Summary of Contents for Atak MP44MAG
-
Page 2: Know Your Player
Features: • Supports multiple music formats such as: MP1, MP2, MP3, & WMA • USB Flash disk function (no driver needed) • High-Speed USB 2.0 Data Transmission Know your player： Outline and key Definition of buttons functions： 1. “PLAY”: ON/ PLAY/ STOP/OFF. 2. - Page 3 3. “VOL–”: Volume decrease. 4. “NEXT”: NEXT entry, fast forward. 5. “PREV”: PREV entry, fast reverse. 6. “ON/OFF”: Power switch 7. “USB”: USB jack. 8. “Headphone Jack”: standard 3.5mm headphone jack. Loading Music Files on the MP3 Player: Connect the MP3 Player into your computers’ USB port. The MP3 Player will be recognized by your PC as a “Removable Disk”...
-
Page 4: Mp3 Mode
The Proper Way To Disconnect or “Eject” the MP3 Player from the Computer If the MP3 Player is not properly disconnected from the computer, music files may be lost, damaged, or the player may not operate correctly. For Windows and MAC systems, follow normal system procedures for the SAFE ejection of a “USB DEVICE”. - Page 5 3. Do not have the power of the MP3 player turned ON before connecting the player to your computer. The MP3 player will automatically turn itself on when inserted into the USB port. Playing Music: 1. Press the PLAY button once to begin playing music. In the PLAY mode, the red and green indicator light will flash alternately (if there are no audio files on your player, the red and green indicator will remain light instead of flashing) To pause the MP3 player, Press the button once and the player will PAUSE.
- Page 6 Insert the MP3 Player into the computers USB port or use the USB Extension cable. If the system correctly recognizes the player, the icon “USB Device” will appear on the Taskbar. If “USB Device” does not appear in the system tray, click on “My Computer” and the “Removable Disk”...
-
Page 7: Troubleshooting
Troubleshooting 1. Is the battery correctly installed? power 2. Please confirm if the unit is turned on can’t turn ON 1. Please ensure the volume is not at 0 and earphone connection has no problem No sound is 2. Please ensure the earphone is clean. heard in the 3. - Page 8 Max. output of (L) 10mW + (R) 10mW (32Ohm) earphone MP3 Bit Rate 8 Kbps—320 Kbps MP3, WMA WMA Bit Rate 5 Kbps – 384 Kbps Frequency response 20Hz to 20KHz Signal-to-Noise >87dB Audio file support MP3 & WMA Operational -5℃...
-
Page 9: Limited 90-Day Warranty
We warrant this product to be free from defects in material and workmanship under normal use for a ninety-day period from the original date of purchase from an authorized ATAK dealer. We will repair or replace the unit free of charge should it become defective under this warranty, providing you, the original purchaser, submit proof of purchase (sales slip) along with the unit and all accessories. - Page 10 USB or other memory devices are not covered nor is the cost incurred in shipping the unit for warranty repair. Under no circumstances shall ATAK be liable for any loss (direct indirect, incidental, foreseen, unforeseen, special or consequential) or for any damage arising out of, or in connection with, the use of this product.
