Index 1 Package..............................5 1.1 Box..............................5 1.2 Complete package contents......................5 1.3 Modem version...........................6 2 General presentation..........................7 2.1 Front panel..........................7 2.2 Back panel...........................7 2.3 External connections........................8 2.3.1 Interfaces and connectors.....................8 2.3.1.1 GSM antenna connector....................8 2.3.1.2 Modem serial port, either full RS232/RS485..............8 2.3.1.3 RJ-45 connector ......................8 2.3.1.4 Power supply connector....................9 2.3.1.5 Audio I/O........................9 2.3.1.6 20-pin connector......................9... - Page 3 4.2.9 Static routes........................24 4.2.10 Dynamic DNS........................25 4.2.11 Access control........................26 4.2.12 Open VPN........................28 4.2.13 Ipsec static/Ipsec mobile....................30 4.2.14 Generating SSL certificates....................33 4.2.15 N2N..........................35 4.2.16 CARP..........................36 4.2.17 NTRIP configuration page....................37 4.2.18 SMS Actions........................38 4.2.19 GPIO..........................39 4.2.20 CAN..........................41 4.2.21 Time..........................42 4.2.22 Syslog..........................43 4.2.23 User files..........................44 4.2.24 Backup and restore......................45 4.2.25 Discard changes.......................45 4.2.26 Save settings ........................45...
- Page 4 7 Terminal architecture........................55 8 Safety recommendations.........................56 8.1 General Safety...........................56 8.2 Care and Maintenance ......................56 8.3 Responsibility ..........................56 9 Accessories............................57 9.1 Accessories critical for using modem..................57 9.2 Additional accessories.......................57 9.2.1 Directional antennas ......................57 9.2.2 Omnidirectional antennas....................60 9.2.3 Powr cable – open end......................61 9.2.4 IO cable..........................61 9.2.5 RS232/486 cable.......................62 9.2.6 DIN rail holder........................62...
-
Page 5: Package
We can find product sticker on the box. It matches modems sticker that is placed on the device. This proves that your modem is original product. More information about stickers in chapter Product sticker. 1.2 Complete package contents Complete package contains: A) RB-MTX modem B) Antenna GSM (via SMA) C) Power supply adapter... -
Page 6: Modem Version
1.3 Modem version There are many ways to upgrade your RB-MTX modem. List below shows typical configuration and different combinations (versions) of this terminal. Option Typical Option Power supply 6…30V LPC3130, ARM9 180MHz LPC3141, ARM9 270MHz 32MB RAM, 256MB MicroSD card... -
Page 7: General Presentation
2 General presentation 2.1 Front panel 2.2 Back panel... -
Page 8: External Connections
RS485 device option). The build-in terminator assumes 120Ω line impedance. 2.3.1.3 RJ-45 connector RJ-45 connector is placed on front panel of RB-MTX modem and used for communication with PC or laptop to plug cable for Ethernet. In order to start configuration pages of modem plug UTP cable between RJ-45 of modem and RJ-45 of your computer. -
Page 9: Power Supply Connector
2.3.1.4 Power supply connector In the RB-MTX modem power supply 6V..30V care must be taken to ensure “clean” power supply input and especially to avoid short transients on power supply lines originating from inductive load switching. Otherwise internal module (G24, H24 or HE910) may be permanently damaged. -
Page 10: Sim Card Holders
2.3.2 SIM card holders SIM card holders are placed in front panel of RB-MTX. To insert SIM card into the extractable holder push yellow button and take holder out. Place SIM card as show in the picture. To operate the module in a GSM network, it is necessary to insert at least one SIM card obtained from the network operator. -
Page 11: Basic Features And Services
3 Basic features and services Basic features and available services are contained in table below. Feature/service Description Standard Supported bands: Quad band 850/900/1800/1900/2100 MHz 800/1800/2600 MHz in LTE variant E-GSM compliant TX power: 850/900 MHz Class 4 (2W) ... -
Page 12: Using The Modem
4 Using the modem 4.1 Setting up the modem To set the modem, do the following steps: 4.1.1 Inserting SIM card(s) Push yellow button place on front panel and take SIM holder drawer out. Place SIM card(s) in the holder(s) as shown in the picture: *modems are available with one or two SIM cards 4.1.2 Connecting antenna ... -
Page 13: Connecting Power Supply Cable
4.1.3 Connecting power supply cable Connect power supply cable into power supply connector 4.1.4 Connecting UTP cable with RJ-45 Plug UTP or similar cable to RJ-45 plug. -
Page 14: Modem Configuration
4.2 Modem configuration Modem is configured via web browser making it portable and easy to use. Modem configuration is described below in following sections. Modem settings are divided into sections which allows user to easily find option needed. When switching tabs settings are automatically saved in modem cache, to save settings permanently and apply them click Save Settings in menu. -
Page 15: Local Network
4.2.3 Local network On LAN configuration page you can find essential parameters needed for LAN connection. Here you can set IP Address (or set it to be downloaded via DHCP), mask, default gateway, DNS addresses. Last two options can be entered manually or downloaded automatically via GSM or DHCP. -
Page 16: Gsm Network
4.2.4 GSM network On ISP Master page you can define internet connection parameters (APN, username, password, CSD, ISP IP and Modem band) for one or two SIM cards (depending on modem version). To use internet you should know those parameters - they are essential for getting access to internet. -
Page 17: Connection Control
4.2.5 Connection control Here you can set parameters of switching between two SIM cards. You can define time for ping and ping counter for 4 IP addresses you choose. In example (picture) here after 3 pings that take 10 seconds each card will change from Master to Slave or opposite. -
Page 18: Ports Configuration
4.2.6 Ports configuration You are able to set port settings under RS232 Port page. There are 3 configurable ports: /dev/ttyS0, /dev/ttyACM0 and /dev/ttyS1 or /dev/ttyUSB0 (depending on modem version). Every port can be set to different mode. On /dev/ttyS0 you can set terminal, ModBus gateway or NTRIP mode. -
Page 19: Vlan
port, choose protocol (TCP or UDP) and enter IP address. When adding new rule or switching tab, currently edited rule is automatically saved. You can delete it (or any other rule) by pressing Delete button. After changes click Save Settings to save whole configuration. You can edit port range rules in the same way in Port range rules section. -
Page 20: Static Routes
VLAN. 4.2.9 Static routes Under static routes tab you can define your own routings. Please click Add new button to add new routing. Enter identifier (used only to distinguish routings in www configuration), choose interface, enter destination network, netmask and gateway. -
Page 21: Dynamic Dns
4.2.10 Dynamic DNS Dynamic DNS is a service which allows user to make your device available under specific www address regardless of its IP changes. In order to do that you must create an account on one of web pages that are supported by MTX modem (currently DynDNS.org or No-IP.com). -
Page 22: Access Control
4.2.11 Access control First section of Access Control tab allows you to configure SSH protocol. You can turn it on or off, set on which port and interfaces (also OpenVPN and IPsec tunnels) it should be accessible. You can also toggle logging via SSH as root and change/delete passwords/keys for root and service user. - Page 23 tabs then. After the generation the message will be displayed. Public key will be automatically pasted into the keys field (if the field wasn't empty before pressing the button, its contents will be saved, the newly generated key will appear first on the list). From now you will be able to download private and public keys by pressing Get private key and Get public key buttons.
-
Page 24: Open Vpn
4.2.12 Open VPN You can connect your modem to a VPN network or create your own one using OpenVPN software. It is possible to create up to four VPN connections (tunnels). To view and change settings of any of tunnels select it from Tunnel configuration list under OpenVPN tab. Then choose if modem should be server or client and connection type: tun or tap. -
Page 26: Ipsec Static/Ipsec Mobile
4.2.13 Ipsec static/Ipsec mobile IPsec is group of internet protocols that enables user to create safe connection between devices. To configure such connection on MTX modem you need to go through three tabs of configuration: Tunnels, Mobile Clients, Keys and Certificates. First of all, you need to enable IPsec under Tunnels tab. - Page 27 In the second phase of proposal please specify the protocol (ESP is authentication with encryption, AH is authentication only), encryption algorithm, hash algorithm and PFS key group. Please note that you can choose multiple algorithms, but at least one should match on both sides of the connection.
-
Page 28: Generating Ssl Certificates
It is possible to create IPsec connection with non-static-IP-devices. In order to do this please click Mobile clients tab. Configuration is similar to the tunnel configuration, but there are less settings (for example there is no PSK field-you should add pre-shared keys for mobile clients in Keys and Certificates tab). - Page 29 At first we need to create folder, in which all our keys and certificates will be stored. Let's say it will be ~/keys. We create two files in it: list of certificates and file enumerating them: touch index.txt echo 00 > serial and subdirectories, where the certificates and keys will be stored: mkdir private certs newcerts crl In order to create certificates, the certificate authority (CA) is needed .
-
Page 30: N2N
4.2.15 N2N N2N is application that enables user to create secure subnetworks like OpenVPN and IPsec, but it is based on P2P connections. User can configure modem to host N2N server (just enable the option and choose port on which it will be available) and up to four tunnels. To configure tunnel choose N2N IP address, local and remote port, netmask and remote IP address. -
Page 31: Carp
4.2.16 CARP CARP is a network protocol that allows many devices to be connected into redundancy group which will be available as one device on chosen network address. For example you can choose devices that have IPs 192.168.1.2 and 192.168.1.3 to be available on 192.168.1.115. If one device will stop working, the other one will serve users at shared address. -
Page 32: Ntrip Configuration Page
4.2.17 NTRIP configuration page One of /dev/ttyS0 port modes is communication with external device using NTRIP protocol. If you decide to use it, it is necessary to set the mode under RS232 Port configuration page. Then, enter settings in NTRIP page. Server address, port and initial position fields are necessary. -
Page 33: Sms Actions
4.2.18 SMS Actions SMS Actions tab allows user to define shell scripts that will be executed every time modem receives SMS with specified content. To enable this option ensure that global SMS Actions checkbox is enabled and you have set one of available ports into SMS receiving mode under Ports configuration tab. Then click New button, enter any identifier and command-sms content that will trigger action. -
Page 34: Gpio
4.2.19 GPIO Settings under GPIO tab in www configuration enable user to configure external input and output GPIO ports. When switching tab to GPIO current pin states is read automatically into eight fields in upper section of the webpage. In whole configuration the following convention is used: the unchecked field represents low state and checked field represents high state. - Page 35 event. Make sure that real time clock is set correctly on the device. In case of regular event specify time interval between two [consecutive] event executions. Finally choose pin or pins used for the event and what action should be taken (setting high state, setting low state or switching states).
- Page 36 Sets low state on physical outputs number 11 and 12 (On successful execution no text is printed): 192.168.1.234/actions/gpio_action.php?cmd=write&pins=11,12&state=L...
-
Page 37: Can
4.2.20 CAN If you have modem with CAN interface you can configure it under CAN tab. You can set the baudrate and set forwarding CAN frames to TCP using slcanpty or socketcand. 4.2.21 Time Here you can manually set hardware clock or input IP of NTP server to synchronize time automatically... -
Page 38: Syslog
4.2.22 Syslog Here you can define how modem should save your logs. Modem has internal memory that get overwritten when it reaches its end. You can also save logs on your computer by clicking download (manually). It is also possible to get remote access to logs by enabling Remote service and setting SYSLOG host. -
Page 39: User Files
4.2.23 User files You can upload to the modem your own scripts and executable files and set them to be used in certain situations (e.x. when the VPN connection is established or at modem startup). Under User files tab there is a list of user files. It is refreshed automatically after selecting tab, it can be also manually refreshed by pressing Refresh button. -
Page 40: Backup And Restore
time you click Save Configuration button in www configuration. You can write your scripts in Bash or PHP, but remember to use special header for scripts ((#!/bin/bash lub #!/usr/bin/php). You can execute uploaded user files, they are stored in /root/userfiles. WARNING: Binary files uploaded to modem should be compiled for processor installed in modem! 4.2.24 Backup and restore... -
Page 41: Discard Changes
4.2.25 Discard changes Discard current changes in configuration which were not saved yet. 4.2.26 Save settings To save your settings click save setting and wait until message will show up to confirm your configuration data was saved. 4.3 System logs description This paragraph shows structure of typical System log with some basic errors: 01/01/0000:00:30 rbmtx syslogd 1.4.1: restart. - Page 42 01/01/0000:01:13 rbmtx supervisor[560]: Entering PIN OK – modem is ready for connection 01/01/0000:01:13 rbmtx supervisor[560]: Entering PIN error code: - wrong PIN message 01/01/0000:01:14 rbmtx login[811]: unable to change tty `/dev/ttyS0' for user `root' 01/01/0000:01:14 rbmtx login[811]: ROOT LOGIN on `ttyS0' 01/01/0000:01:20 rbmtx pppd[901]: pppd 2.4.5 started by root, uid 0 –...
-
Page 43: Firmware Update
4.4 Firmware update This chapter describes in few steps how to make upgrade of your modems firmware. Actual number of your modems firmware can be found here: http://x.x.x.x/firmware.php where x.x.x.x is ip adres of your modem (by default it is 192.168.1.234). You need following files for upgrade and test your upgrade: ●... -
Page 44: Elproma Device Manager
4.5 Elproma Device Manager Elproma Device Manager is an application which allows you to find RB MTX modems in local area network (LAN) and then restore factory settings by entering their IMEI number. It is particularly useful when you forgot IP number of device and you can't access it by terminal on serial port. - Page 45 When the scan is complete you can see list of available devices in the table. You can review information like IP address, MAC address, device name, firmware version and uptime. If you want to restore factory settings on any device on the list, click the Reset button and enter IMEI.
-
Page 46: Troubleshooting
5 Troubleshooting 5.1 No communication with the modem If there is no communication with the modem do the following steps: Check all external connections of the modem Verify if power supply is correct Check if TCP/IP parameters are correct ... -
Page 47: Technical Characteristics
6 Technical characteristics 6.1 Mechanical characteristic Max. dimensions 70 x 59,9 x 30,9 mm (w/o connectors) 80 x 59,9 x 30,9 mm (w/ connectors) Weight ≈138,3 g (only modem w/o any external connection) ≈145,7g (modem w/ antenna) Volume ≈129,56 cm3 (w/o connectors) 6.2 Housing (dimension diagram) -
Page 48: Electrical Characteristic
6.3 Electrical characteristic 6.3.1 Power supply Nominal voltage range: 6V..30V Maximum continuous (average, depends on supply voltage) supply current: +800 mA max Peak (momentary) supply current: 2 A 6.3.2 RF characteristics 6.3.2.1 Frequency ranges Range depends on the module that is used in your version of device and type of network you choose to use. -
Page 49: Rf Performance
6.3.2.2 RF performance Minimum radiated RF performance is shown in the table below: Band 850/900 1800/1900 GSM/GPRS TRP [dBm] 24,5 TIS [dBm] -101,5 EGPRS TRP [dBm] 20,5 19,5 TIS [dBm] -92,5 -93,5 6.3.2.3 External antenna The external antenna is connected to the modem via SMA connector. Antenna must have parameters as shown below in table. -
Page 50: Terminal Architecture
7 Terminal architecture Diagram below shows simplified architecture of RB-MTX. Features marked with dotted lines are available as option. -
Page 51: Safety Recommendations
8.2 Care and Maintenance The RB-MTX terminal is a electronic product that should be treated with care. Please follow suggestions shown below due to using modem for many years. Do not expose terminal to any extreme circumstances like high temperature or high humidity ... -
Page 52: Accessories
9 Accessories The tables below shows recommended accessories for RB-MTX terminal. 9.1 Accessories critical for using modem Table below shows accessories critical for using modem. Without them usage of modem is impossible. Accessory Description Part no. Power adaptor 6V … 30V... - Page 53 AK 5GSM/X Directional antenna AK 7/DCS-UMTS/10 Directional antenna It is possible that there is no signal in buildings the antenna in that cases can be mounted on the roof or in a room where signal is sufficient. The antenna can be mounted on an aerial mast (as shown in pictures below) or in other ways.
- Page 54 FME – SMA converter FMA connector male...
-
Page 55: Omnidirectional Antennas
9.2.2 Omnidirectional antennas In case of weak coverage you can also use omnidirectional antennas. The signal gain of omnidirectional antenna is lower than directional antenna. Still, in most cases this is enough to get proper reception. You can use magnetic base or wall handle antennas, they differ in way of mounting –... -
Page 56: Io Cable
9.2.4 IO cable 9.2.5 RS232/486 cable... -
Page 57: Din Rail Holder
9.2.6 DIN rail holder 9.2.7 Bur holder... -
Page 58: Conformity Assessment Issues
10Conformity Assessment Issues The Telit GT864-3Ghas been assessed in order to satisfy the essential requirements of the R&TTE Directive 1999/05/EC (Radio Equipment & Telecommunications Terminal Equipments) to demonstrate the conformity against the harmonised standards with the final involvement of a Notified Body. -
Page 59: Safety Recommendations
11Safety Recommendations READ CAREFULLY Be sure the use of this product is allowed in the country and in the environment required. The use of this product may be dangerous and has to be avoided in the following areas: Where it can interfere with other electronic devices in environments such as hospitals, airports, •... -
Page 60: List Of Acronyms
12List of Acronyms Accumulated Call Meter ASCII American Standard Code for Information Interchange Attention commands Cell Broadcast Cell Broadcasting Service Call Control Meter CLIP Calling Line Identification Presentation CLIR Calling Line Identification Restriction CMOS Complementary Metal-Oxide Semiconductor Carriage Return Circuit Switched Data Clear To Send Digital Audio Interface Data Carrier Detected... - Page 61 Light Emitting Diode Linefeed Mobile Equipment Man Machine Interface Mobile Originated Mobile Station Mobile Terminated Other Equipment Manufacturer Phone Book Protocol Data Unit Packet Handler Personal Identity Number PLMN Public Land Mobile Network PUCT Price per Unit Currency Table PIN Unblocking Code RACH Random Access Channel Radio Link Protocol...
-
Page 62: On-Line Support
13On-line support Elproma provides a range on on-line support which includes: the latest version of this document • the latest drivers for RB-MTX • technical support • This information can be found on our web sites at www.elproma.com.pl www.teleorigin.com. For further information You can contact us at: email: info@teleorigin.com...
