Summary of Contents for ikonic IKE-D9004
- Page 1 IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual...
-
Page 2: Table Of Contents
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual CONTENTS Chapter 1: DVR Features..............................2 Chapter 2:Layoutt.................................. 3 2.1 Front Panel ..................................3 2.1.1 4-CH Front Panel (Details please refer to the real product)..................3 2.1.2 8-CH Front Panel (Details please refer to the real product)..................4 2.2 Rear Panel.................................. - Page 3 IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual 5.2.7.4 Language................................24 5.2.7.5 Info..................................24 5.2.7.6 System Maintenance ............................25 5.3 Menu Lock..................................25 5.4 Video Search..................................25 5.5 PTZ Control ..................................25 5.6 Record ..................................... 26 5.7 Stop recording ................................. 26 Chapter 6: Net-Viewer Program ............................
- Page 4 IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual Safety Instructions Use proper power source. Do not use this product with a power source that applies more than specified voltage (100-240V AC). Never insert anything metallic into the DVR case.
-
Page 5: Chapter 1: Dvr Features
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual Chapter 1: DVR Features Real time monitoring Supports real time surveillance via Monitor Saves Recordings DVR saves real-time recording image to HDD Backup Recordings Supports DVR backup via USB flash drive and hard drive. -
Page 6: Chapter 2:Layoutt
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual Chapter 2:Layoutt 2.1 Front Panel 2.1.1 4-CH Front Panel (Details please refer to the real product) Item Key title/Indicator Marks Functions Power Switch Turn Power on and off Power indicator If the “Green”... -
Page 7: 8-Ch Front Panel (Details Please Refer To The Real Product)
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual 2.1.2 8-CH Front Panel (Details please refer to the real product) Power Switch PAUSE: Pause / Frame Play PWR: PWR Indicator PLAY: Play IR receiver for Remote Control FWD: Play Forward / Move Right HDD: HDD Indicator STOP: Stop Playback;... -
Page 8: Rear Panel
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual 2.2 Rear Panel 2.2.1 4-CH Rear Panel (Details please refer to the real product) Item Physical port Connection method Connect CH1-4 ( BNC interface) Video input Video output Connect monitor output ( BNC interface) -
Page 9: 8-Ch Rear Panel (Details Please Refer To The Real Product)
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual 2.2.2 8-CH Rear Panel (Details please refer to the real product) CH1-8: Video inputs Audio Output Video Outputs USB port: backup to Flash Drive & Hard Drive Audio Input... -
Page 10: Remote Control
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual 2.3 Remote Control Channel Select 1-8 ; Numeric key 9、0 Numeric Key Preview all Channel Menu Enter/Exit Main Menu ▲ Up Key ▼ Down Key ◄ / Left / Right Key... -
Page 11: Chapter 3: Dvr Installation
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual Chapter 3: DVR Installation 3.1 Hard Drive Installation Caution： Please do not Install or take out hard drive when DVR is running! (1) Remove screws and open DVR upper cover carefully;... -
Page 12: Chapter 4: Dvr Boot Up
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual Chapter 4: DVR Boot up 4.1 System Initialization After connecting the power adapter and turning On the power button, the system will boot-up and start initializing. Picture 4-1 4.2 Main Interface After finishing system initialization the system will enter into main interface. -
Page 13: Main Menu Preview
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual 5.1 Main Menu Preview Color set Camera Dwell time display Recording Network Search Playback Rec. Search File List HDD Management Alarm Setting E-mail setting Device PTZ Setting Management Mobile... -
Page 14: Camera Setup
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual 5.2.1 Camera setup Go to [Main Menu Camera] to set up the name display and position display of each channel (Shown as Picture 5-3), You can also adjust image brightness, saturation, contrast and hue... -
Page 15: Network Set
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual The [Record Setup] menu allows you set up recording status (on/off) of each channel, it also allows you setup recording image resolution and quality, and turn audio on/off. This menu also allows you select recording mode (recording after power on and scheduled recording) and recording file length. - Page 16 IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual When selecting DHCP, DHCP server will allocate DVR IP address automatically. When selecting PPPoE, you need to input user and password provided by ISP supplier and set up web port (details please refer to the below picture 5-8).
-
Page 17: Recording Search
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual 5.2.4 Recording Search Click [Main menu search] to enter into [Video Search] menu (shown as the below picture 5-20). Searched playback: If you input specific date and click [Search], you will find all the recordings for that day. -
Page 18: Multi Player
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual 5.2.5 Multi player 1、Copy backup file to your PC. 2、Open multimedia player and click [File Local (F)] to find/select the backup file, and then click [open] button Note: the file type you have selected should be *.264 format. -
Page 19: Device Management
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual Recording date and time processing for the current recording file Play All the windows Previous recording file Add window Pause Start Stop Previous frame / Next frame Delete Slow play, Normal play, Fast Play... -
Page 20: Hdd Management
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual 5.2.6.1 HDD Management Click [Main Menu Device HDD] to enter [HDD Management] menu (shown as Picture 5-30) Picture 5-30 When you install a HDD, the system will automatically detect if HDD is formatted or not;... -
Page 21: Email Alarm Notification
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual Alarm Type Function Sends alarm when DVR can’t receive video signal (such as camera damage, cable broken or damaged Video Loss or power supply malfunction). When an object moves into motion detection area, alarm will be triggered. You can adjust Motion Detection sensitivity level to suit the needs of your actual application environment. -
Page 22: Ptz Setup
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual there are exceptions, for example, SMTP port of G-mail server should be 465. SMTP server: indicates server address you use. Sender email: indicates sender’s email address. The email address should be consistent with the server you use. - Page 23 IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual systems on 3G networks. Before you can access the DVR from a mobile phone you need to setup the Network Configuration on the DVR. Go to section 5.2.3 Network Setup on page 14 of the product manual for instructions on how to do this.
- Page 24 IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual Web port: Same as the Server Port you setup in the DVR, it needs to be forwarded to the IP address of the DVR, setting range is between 1024 and 65535, the default setting is 18600. Note: this port is in addition to the ports used for standard remote access.
-
Page 25: Server Port
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual on the Select option (red box in Pic 6). This will display the window in Pic 7, click on Continue (red box in Pic 7) which will display the screen in Pic 8 and tell you it is installing the program (red box in Pic 8). -
Page 26: Motion Detect
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual Pic 13 5.2.6.5 Motion Detect Click [Main Device Motion] to enter into the [Motion Detection] menu to setup motion detection recording. The [Motion detection] Menu has three sections, including Channel Status, Sensitivity and Motion area. -
Page 27: Password
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual 5.2.7.2 Password This option allows you set the device ID for the DVR and set the system password if you want to use one. The new passwords will be available after clicking [APPLY] button. -
Page 28: System Maintenance
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual 5.2.7.6 System Maintenance This option allows you reset the DVR to factory default settings, update system software (firmware), and set system auto-maintenance. Click [Main menu System Maintain] to enter into the [System Maintain] menu (shown as Picture 5-47). -
Page 29: Record
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual Clean: remove settings. Note: this DVR model supports up to 100 pre-set points. But actual quantities may be restricted by the PTZ camera you are using. 5.6 Record When you want the system to start recording click [ Rec ] button to start manual recording. -
Page 30: Main Interface Of Net-Viewer
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual 6.3 Main Interface of Net-viewer Picture 6.3 Log in Net-viewer and show the interface as follows 6.3.1 Menu column (Section 1 on Picture 6-3) 6.3.2 PTZ Control (Numbers 2, 3, 4 on Picture 6-3) 6.3.3 Live Play Control (Numbers 6 through 10 on Picture 6-3) -
Page 31: Setup
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual Slow button: slow playback recording. Next Frame: play frame by frame. 264 TO AVI button: convert file from H.264 format to AVI format The native format of the backup files is H.264, you can convert H.264 format into more familiar AVI format by clicking the key of 264 to AVI. -
Page 32: Host Info
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual System allows you setup motion detection settings for each channel of DVR remotely (shown as Picture 6-8) Picture 6-8 ③ PTZ Control Click [PTZ control] to setup PTZ cameras. Remote setup methods are the same as local DVR setup. -
Page 33: Log Out
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual 6.3.1.4 Log out Log out of the system. 6.3.2 PTZ Control (Numbers 2, 3, 4 on Picture 6-3) Note: below-mentioned series no will be consistent with the remark no shown as Picture 6-2. -
Page 34: Chapter 7: Specifications
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual Chapter Specifications Model Video System NTSC / PAL(Optional) Compression Format Video：H.264 / Audio：8kHz*16bit ADPCM 8-CH BNC input/2-CH BNC output / 1- Video Output 4-CH BNC Input/ 2-CH BNC Output / 1-VGA output... -
Page 35: Chapter 8: Windows Vista User
IKONIC, 15 rue du Buisson aux Fraises, 91300 Massy User Manual Chapter 8: Windows Vista User 1、Open IE browse firstly, then enter into Tool bar- and select appear the below picture: 2、Second, select icon tick the settings of “ActiveX controls and plug-ins”to Enable, details as follows: Lastly after tick all the “Enable”, please... - Page 36 Open IE browser and input IP address and web port of DVR…computer will auto downloadand install the widget. We suggest Visita user set user access authority in order to make your PC safer. Setting processing as follows: Click [Start Set Control panel User account] to set user access authority shown as below picture. Remind: If the widgets are not downloaded successfully, please check if your browser’s safety level or firewall setting is too advanced.
-
Page 37: Chapter 9: Appendix
Chapter 9: Appendix 9.1 Operation Function Table Type Title Description Page Time setting Setting system date, time and format and day-light saving time setting Language Select Setting system language Setting CH title and position; adjusting image color parameter value; setting CH display to CH Setting ON / Off and time display/recording time overlaying to On/Off. -
Page 38: Recording Alarm Setting
9.2 Recording Alarm setting Please refer the below matrix: “⊥” stand for “only alarm but no recording”; “AMR” stand for “alarm recording”; “NLR” stand for “normal recording”; and “NOR” stand for “ no recording”. Once alarm is triggered, alarm icon will occur, and when many alarms are triggered, alarm remarks will occur on the screen. Recording Mode Timing recording Recording alarm setting... -
Page 39: Email Server Check List
9.4 Email server check list （The below info only for your ref.） （Web site） Email address Sender server（25） Receiver server（110） @163.com smtp.163.com pop3.163.com smtp.vip.163.com pop.vip.163.com @vip.163.com smtp.188.com pop.188.com @188.com www.163.com @126.com smtp.126.com pop3.126.com @netease.com smtp.netease.com pop.netease.com @yeah.net smtp.yeah.net pop.netease.com www.163.net smtp.163vip.net popx.163vip.net www.sina.com... -
Page 40: System Connection Configuration
9.6 System connection Configuration 4-CH 8-CH... - Page 41 The material in this document is the intellectual property of our department . No part of this manual be reproduced, copied, translated, transmitted, or published in any form or by any means without our department prior written permission. Our products are under continual improvement and we reserve the right to make changes without noti ce.
