- Page 2 ADSL2+ Router...
-
Page 3: System Requirement
ComTW263R4 ADSL2+ Router ADSL2+ Router System Requirement Pentium 200 MHz processor or above Windows 98SE, Windows Me, Windows 2000, Windows XP and Windows Vista. 64 MB of RAM or above 25 MB free disk space Package Contents For Annex-A ADSL2+ Router ADSL2+ Router CD-ROM (Software &... -
Page 4: Installation And Setup
ADSL2+ Router Installation & Setup ●LAN Connection: Connect an Ethernet cable from your PC's Ethernet port to ADSL2+ Router's LAN Port. ●WAN Connection: Connect the telephone cable from your home's telephone jack to the telephone port (LINE) of the ADSL2+ Router, if there is no Splitter applied. ●Power Adapter Connection: Connect the power adapter to the power inlet (PWR) of the ADSL2+ Router and turn the power switch (SW) on. -
Page 5: Connection Of Adsl2+ Router
ComTW263R4 ADSL2+ Router Connection of ADSL2+ Router If you have an ISDN telephone line connected the router as shown below: (Annex-B ADSL2+ Router) **Use the “ATF057” Annex-B Splitter (Optional) Connect the supplied RJ45 Ethernet cable from your PC's Ethernet port to the ADSL2+ Router's “LAN” Port. Connect the supplied RJ11 telephone cable from your home's telephone jack to the “LINE”... - Page 6 ADSL2+ Router If you have a PSTN telephone line (normal analog line) connected the router as shown below: (Annex-A ADSL2+ Router) **Use the “ATF085A1R” Annex-A Splitter (Optional) Connect the supplied RJ45 Ethernet cable from your PC's Ethernet port to ADSL2+ Router's “LAN” Port. Connect the supplied RJ11 telephone cable from your home's telephone jack to the “LINE”...
-
Page 7: Led Meaning
ComTW263R4 ADSL2+ Router LED Meaning Your ADSL2+ Router has indicator lights on the front side. Please see below for an explanation of the function of each indicator light. 1 Ethernet Port model ● Power : Power indicator ● ADSL ACT : ADSL Active indicator ●... - Page 8 ADSL2+ Router 4 Ethernet Ports model: ● Power : Power indicator ● ADSL ACT : ADSL Active indicator ● ADSL LINK : ADSL Link indicator ● LAN 1~4 : Ethernet 10/100M speed active indicator Label Color Flash Yellow Power On Power Off Green ADSL Active...
-
Page 9: Configuration Procedures
ComTW263R4 ADSL2+ Router Configuration Procedures Before starting the ADSL2+ Router configuration, please kindly configure the PC computer as below, to have automatic IP address / DNS Server. For Windows 98SE/ME/2000/XP Click on "Start” -> “Control Panel” (in Classic View).In the Control Panel, double click on "Network Connections"... - Page 10 ADSL2+ Router Double click on "Internet Protocol (TCP/IP)". Check "Obtain an IP address automatically” and “Obtain DNS server address automatically” then click on "OK" to continue. Click "Show icon in notification area when connected" (see screen image in 3. above) then Click on "OK" to complete the setup procedures.
- Page 11 ComTW263R4 ADSL2+ Router For Windows Vista-32/64 1. Click on "Start” -> “Control Panel” (in Classic View) -> “Network and Sharing Center”. In the Manage network connections, double click on "Manage network connections" to continue. 2. Single right click on “Local Area connection", then click "Properties". 3.
- Page 12 ADSL2+ Router Double click on "Internet Protocol Version 4(TCP/IPv4)" Check "Obtain an IP address automatically" and “Obtain DNS server address automatically” then click on "OK" to continue. Click "Show icon in notification area when connected" (see screen image in 4. above), then Click on "OK" to complete the setup procedures.
- Page 13 ComTW263R4 ADSL2+ Router ADSL2+ Router Configuration via Ethernet Port Please insert the supplied CD into your CD-ROM drive. The CD should auto-start, displaying the window shown in 3. below. If your CD does not start automatically go to Windows Explorer, Select your CD drive and double click “setup.exe”...
- Page 14 ADSL2+ Router...
- Page 15 ComTW263R4 ADSL2+ Router...
- Page 16 7435-0B72-00...
