Summary of Contents for mobitech DR-1000
- Page 1 1CHANNEL DRIVING VIDEO RECORDER Instruction Manual DR-1000 Thank you for purchasing this product. For proper usages and application, Please read this instruction manual thoroughly. ver. 1.0 PRINTED IN KOREA * Design and specifications are subject to change without notice.
-
Page 2: Table Of Contents
Contents Safeguard instructions Please read the “Safety Rules” carefully before using this product. Following the safety rules prevents users from Safeguard instructions ..............................3 damages related with the misuse of the product. It is very important to follow these safety rules. We state “Cau- 1. - Page 3 The front glass and camera lens should be kept clean. Please take care below notice for SD card. we do not have responsibility for data - If it is dirty, the recording image may be low. loss or damage caused by not complying below rules. Attach the product recommended place.
-
Page 4: Feature
Feature Please take care below notice for built-in battery. We do not have responsibility · All car accident records for damage caused by not complying below rules. · Parking mode function : Ordinary power cable(option) connecting · Wide angle of view (130°) support (Built-in WDR CAMERA) Built-in battery is an auxiliary usage for safe saving recording image while the power is not supplied. -
Page 5: Installing The Recorder In Your Vehicle
Installing the recorder in your vehicle . How to install Prior to installation, check the followings : Front Glass Outdoor Outdoor Tinting section - To ensure safe installation, always perform installation procedures in a bright place with no vehicle traffic. Tinting section Front glass Double-sided... -
Page 6: Wiring Diagram
4. Wiring diagram Once it has been at a level with the ground after angle adjustment, connect the product to the cigarette jack. Push in the cigarette cable in the slit between the front glass and the roof. At this time, use a thin and hard object for convenient handling. -
Page 7: Components And Their Functions
Components and their functions Preparations for operation Before using the SD card, check the followings: - Always use the original SD card only. If not, data loss may happen. 11. GPS Engine - The SD card can be inserted regardless of the power On/Off status of the product. As soon as it is inserted, it will reset the internal software and then operate. -
Page 8: Operation
Operation . Video recording Once installation and wiring procedures have been completed, start up the engine with the SD card inserted. Then, it will power on without any other additional operation, and recording will start simultaneously. Before operating this product, please take case below point. * Factory Default : Dual Recording Mode (User can change recording mode on Recording setting / refer to page 7) - Do not operate on driving. -
Page 9: Emergency Recording / Instant Capture
5. Functions of MODE button 4. Emergency recording / Instant capture Voice recording ON/OFF (Default : ON) Emergency recording Emergency recording function is intended to activate manually recording in an unexpected event or when it is necessary to save images at discretion. Such images will be saved in [EVENT] folder of the SD card. While using the product, press [M] button shortly. -
Page 10: Pc Viewer Manager
PC VIEWER MANAGER . How to execute PC VIEWER MANAGER Double click DR-1000 icon then below screen is appeared and PC VIEWER MANAGER is executed. Recommended PC specifications for PC VIEWER MANAGER CPU : Pentium 4 2.0GHz or more Memory : 1GB RAM or more... -
Page 11: About User Interface
. About user interface 4. File list 1. File list Displays the files saved in the SD card. 2. Select Selects and deselects a file. 3. Extend list Extends the file list into an additional window. 4. Sort Sorts All/Normal/Event Files. 5. -
Page 12: Movie Control
5. Movie control 5. Sort file 1. Enables the user to sort All/Event/Normal files in the file list. 2. Click [ALL], and all the files in the SD card will be displayed in the list. 3. Click [EVENT], and EVENT files in the SD card will be displayed in the list. 4. -
Page 13: Screen Capture
6. Screen capture 8. Checking the route It is possible to check driving routes on the map. - Click screen capture button during playing, and the screen being played will be saved as an image file. 1. You can move the map by arrow button. - File format and Save path : JPEG / Same path as Export File List. -
Page 14: Configuration
10. Configuration Recording settings · Setting recording quality Click configuration button to open the configuration window. - High Quality : high-definition recording (heavy capacity) - Normal Quality: medium-definition recording (mediate capacity) - Low Quality : low-definition recording(low capacity) · Setting recording mode - Regular Mode: Regular recording at intervals of 1 min - Event Mode: Recording activated only in an event(15 sec.) - Dual Mode: Event recording activated in an event during... -
Page 15: Specifications
Specifications Input user informations · Input user password WDR CMOS Camera (130° Viewing Angle) Video Input Channel - Input Password : Input password Normal : 640x480 / Parking : 320x240 Recording Resolution - Confirm Password : Input password again for confir- mation. -
Page 16: Parking Mode
Parking mode : Ordinary power cable(option) connecting Parking mode ON/OFF FEATURE While using the product, press [M] button till the LED lamp off and on. To Parking surveillance mode means continuous recording mode on parking status which supports power from car stop the parking mode, then press M button shortly. - Page 17 MEMO MEMO...
- Page 18 INSTRUCTION MANUAL +82-32-458-1232 E-mail ds_back@mobiteq.co.kr Website www.hawk-eye.co.kr www.mobiteq.co.kr Address 24BL 5L, 451-4, Nonhyeon-dong, Namdong-gu, Incheon, Korea...
