this  POS  terminal.  Your  easy‐to‐use  POS  terminal is designed to help you enhance your business flexibility by offering a  superior customer experience.   Overview of FS100     Pro   Lite                   Powerful expansion capability   Counter space‐saver     Dual display for advertising    ...
  • Page 7: Rear View

        Chapter 1 — Welcome Rear View The rear panel view, with the input and output ports, is shown in the  illustration.       Upper I/O Ports (Lite/ Pro) DESCRIPTION   1   Line Out   2   LAN port   3   USB port x 2   4   COM 3   5   CF Card slot   6   VGA port (Pro only)  nd     7   K/B, M/S Combo port   8   24V DC input            ...
  • Page 8: Osd Control Buttons

    Chapter 1 — Welcome OSD Control Buttons ICON   FUNCTION   1     Press the Power button to start up the system.   Press the Power button for 4 seconds to shut down the system from  hardware.   Press  the  Power  button  and  “Brightness  +”  button  for  4‐6  seconds to reset the system from the hardware.   2   Power LED Red: Standby mode.   Green: System start up.   3   Brightness +   Press the “Brightness +” and “Brightness ‐” button to active the   adjustment mode, then press Brightness +” and “Brightness ‐”   4   Brightness ‐   button for brightness adjustment. The setting will be saved after   releasing the button for 6 seconds.   5   Speaker +   Press the “Speaker +” and “Speaker ‐” button to active the   adjustment mode, then press “Speaker +” and “Speaker ‐”   6  ...
  • Page 9: Features

    Chapter 1 — Welcome Features This POS terminal comes equipped with the following features:     ▪ Noise‐free   The fan‐less, noise free design of the FS100   is ideal for noise‐intolerant environment.     ▪ Low power   ULV (Ultra Low Voltage) design of the device is   consumption   embedded with a unique chip set and CPU renders   power saving function.     ▪ Saving cost of   Modular design provides the owner with the   ownership   following benefits: (a) cost effectiveness, (b)   customization flexibility, and (c) easy maintenance.     ▪ Compact size/   Slimmest in the POS industry standard (24 mm).   Aesthetic   This elegant, economic POS system features a sleek,   design   compact design base that saves counter space and   adds appeal to the service environment.     ▪ Dust/water  FS100 series features a highly durable,   proof   rigorously tested design that is reliable and   dependable in rugged environments.  ...
  • Page 10: Unpacking

    Chapter 1 — Welcome Unpacking Before setting up your FS100, check that the package contains the following  items.  If  any  of  the  items  are  missing  or  damaged,  contact  your  vendor  immediately.     2nd Customer Display   FS100 Touch   Customer Display   (optional)   Terminal   (optional)                         Magnetic Stripe Reader  AC Power Cord   Power Adapter  ...
  • Page 11: Getting Started

    Chapter 2 Chapter 2 Getting Started This  chapter  describes  how  to  install  the  optional  accessories  on  your  FS100  Touch Terminal for optimal serviceability.   Pre-installation Notice Before  you  start  installing  your  FS100,  please  read  the  following  notices  carefully.   1. The FS100 does not support PCI slot.   2.  Do  not  plug  in  or  unplug  any  interior  devices,  such  as  memory  module  or    ...
  • Page 12: Limitations

    Chapter 2 — Getting Started Preset voltage setting for MSR   1.  The  MSR  default  setting  is  ISO  Track  1  &  2.  (For  customized  track  settings,     advise the manufacturer before production.)   2.  In  event  of  any  requirement  to  change  the  setting  of  the  MSR,  run  Setting     utility in the driver CD provided in the accessory package.   3. ...
  • Page 13: Hardware Installation

    Chapter 2 — Getting Started Hardware Installation Installing the Adapter and Internet for Lite type To install the adapter and Internet cable for Lite type, do the following:   1.  Connect  the  Internet  RJ  45  cable  and  the  power  cable  to  the  connectors  and     arrange the cables in the clamps as shown.                  ...
  • Page 14: Installing The Adapter And Internet For Pro Type

    Chapter 2 — Getting Started Installing the Adapter and Internet for Pro type To install the adapter and Internet cable for Pro type, do the following:   1. Take out the cable clamps from the accessory package and attach them to     the position as shown. Connect the Internet RJ 45 cable and the power     cable to the connectors and arrange the cables in the clamps.                     RJ 45 Power adapter connector connector Cable clamp 2.  Replace  the  extension  base  cover  with  two  M3  screws  and  then  affix  the    ...
  • Page 15: Installing The Customer Display For Lite Type

    Chapter 2 — Getting Started Installing the Customer Display for Lite type Follow the procedures below to install the Customer Display.   1.  Connect  the  VFD  DB  9  cable  to  the  connector     as shown.   2.  Replace  the  base  cover  and  affix  it  with  two     M3 screws.   3.  Attach  the  Customer  Display  to  the  base  of  the    ...
  • Page 16: Installing The 2Nd Display (For Pro Type Only)

    Chapter 2 — Getting Started Installing the 2nd display (for Pro type only)   To install the 2  display onto the FS100 Terminal, do the following:   1.  Connect  the  DB  15  cable  to  the  connector  on  the  back  of  the  FS100     Terminal LCD screen and arrange the cable in the clamp as shown.               DB 15 connector Cable clamp 2. ...
  • Page 17: Installing The Msr

    Chapter 2 — Getting Started 4. Install the 2  Display and lock it to the stand with four M3 screws.                     Installing the MSR To install the MSR onto the LCD display, do the following:   1.  Attach  the  MSR  device  jack  to  the  MSR  socket  on  the  side  of  the  LCD     display.   2.  Affix  the  upper  and  lower  MSR  wires  firmly  to  the  slots  on  the  side  of    ...
  • Page 18: Appendix

    Appendix Appendix Technical Information Specifications ITEM   SPECIFICATION   Model Name        FS100 All in One Touch POS System   Processor   Supports VIA Eden CPU up to 1.0 GHz    Memory   200‐pin DDR RAM *1, up to 2GB (DDR333/400)   System Core   North Bridge: VIA CN‐700   Chipset   South Bridge: VIA 8237R+   BIOS   Award BIOS with enhanced ACPI 1.0   PnP/APM/DMI/ESCD/PCI bus 2.1/ On Now/ DRAM ECC   AGP 3D   VIA AGP4X graphics core, share memory from 8MB up to   Graphics   64 MB   Dual  VGA  output  (Dual‐view  on  North  Bridge  Chips)  Supports 3D/2D graphics accelerator   NT  4.0/5.0,  Windows  95/98/2000/XP  utility  APM/ACPI 1.0   Direct 9.0, VPE, MPEG2   Parallel Port   One LPT port (SPP/EPP/ECP), IRQ and address selectable  ...
  • Page 19 Appendix — Technical Information ITEM   SPECIFICATION   Serial ATA   One Serial ATA HDD ports   Port   Thermal   One heat‐sink for CPU heat pipe and North Bridge Chip   Solution   Compact Flash   One bootable compact flash card socket (Type I/II)   Card   Cash Drawer   One cash drawer port with status sensor. (EPSON ESC Pin   Port   define)   System Power   DC 24V/ 5A /120W external power adapter with internal DC   to DC power inverter.   AC 90 to 264V Full Range.   AC Power   Source   System Trigger   System front side tact switch (ATX Trigger) below the LCD   Control   display with bottom.   Ethernet Port   Realtek RTL8100C Ethernet chip on board   (10/100 Mbps   Intel Ethernet chips on board (10/100 base‐ T, Gigabyte   Auto)   extendible)   ACPI/NT 4.0/5.0 (NDIS5)   Remote boot ROM for NT 4.0   Enable or disable by BIOS setup   Audio   VIA VT 1612A AC97 CODEC on board   Keyboard  ...
  • Page 20: Frequently Asked Questions (Faq)

        Appendix — Technical Information ITEM   SPECIFICATION   Smart Card Reader   20  column  *  2  lines  VFD  Customer  Display  Optical Finger Print Sensor   10.4” or 12.1” LCD Customer Display 32  Keys Programmable POS Keyboard       Note: Specifications are subject to change without notice. Frequently Asked Questions (FAQ) Question 1: Why does the system appear unstable after updating BIOS?   Answer:  Load  optimized  defaults  (or  load  SETUP  Default)  after  flashing    ...
