Panasonic WV-CW474F Instructions

please read these instructions carefully and save this manual for future use.
CAUTION
RISK OF ELECTRIC
SHOCK DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER SER-
VICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrow-
head symbol, within an equilat-
eral triangle, is intended to
alert the user to the presence
of uninsulated "dangerous volt-
age" within the product's enclo-
SA 1965 sure that may be of sufficient
magnitude to constitute a risk
of electric shock to persons.
The exclamation point within
an equilateral triangle is intend-
ed to alert the user to the pres-
ence of important operating
and maintenance (servicing)
instructions in the literature
accompanying the appliance.
SA 1966
WARNING:
To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.

Preface

Panasonic's WV-CW474F/CW474S series color digital camera is designed for installing a
wall or ceiling board.

Installation

The following installation should be made by qualified service personnel or system installers.
Important notice: Be sure to use a ceiling board having enough strength to support this
camera.

Camera Mounting Position

WV-CW474F
should be mounted into the two gang junction box (4 in. x 4 in.) built in a
wall or ceiling.
WV-CW474S
should be mounted by use of the supplied camera mounting bracket. The
camera mounting bracket can be mounted on a flat surface such as a wall and ceiling.
Secure the camera mounting bracket to the position where the camera should be mounted
with the supplied four screws. Verify the camera mounting bracket is mounted firmly after
screwing it.
Camera mounting bracket
screw x 4 (procured locally)
Before attempting to connect or operate this product,
Color CCTV Cameras
WV-CW474F
Model No.
WV-CW474S
N1101-1121 V8QA5952BN
NOTE: This equipment has been tested and
found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful interfer-
ence when the equipment is operated in a
commercial environment. This equipment gen-
erates, uses, and can radiate radio frequency
energy and, if not installed and used in accor-
dance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential
area is likely to cause harmful interference in
which case the user will be required to correct
the interference at his own expense.
FCC Caution: To assure continued compli-
ance, (example - use only shielded interface
cables when connecting to computer or
peripheral devices). Any changes or modifica-
tions not expressly approved by the party
responsible for compliance could void the
user's authority to operate this equipment.
The serial number of this product may be found
on the top of the unit.
You should note the serial number of this unit
in the space provided and retain this instruction
as a permanent record of your purchase to aid
identification in the event of theft.
Model No.
Serial No.
<Mounting hole pattern>
85 mm
(3-3/8")
Instructions
Printed in Japan
N 19
Cable access hole for
3/4" pipe
51 mm
(2")
85 mm
(3-3/8")
Bracket center
For U.S.A
