- Page 1 MANUAL Thru 3x8 ™ 3 I N 8 O U T M I D I THRU BOX...
- Page 2 (In C) is on the back panel. All 8 of the outputs are on the back panel. Each of the Thru 3x8’s 8 outputs can be individually connected to any one of the three inputs using the 8, three position dip switches on the front panel.
- Page 3 Also, any MIDI signals received at any of the Thru 3x8’s MIDI ins are simultaneously sent out all of selected MIDI outs. So the Thru 3x8 can be used to eliminate any “MIDI delay” you may be experiencing because of daisy chaining several MIDI devices together.
- Page 4 . I f everything is done correctly, the power LED over the power switch will light. If you have any questions about your Thru 3x8 please contact our tech support in any of the following ways: voice: (626) 445-8495 email: techsupt@midiman.net...
