- Page 1 SmartLine SL 120-12 Inverter / Voltage transformer Power Inverter User manual User Manual Please rear this User Manual before taking the Voltage Transformer into operation! SL120.02_GB...
-
Page 2: Table Of Contents
Contents Overall view ..................Important safety instructions ............Area of operation ................. Cable ................... Care and maintenance..............Children ..................Intended use ................Technical specifications ............. Introduction ..................Important instruction for use ............Connecting the inverter ..............Connecting to a vehicle socket ........... Disconnecting ................ -
Page 3: Overall View
USB - port, 5 V 500 mA (hidden in the image) Range of use The Inverter SL 120-12 can be used to provide 230 V AC for laptops, radios, MP3 - players, cell phone charger etc. by means of 12 V DC (e.g. car battery). -
Page 4: Cable
Important instructions and area of operation Before the initial use of the device please thoroughly read the following instructions and comply with all warnings, even if you are accustomed to being around electronic devices. Keep this handbook safe for future reference. Should you sell the device or pass on to someone else, these instructions should also be passed along. -
Page 5: Care And Maintenance
Federal Republic of Germany the relevant laws and standards of the country in which it is used have to be observed. Any other use is considered to be improper use and is therefore forbidden. Technical specifications SL 120-12 Input voltage 12 V (DC) Output voltage... -
Page 6: Introduction
The SL 120-12 has a cable with a plug for the cigarette lighter that allows you to connect the device to the car on-board socket (12 V). -
Page 7: Connecting The Inverter
Observe the information for the continuous output power and the peak performance. Devices that have a power consumption of more than 120 W are not allowed to be used with this inverter. The higher peak power output is only for supplying the momentary inrush current when a device is switched-on. -
Page 8: Disconnecting
Note: If the voltage supply to the inverter is interrupted during operation it automatically switches off. This means that once the voltage is reapplied the inverter needs to be switched-on again according to point 5. Disconnecting Switch-off the consumer and remove the power plug from the power socket (2) of the inverter. -
Page 9: Disposal Of Old And Defective Devices
The over temperature protection is active and the device has switched itself off (error indicator (4) is illuminated). To reactivate the device first switch-off at the power switch (3) and allow it to cool. Undervoltage The voltage of the car battery is too low. Recharge the car battery. With an undervoltage the error indicator (4) first illuminates as soon as the device has switched itself off completely.
