PureLinkk MX-1800 User Manual

Modular digital matrix router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL
USER MANUAL
MX-1800 / 3600
MX-1800 / 3600
Modular Digital Matrix Router
Ver 1.1
03/02/2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MX-1800 and is the answer not in the manual?

Questions and answers

Summary of Contents for PureLinkk MX-1800

  • Page 1 Ver 1.1 03/02/2009 USER MANUAL USER MANUAL MX-1800 / 3600 MX-1800 / 3600 Modular Digital Matrix Router...

  • Page 2: Table Of Contents

    Table of Contents Table of Contents 1. BASIC KNOWLEDGE OF THE PRODUCT 1-1. SAFETY INFORMATION AND INSTRUCTION 1-2. PACKAGE CONTENTS 1-3. PRODUCT FEATURES 1 4 NAMES AND FUNCTION OF EACH PART 1-4. NAMES AND FUNCTION OF EACH PART 1-5. INSTALLATION ENVIRONMENTS AND METHODS 2.
  • Page 3 MX Series Front Panel Diagram MX Series Front Panel Diagram < MX-1800 Modular Matrix Router> < MX-3600 Modular Matrix Router>...
  • Page 4 MX Series Rear Panel Diagram MX Series Rear Panel Diagram < MX-1800 Modular Matrix Router> < MX-3600 Modular Matrix Router>...

  • Page 5: Basic Knowledge Of The Product

    1. Basic Knowledge Of The Product 1. Basic Knowledge Of The Product 1 1 - - 1 Safety Information and Instruction 1 Safety Information and Instruction ▪ All the safety and user manual should be read before the appliance is operated. ▪...

  • Page 6: Package Contents

    DVI, HDMI, which are applied to most digital products. MX Matrix Series are designed to meet customers’ demands by providing prompt availability of DVI or HDMI Input / Output cards. MX-1800 allows you to populate the Input/ Output card with any connection (DVI or HDMI) you like and expand as needed.

  • Page 7: Names And Function Of Each Part

    1 1 - - 4 Names and Function of Each Part 4 Names and Function of Each Part • Main Chassis (For MX-1800 or MX-3600) • DVI Input / Output card with 3 or 6 ports, digital coaxial audio, HDCP compliant.
  • Page 8 2. Functions of the product 2. Functions of the product 2 2 - - 1. MX 1. MX- - 1800 / 3600 System Diagram 1800 / 3600 System Diagram Any combination of input channel can be routed to any output channel or single input channel can be assigned to multiple output channel by using front touch panel, RS-232c or LAN (TCP/IP) communication port.
  • Page 9 ▪ Power source: DC12V, 12.5A ▪ Power consume: 100Watts/max : 120Watts. ▪ Size (Width * Length *Height, INCH): 17.2” * 10.2” * 10.5”. (MX-1800) / 19” * 10.5” * 17.5” (MX-3600) ▪ Weight: 26.5 lbs (MX-1800) / 46 lbs (MX-3600)

  • Page 10: How To Operate

    3. How to operate 3. How to operate 3 3 - - 1 How to Create Channels 1 How to Create Channels When matrix is turned on, the front touch panel LCD display will show the list of Main Menu as follows: Power switch: Power On/Off Touch On/Off: Touch panel operation On/Off Back Light On/Off: Touch panel backlight On/Off...
  • Page 11 How to Create Channel: Select Input / Output channel: When CREATE icon on main menu is selected, Pic. C-2 will appears on the front LCD display. Step1. CHANNEL INPUT menu -> Select any Input channel -> Go to Step 2. <Please refer to Picture C 2>...
  • Page 12 Step 3. Confirmation OK: Finish the channel set up ->return to main menu RETURN: Returns to CHANNEL OUTPUT menu <Please refer to Picture C-4> < Picture C - 4 > How to read and save EDID: Read and Save EDID : If EDID icon is selected, Pic.
  • Page 13 Step1. OUTPUT EDID SELECT menu -> select OUTPUT channel (to retrieve EDID information from connected display device.) -> go to Step 2. <Please refer to Picture D-2> < Picture D - 2 > Step 2. Press EDID INPUT button -> select INPUT channel (one or multiple input channel can be selected) ->...
  • Page 14 3-1b Preview of Input and Output Channel or EDID selection: When PREVIEW icon is selected, Pic.D-4 will appears on the front LCD display. INPUT VIEW: View the status of selected Input channel OUTPUT VIEW: View the status of selected Output channel MATRIX VIEW: View the status of selected all input/output channel on single display...
  • Page 15 System Configuration: When SYSTEM CONFIG is selected Pic E 1 will appears on the front LCD is selected, Pic. E- 1 will appears on the front LCD Display. SYSTEM CONFIG is designed to change the configuration of RS-232, LAN, and SYSTEM. <Please refer to Picture E-1>...
  • Page 16 SYSTEM GENERAL CONFIGURATION When SYSTEM icon is selected, Pic E-4 will appear on the front LCD display. Buzzer: Buzzer sound On/Off SAVE: Save any change you make CANCEL: Return to main menu <Please refer to Picture E-4> < Picture E - 4 > SYSTEM INFORMATION SYSTEM INFO shows the current status of channel SYSTEM INFO shows the current status of channel...
  • Page 17 PRESET It allows users to have up to 20 different groups of preset For example lets say you want groups of preset. For example, lets say you want to use only 4 inputs & output channel and assign them in certain order. Then PRESET feature will help saving previous assignment.

  • Page 18: About Product Id

    Preset Save: Create -> Input -> Select One or Multiple #-> Output-> Select One or Multiple ## -> If you done selecting all Input and Output >Enter If you done selecting all Input and Output ->Enter- > Preset Save ->Preset Number -> Select # -> Preset Name ->Input Name->Save Preset Call: Preset Call->...

  • Page 19: Rs-232C (Com Port) Communication Protocol

    3. RS- - 232C (COM PORT) Communication Protocol 232C (COM PORT) Communication Protocol RS-232C PC Control Software Step 1. Click MX-1800 icon to execute the PC Digital Controller program. <Please refer to Picture H-1> < Picture H - 1 >...
  • Page 20 Step 3. Go to “Setting” on the tab menu and select valid COM port. Port: Select the communication port #1 through #4 Baud Rate: Select the Baud Rate which is correspond to the connected matrix switcher. Timeout: Configure the delay time for each control command command <Please refer to Picture H-3>...
  • Page 21 Step 3. Now you can see an added switch and the list of channels <Please refer to Picture H-6> < Picture H - 6 > To modify the added switcher: When you need to make any change on previously When you need to make any change on previously added switcher setting, you can go back by double- click on added switcher from the list of switcher box <Please refer to Picture H-7>...
  • Page 22 To use Pannel window: Selecting and changing input/output channel can be easily performed by using the Pannel window easily performed by using the Pannel window. To activate the Pannel window, double click NAME column as shown under. Create: Use to create a new input/output channel <...
  • Page 23 RS-232C Hyper terminal or other applications (For your convenience, we developed an external control software program called “Com-master”.) Step1. Execute ComMaster program and click “Open Com” button. <Please refer to Picture I-1> < Picture I - 1 > Step2. In Pic I-2, it is shows a command code as an example;...
  • Page 24 RS-232C Example of communication code when product ID is set to “01”. Example of communication code when product ID is set to “01” product ID is set to 01 . <Please refer to Picture I-3> < Picture I - 3 > Step3.
  • Page 25 RS-232C When an incorrect command is send to the matrix router, there won’t be any response. Example of Incorrect command !0101010302304* <Please refer to Picture I-5> N thi Nothing Changed ! < Picture I - 5 >...

  • Page 26: Pc Control Software

    255.255.255.255 < Picture J - 1 > Mac Address: Set up Mac Address/ default: 00.08.DC.00.00.00 Step 3. Execute MX-1800 / 3600 control program. Step 4. Enter the same IP address as you already set up in the router. Your LAN connection is now complete.
  • Page 27 < Picture J - 3 > command data at the bottom of left corner. <Please refer to Pic J-4> < Picture J - 4 > MX-1800 /360 Internet Explorer LAN Control Page Internet Explorer LAN Control Page Internet Explorer LAN Control Page...
  • Page 28 LAN (TCP /IP) TelNet TelNet Setup Setup When you use Telnet via LAN port, it enable you to remotely control Window DOS prompt, Hyper Terminal, and the Telnet program. (Control code is correspond with RS-232 command.) *Note: When you attempt to use either Telnet or Internet Explorer to communicate with the router, you must not input “0”...
  • Page 29 Communication Code Configuration Communication Code Configuration 4. 4. 4 4 - - 1.The Structure of 1.The Structure of Command code for RS Command code for RS- - 232 & LAN Communication & LAN Communication...
  • Page 30 Example of Command Code. Example of communication code when product ID is set to “01”.
  • Page 31 Baud rate: “ 00 ” : 1920 bps “ 01 ” : 4800 bps “ 02 ” : 9600 bps “ 03 ” : 14400 bps “ 04 ” : 19200 bps “ 05 ” : 28800 bps “ 06 ” : 38400 bps “...

  • Page 32: Lan Communication

    4 4 - - 2 LAN Communication 2 LAN Communication The following data is required in order to switch channels via internet connection Begin with a string of LCD.CGI”, “O 01 = I 18” represents “Output 01 Input 18”, the sequences and the size of strings have to be identical to each other After the reset, it needs to be connected to server again(switcher).

  • Page 33: Connector Pin Assignment

    4 4 - - 3 Connector Pin 3 Connector Pin Assignment POWER Assignment POWER INPUT INPUT...

  • Page 35: Warranty Information

    5. Warranty Information ▪ 2 Years Warranty y Dtrovision warrants this DVI Switcher to be free from defects in workmanship and materials, under normal use and service, for a period of 2 yeasr from the date of purchase from Dtrovision or its authorized resellers. If a product does not work as warranted during the applicable warranty period, Dtrovision shall, at its option and expense, repair the defective product or part, deliver to customer an equivalent product or part to replace the defective item or...
  • Page 36 Dtrovision LLC. 9A Bergen Turnpike Little Ferry, New Jersey 07643 Tel: 201-488-3232 Fax: 201-621-6118 www.dtrovision.com For help with placing an order please contact your local distributor or For help with placing an order, please contact your local distributor or reseller. For any technical question or support you need, please contact us support@dtrovision.com...
