IMS motorcom MIT-30 User Manual

Thank you for buying our Motorcycle Intercom System with hands free feature (MIT 30)

1.Correct Using

MIT-30 is designed for mobile communication for
motorcyclists.
Using the MIT-30 in other ways than described is
not allowed.

2.Security Information

IMPORTANT ! PLEASE READ !
Any damage resulting out of using this unit
in another way than described in this users
manual will lead into lost of warranty. We are
not responsible for any damage resulting
out of wrong using of this unit.
Attention! The Multi-Function-Box as well as all connected cables needs to be installed
in that way, that they do not hinder the drivers safety.
Do not pull the cables of the Multi-Function-Box as it can lead into malfunction of the
unit or the water resistance might be damaged.

3.Delivered With

1 pc Multi-Function-Box with cables and 12 V power cable with standard power plug
2 pcs Helmet Speaker Set with extension cable
2 pcs. Ear pads for helmet speaker set
1 pc Audio Connection cable with 3,5 mm angle-entry-plug on 3,5 mm plug (straight)
1 pc Telephone connection cable with 2,5 mm angle-entry-plug on 3,5 mm connection

4. Note for Installation

To activate the unit, please use the 12 V jack of your motorbike
NOTE: Please first follow all below described steps before you connect the unit to
the 12 V jack !

4.1. Connections:

4.1.1. Connection to the Telephone

Connect the 3,5 mm connection with the 3,5 mm plug of the Multi-Function-Box
(referring marked cable).
Next connect the 2,5 mm angle-entry-plug of the telephone connection cable either
direct with your cellular phone or in an optional available cellular phone headset adapter.
According to legislation it is not allowed to do outgoing calls while driving!
Users Manual
MIT- 30
