230v AC - 50Hz
15W
High Speed/Single Speed
35W
Low Speed
25W
IPX4 Rating – This product is double insulated.
Manufactured in the UK by
Polypipe
Sandall Stones Road, Kirk Sandall Industrial Estate, Kirk Sandall, Doncaster DN3 1QR
Tel: +44 (0) 8443 715523 Fax: +44 (0) 8443 715524
www.polypipe.com/ventilation
Installation Instructions
Window / Wall Fans
www.polypipe.com
ISSUE 1
08/11 LAB739R
SVC6
Polypipe
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for silavent SVC6
Summary of Contents for silavent SVC6
-
Page 1: Installation Instructions
Installation Instructions 230v AC - 50Hz High Speed/Single Speed Low Speed SVC6 IPX4 Rating – This product is double insulated. Window / Wall Fans Manufactured in the UK by Polypipe Polypipe Sandall Stones Road, Kirk Sandall Industrial Estate, Kirk Sandall, Doncaster DN3 1QR www.polypipe.com... - Page 2 They may be used in other applications where a high level of ventilation is required. The SVC6 is designed primarily as a window fan but it can also be installed on a wall or a ceiling but should not be ducted over 2 metres. When fixing through the wall a wall fitting kit SVC901W is required.
-
Page 3: Operation
OPERATION A GUIDE TO VENTILATION All models are fitted with high technology thermo actuated shutters which operate WHERE TO SITE YOUR FAN automatically. Allow up to 1 minute for shutters to open and up to 4 minutes to close. Incorrect siting of an extractor fan can DO NOT FORCE SHUTTERS severely impair its efficiency. -
Page 4: Assembly And Fitting
ASSEMBLY AND FITTING MODELS : SVC150B with SPEED CONTROLLER ANC841A OF SVC6 (see CAUTION and WARNING on page 9) SLOW SPEED SPEED CONTROLLER ADJUSTMENT ISOLATOR SWTCH Speed Control Terminals Fan Terminals 1 - Fan Line N - Neutral 2 - Live In... - Page 5 WIRING INSTALLATION WINDOW FITTING WARNING : Isolate from Power Supply before commencing work WIRING REQUIREMENTS FOR DOMESTIC ELECTRIC FANS It is recommended that fans be connected into the lighting circuit, with double pole (3mm) isolation provided before the room light switch and suitably fused, in accordance with IEE Regulations.
-
Page 6: Surface Mounting
We recommend the use of this fixing kit as it contains all the necessary parts to surface mount or flush fit the SVC6 fan unit. Cut hole through wall in desired position. On the outside allow clearance for the 150mm...
