GeoBox G-301 Quick User Manual

G-301 Quick User Manual
------------------------------------------------------------------------------------------------------------------------------------------------
G-301 Passive 3D control Box Quick User Manual
Thank you for choosing GeoBox. GeoBox is an advanced dual channel video processor
with patented warp technology. It is a standalone system capable of image stacking, 2D
to 3D conversion and 3D demultiplexer with precise geometry adjustment. No additional
video distributor, tool or computer is required for the setup of GeoBox.
Figure 1
Figure 2
FCC/CE statement
Note: This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential/office installation. The equipment
generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
--Consult the dealer or an experienced Radio/TV technician for help.
--Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the
equipment.
1. Full HD input and output
2. Loop back for 3 projector stacking
3. Precise geometry adjustment for easy
system installation and stacking
4. New 2D to 3D conversion technology
5. Convert 3D for 2D TV display
6. Support HDMI 1.4 standard 3D
formats from Blue Ray, PC...
7. Multiple input ports to allow flexible
input source selection
8. 3D demultiplexer into RH/LH for
passive 3D display
9. User friendly OSD and IR remote
control. No PC is required
10. IR extender & RS-232 control
11. Allow same setup for 3D display and
high brightness 2D stacking
12. Support curved screen 3D display
1
Document: G-301102

Features
