Summary of Contents for Peachtree Audio iNova
-
Page 2: Important Safety Instructions
Important Safety Instructions Read these instructions – All the safety and operating instructions should be read before this product is operated. S a f e t y Keep these instructions – The safety and operating G u i d e l i n e s instructions should be retained for future reference. - Page 3 Introduction Front Panel Back Panel Connections Remote Control Advice for iPod Useful Tips and more... Troubleshooting Product Guarantee and Service Compatibility for iPod Technical SpeciÀcations...
- Page 4 ESS Sabre³² DAC. This high-performance digital to analog converter lies at the heart of the iNova. And it’s why you’re going to love what you hear when you connect your computer’s music library to an iNova digital input.
- Page 5 Input for iPod: Push to hear the digital signal from an iPod connected to the iPod dock on top of the iNova. Standby: The iNova is in standby mode when this button glows red. Push to turn on the iNova; the button will light up blue. When you are Ànished listening, push again to return to standby mode.
- Page 6 AC Power Cord Attachment and Fuse: The three-prong power cord is included with the iNova. The fuse is user replaceable after turning the iNova off. You may call your dealer or Peachtree Audio’s service department with questions regarding fuse replacement. WARNING: Using the wrong value fuse may damage the iNova and is a potential Àre hazard.
- Page 7 Be sure the iNova and the external ampliÀer are both turned off. Connect a stereo RCA cable from the iNova “Pre Out” jacks to the stereo RCA inputs of the external ampliÀer; connect your speaker wires to the speaker terminals of the external ampliÀer.
- Page 8 POWER: Put the iNova in or out of “Standby”. MUTE: Mute or unmute the iNova. R e m o t e Buttons 3-8 are for control of your iPod docked in the iNova C o n t r o l MENU: Press to access the menu of the iPod.
-
Page 9: Supported Ipod Models
It should click in to place over the multi-pin connector. You can remove the inserts by applying gentle pressure to the inside back of the insert and pushing upward. - Page 10 Launch iTunes and enjoy your music. Once you set up your computer following the above instructions it should recognize the iNova’s USB Audio DAC and default to it. If you unplug the USB connection you may have to repeat some steps; this is not unusual.
- Page 11 Interested in the Green Movement? The iNova meets the European RoHS standards for non-hazardous metals. The iNova utilizes a standby transformer that draws less than one watt of power. We will continue to investigate more ways of making our products environmentally...
- Page 12 This can require some trial and error diagnostics. If you have music Àles available on a laptop computer connect it (while on battery power) to the iNova and a pair of speakers. If it works properly, with no noise, then the You pick up hum and noise through your iNova computer in your ofÀce is introducing a ground loop into...
-
Page 13: Claims Under Warranty
Please insure the unit against loss or damage while in transit. In the unlikely event that you experience a failure with your iNova, please call for a return authorization number before returning products for service. Any iNova received without an RA # will be refused. - Page 14 Compatibility for iPod To provide you with extraordinary sound the iNova takes the digital signal directly from your iPod and routes it to the iNova’s built-in high-performance digital to analog converter. The table below shows the iPods that are compatible with the iNova.
- Page 15 AmpliÀer Technical ST MOSFET amp modules 80 watts per channel at less than .1% distortion into 6 ohms Specifications Sigma Servo internal wiring conÀguration for better damping PreampliÀer Hybrid tube design (6N1P) 7.0V output @ 2.0V input <1 ohm at output stage Class A output stage Polypropylene caps in the signal path Headphone Amp...
- Page 16 Made For: iPod touch (1st and 2nd generation) iPod classic (80G, 120G, 160G only) iPod nano (2nd, 3rd, 4th, and 5th generation) “Made for iPod” means that an electronic accessory has been designed to connect speciÀcally to iPod and has been certiÀed by the developer to meet Apple performance standards.
