Summary of Contents for clientron PT6100

  • Page 1 PT6100 User Manual Version: 1.0 P/N : Cover Page Cover page 1 | 1 1 1...
  • Page 2 Clientron PT6100 User Manual Version: 1.0 Copyright Copyright 2014 Publishing. All Rights Reserved. This manual, software and firmware described in it are copyrighted by their respective owners and protected under the laws of the Universal Copyright Convention. You may not reproduce,...
  • Page 3 Clientron PT6100 User Manual Version: 1.0 Safety Instructions Read these instructions carefully. Keep these instructions for future reference. Please disconnect this equipment from AC outlet before cleaning. Don’t use liquid or sprayed detergent for cleaning. Use moisture sheet or cloth for cleaning.
  • Page 4: Table Of Contents

    Clientron PT6100 User Manual Version: 1.0 Table of Contents 1. Packing List……………………………………………… Standard Accessories……………………………………….. Optional Accessories………………………………………... 2. System View ……………………………...………. …… Rear View…………………………………………………….. Specification………………………………………………….. Internal Layout……………………………………………….. 3. Pin Definition……………………………………………... 4. Rear I/O Interface…………………..…………………… 5. System Assembly & Disassembly…………………… HDD…………………………………………………………..CFast ard…………………………………………………….
  • Page 5 Clientron PT6100 User Manual Version: 1.0 7. BIOS/Utility Setup……………………………………….. 8. LCD Surface Cleaning………………………………….. P110 5 | 111...
  • Page 6: Packing List

    Clientron PT6100 User Manual Version: 1.0 Packing List Packing List Standard Accessories System (with stand) Power Adapter Power Cord Driver Bank Screw x2 Cable Cover Optional Accessories a. Single MSR b. 3 IN 1 MSR c. UPS Battery d. Screw x2...
  • Page 7: System View

    Clientron PT6100 User Manual Version: 1.0 System View System View 2-1 Rear View with Optional LPT Port Rear View Standard Item 19V DC Input PS2(K/B) RJ45(COM 4 for External VFD) UPS Battery(Option) COM2 COM3 USB 2.0/1.1 X4 RJ45(LAN) 10. RJ11(Cash Drawer) 11.
  • Page 8: Specification

    Clientron PT6100 User Manual Version: 1.0 2-2 Specification Processor Intel® Celeron J1900 Quad Core 2.0Ghz Memory One SO-DIMM socket supports DDR3L up to 8GB Audio Line-out/Mic-in Network RJ45 10/100/1000 Base-T 4*USB 2.0 Storage CFast card / 2.5” SATAII HDD / SSD...
  • Page 9: Internal Layout

    Clientron PT6100 User Manual Version: 1.0 Internal Layout 9 | 111...
  • Page 10: Pin Definition

    Clientron PT6100 User Manual Version: 1.0 Pin Definition Pin Definition 1. COM 5 for Touch Panel (CN 7) Function Function Function T_UR T_SG T_LR T_UL T_LL 2. Parallel J1 Pin Name Description Pin NO. Pin Name Description STB# Printer Strobe...
  • Page 11 Clientron PT6100 User Manual Version: 1.0 5. Mic J3 Pin Name Description Ground Ground Mic R Mic L Detect Detect 6. Speaker SP1 Pin Name Description Speaker + Speaker - 7. LVDS CN 13 Pin Name Description Pin NO. Pin Name...
  • Page 12: Rear I/O Interface

    Clientron PT6100 User Manual Version: 1.0 Rear I/O Interface Rear I/O Interface 1. COM1’ COM2’ COM3 port Signal Function Signal Function Carrier Detect (IN) Data Set Ready (In) Receive Data (IN) Request To Send (OUT) Transmit Data(OUT) Clear To Send (IN)
  • Page 13 Clientron PT6100 User Manual Version: 1.0 3. USB port Signal Name Wire Colour Comment Cable Power - Data White Data Transfer + Data Green Data Transfer Ground Black Cable Ground Shell Shield Drain Wire 4. PS/2 K/B port Signal Name...
  • Page 14: System Assembly & Disassembly

    Clientron PT6100 User Manual Version: 1.0 System Assembly & Disassembly System Assembly & Disassembly 1. Unfasten the HDD cover screw*2 2. Pull out the HDD bracket 3. Fasten the screw*4 4. Place the HDD bracket back to the module 5-2 CFast Card Please notice the unnotched CFast Card .
  • Page 15 Clientron PT6100 User Manual Version: 1.0 Before Installing CFast Card. After Installing CFast Card 15 | 111...
  • Page 16: Msr

    Clientron PT6100 User Manual Version: 1.0 1. Open the MSR cover 2. Single MSR or 3-in-1 3. Screw*2 M3x10L 4. Fasten the screw 5-4 UPS Battery Paste two rubbers on the located position of the Stand Bracket. Reeve two cable ties through the stand bracket. Place the battery pack in position and bind the cable ties tightly.
  • Page 17: Cable Cover

    Clientron PT6100 User Manual Version: 1.0 cable cover Assemble the cable cover from bottom and make sure the two latches are on the right position. Then fasten 2 screws (M3*5L). 5-6 15” 2 Display ☆ Power supply must be replaced to 120W above power adapter.
  • Page 18 Clientron PT6100 User Manual Version: 1.0 2. Install the pole into the socket in clockwise direction. 3. Fasten the four screws (M4*8L) to joint the VESA bracket and the rear cover. 4. Connect the COM port, DC cable as shown in figure .
  • Page 19 Clientron PT6100 User Manual Version: 1.0 7. Assemble the cable cover from bottom and make sure the two latches are on the right position, and fasten the two screws (M3*5L). Route the cables through the opening of stand front cover and cable clip at the bottom and route the cables into the tube of pole.
  • Page 20 Clientron PT6100 User Manual Version: 1.0 10. Mount the VESA bracket on the pole and route cables out of the tube of VESA bracket. Fasten the thumb screw to fix the VESA bracket. 11. Connect the DC power cable as shown in figure.
  • Page 21: Internal Vfd

    Clientron PT6100 User Manual Version: 1.0 5-7 Internal VFD Clientron electronics Model PT6100 Assembling Figure Inc. Operation VFD MODULE assemblely Item Operation procedure Remark Prepare all components as Fig 1 Assemble holder & hinge assy by TAPPING SCREW P/H 2.6φ*5 x2 pcs(As Fig 2) Torque 2Kgf Fix VFD module on holder assy by TAPPING SCREW P/H 2.6φ*5 x4 pcs as Fig 3...
  • Page 22: Wi-Fi

    Clientron PT6100 User Manual Version: 1.0 5-8 Wi-Fi Connect the antenna to Wi-Fi module, fastening the Wi-Fi Module to the Rubber , then fasten WI-Fi Module and antenna on VFD cover. Assemble VFD cover and Back panel with 2 screws. Then connect Wi-Fi /MSR cable to...
  • Page 23: Nd Display

    Clientron PT6100 User Manual Version: 1.0 5-9 8” 2 Display Remove the plastic pole cover from the stand. Install the pole into the socket in clockwise direction. 23 | 111...
  • Page 24 Clientron PT6100 User Manual Version: 1.0 Connect VGA cable and DC power cable Fasten the four screws (M4*8L) to joint the VESA bracket and the rear cover. Reeve the cables out of the tube. 24 | 111...
  • Page 25 Clientron PT6100 User Manual Version: 1.0 6. Mount the VESA bracket on the pole and route cables out of the tube of VESA bracket. Fasten the thumb screw to fix the VESA bracket. Reeve the cables out from the bottom of pole.
  • Page 26 Clientron PT6100 User Manual Version: 1.0 Connect the VGA cable as shown in figure. Put the cable cover on the hinge of VESA bracket. 26 | 111...
  • Page 27: 2D/I-Button With Rfid Module

    Clientron PT6100 User Manual Version: 1.0 5-10 1D / 2D / i-Button with RFID module Cable installation. a. For i-Button with RFID module; For 2D barcode scanner with RFID module: Connect the cable as shown in figure. b. For 1D barcode scanner with RFID module: Connect the cable as shown in figure.
  • Page 28: Pole Type Vfd Vd1220

    Clientron PT6100 User Manual Version: 1.0 5-11 Pole type VFD VD1220 1. Take VFD panel and two VFD poles out from the package box and Install two tubes into one pole and reeve the cable from the VFD panel through the socket of stand.
  • Page 29 Clientron PT6100 User Manual Version: 1.0 Then install the pole into the foot ring. 5 cable to POS terminal’s RJ45 port Then connect RJ4 29 | 111...
  • Page 30: Device Driver Installation

    Clientron PT6100 User Manual Version: 1.0 Device Driver Installation Device Driver Installation 6-1. Resistive Type Touch Panel and P-CAP 1. Click “Next”. 2. Click “Next”. 30 | 111...
  • Page 31 Clientron PT6100 User Manual Version: 1.0 3. Click “Next”. 4. Select “None”, Click “Next”. 5 Click “OK”. 31 | 111...
  • Page 32 Clientron PT6100 User Manual Version: 1.0 6. Select “Support Multi-Monitor System”, Click “Next”. 7. Click “Next”. 32 | 111...
  • Page 33 Clientron PT6100 User Manual Version: 1.0 8. Click “Next”. 9. Click “Next”. 33 | 111...
  • Page 34 Clientron PT6100 User Manual Version: 1.0 10. Select “Create a eGalaxTouch Utility shortcut on desktop”, Click “Next”. 34 | 111...
  • Page 35 Clientron PT6100 User Manual Version: 1.0 11. Would you do 4 point calibration now? Click “Yes”. 12. Do 4 points aligrment to match display. 13. Calibration utility. 35 | 111...
  • Page 36: Magstripe Card Reader Configuration Utility

    Clientron PT6100 User Manual Version: 1.0 6-2 MagStripe Card Reader Configuration Utility 1. Combo USB HID MSR The MagStripe Card Reader Configuration Utility is used to set up the output format of HIDMSR-20 Installation Below steps guide you how to install the Utility program ...
  • Page 37 Clientron PT6100 User Manual Version: 1.0 Configuration Below is the main window of Utility program. For the settings, there are:  Language: The language defines the code positions of the keyboard. Each language should use its own settings. Wrong language selected will cause the wrong character displayed.
  • Page 38 Clientron PT6100 User Manual Version: 1.0 Shown below is the data structure of the output string for MSR. PR2 SS2  PP: Prefix for package.  PR1: Prefix for track 1.  SS1: Start sentinel for track 1.  TK1: Data for track 1, if error happens, using Error Message instead.
  • Page 39 Clientron PT6100 User Manual Version: 1.0 This group defines the start and end sentinel for each track. The sentinel is always used to extract the track data from the whole MSR data string. The data length for each sentinel is fixed to one character.
  • Page 40 Clientron PT6100 User Manual Version: 1.0 Switch Output Order Show below is the selection of the three track data output order (sequence). The default order is Track 1–Track 2–Track 3. There 6 orders allow to be selected. Please select one to fit your application needs.
  • Page 41 2. SINGLE MSR The MagSwipe Configuration Utility is used to set up the output format of MagSwipe Installation Below steps guide you how to install the Utility program  Insert the setup CD  Run the 80066804-006_Magswipe_Configuration_Software_V2_1_A setup file that is located in the Software folder of CD.
  • Page 42 Clientron PT6100 User Manual Version: 1.0 Configuration Select Reader Interface The reader to be configured should be connected. Select the corresponding connected reader interface and click the Continue button 42 | 111...
  • Page 43 Clientron PT6100 User Manual Version: 1.0 After the interface selection is made, click the Continue button. The utility attempts to communicate with the connected reader. If successful, the Home Menu Page is displayed. The Home Menu Page is shown below...
  • Page 44 Clientron PT6100 User Manual Version: 1.0 Button Definitions Send To MSR When all the setting parameters are selected, use the "Send To MSR..." button to send configuration data to the reader device. When the reader has received the data correctly, the settings take effect immediately.
  • Page 45 Clientron PT6100 User Manual Version: 1.0 The configuration data can be saved as a file and being used later to configure other readers. When saving a configuration the "File Save" dialog is opened as shown below. Input a filename and file location.
  • Page 46 Clientron PT6100 User Manual Version: 1.0 MSR Reading This option will turn on or off the MSR. If MSR is disabled no data is sent out to host in any case. The default is MSR Reading Enabled. Decoding Method Settings This option gives four kinds of decoding methods.
  • Page 47 Clientron PT6100 User Manual Version: 1.0 can transmit, setting an appropriate inter-character delay will keep the reader from overrunning the host input buffer. The default is 2ms. Default Page Button After you click the Default Button, the general settings page will change back to the default value.
  • Page 48 Clientron PT6100 User Manual Version: 1.0 Track Settings Track Selection There are three tracks of info rmation possible on a magnetic stripe. This option selects the tracks that will be decoded (read). Note that the magnetic stripe reader must have the hardware configuration (read head and circuits) for reading the specified tracks.
  • Page 49 Clientron PT6100 User Manual Version: 1.0 The error output for track 1 is "%E?". The error output for track 2 is ";E?". The error output for track 3 is "+E?". Keyboard Settings Keyboard Settings There are keybroad settings information on a magnetic stripe. MiniMag II will support following foreign language keyboard and function key output for PS/2 and USB HID Keyboard Interface.
  • Page 50 Clientron PT6100 User Manual Version: 1.0 50 | 111...
  • Page 51: Fingerprint Reader

    Clientron PT6100 User Manual Version: 1.0 6-3 Fingerprint Reader 1. Check Fingerprint reader be detected by “Device manager “ 2. Select SDK folder. 3. Run Setup.exe. 51 | 111...
  • Page 52 Clientron PT6100 User Manual Version: 1.0 4.Click “Next”. 5. Select “ I accept the terms in the license agreement” and click “Next”. 52 | 111...
  • Page 53 Clientron PT6100 User Manual Version: 1.0 6. Click “Next”. 7. Click “Next”. 53 | 111...
  • Page 54 Clientron PT6100 User Manual Version: 1.0 8. Click “Install”. 9. Click “Finish”. 54 | 111...
  • Page 55 Clientron PT6100 User Manual Version: 1.0 10. Restart systems. 11. Check Fingerprint reader in Device Manager. 55 | 111...
  • Page 56 Clientron PT6100 User Manual Version: 1.0 12. Launch Fingerprint reader from start menu 13. Select “COM-ActiveX” 56 | 111...
  • Page 57 Clientron PT6100 User Manual Version: 1.0 14. Select “Sample” 15. Select ”VB6’. 57 | 111...
  • Page 58 Clientron PT6100 User Manual Version: 1.0 16. Select “Enrollment Sample”. 17. Enroll the fingerprint by the “Enrollment“ 58 | 111...
  • Page 59 Clientron PT6100 User Manual Version: 1.0 18. Select “Fingerprint Enrollment” 59 | 111...
  • Page 60 Clientron PT6100 User Manual Version: 1.0 19. Put your finger on fingerprint reader and follow the direction to enroller your fingerprint, it need scan your fingerprint 4 times 20. After enroller finish it will popup a dialog box 60 | 111...
  • Page 61: Rfid

    Clientron PT6100 User Manual Version: 1.0 RFID 1. Install Check the Device Manager to verify the status of RFID reader. Computer Management -> Device Manager -> Other devices (The device will show a question mark if the installation is not done properly.) 1.2 Install RFID driver,file name:XP2KxVista.exe...
  • Page 62 Clientron PT6100 User Manual Version: 1.0 1.2.1 After clicking Next, A pop up console window appears as below. 1.2.2 Check the Device Manager to verify the status of RFID reader. Computer Management -> Device Manager -> Ports (COM & LPT)
  • Page 63 Clientron PT6100 User Manual Version: 1.0 1.3 install RFID utility MifareDemoSetup_PSW00020.exe 3-1 Path:\MF320\MifareDemoSetup_PSW00020.exe 1.3.1 InstallShield Wizard will be activated. 63 | 111...
  • Page 64 Clientron PT6100 User Manual Version: 1.0 1.3.2 Click “Next”. 1.3.3 Click “Next”. 64 | 111...
  • Page 65 Clientron PT6100 User Manual Version: 1.0 1.3.4 Click “Giga-TMS” & “Next”. 1.3.5 Click “Next”. 65 | 111...
  • Page 66 Clientron PT6100 User Manual Version: 1.0 1.3.6 Click “Finish” 2. Run RFID demo program. Start -> All Programs -> GIGA-TMS -> Mifare Demo 66 | 111...
  • Page 67 Clientron PT6100 User Manual Version: 1.0 2.1 Run “Auto Scan” Demo AP will detect the RFID reader automatically. Or select the RFID COM port 67 | 111...
  • Page 68 Clientron PT6100 User Manual Version: 1.0 2.2 After finishing the AutoScan, Request box will be ready for the click and Reader Version will show on the position as marked. (Reader Version: PGM-T1235 V1.0R3 (101230) Place Mifare Card to the RFID reader area. Event Dialog window gets the data from the Mifare Card.
  • Page 69 Clientron PT6100 User Manual Version: 1.0 2.3 Card type will be recognized when you click “Request”. (Your Mifare card should be placed on the RFID reader area.) Card ID will be recognized when you click “Card ID”. 69 | 111...
  • Page 70 Clientron PT6100 User Manual Version: 1.0 2.5 SAK will be read when you click “Select”. 2.6 The result will show when you click “Authenticate”. 70 | 111...
  • Page 71: Internal Vfd

    Clientron PT6100 User Manual Version: 1.0 6-5 Internal VFD Specification Display Method Vacuum Fluorescent Display(blue-Green) Number of Characters 40 (20 Columns X 2 Lines) Brightness 500 ~ 1000 cd/m2 Character Font 5X7 Doc Matrix Alphanumeric, International Character Type Characters Character Size 6.75(H) X 3.75(W)mm...
  • Page 72 Clientron PT6100 User Manual Version: 1.0 72 | 111...
  • Page 73 Clientron PT6100 User Manual Version: 1.0 73 | 111...
  • Page 74 Clientron PT6100 User Manual Version: 1.0 74 | 111...
  • Page 75: Configuration Utility Of I-Button Reader

    Clientron PT6100 User Manual Version: 1.0 6-6 Configuration Utility of i-Button Reader Notice: For the i-Button Reader device, there are two installation positions with two different I-button readers from different vendor. Please select correct configuration utility for installation 3 in 1 MSR Bottom Case 1.
  • Page 76 Clientron PT6100 User Manual Version: 1.0 76 | 111...
  • Page 77 Clientron PT6100 User Manual Version: 1.0  The utility program will detect the connected reader. If detected, all the input text boxes will be enabled.  If the reader has not been connected to PC yet, please connect the reader and then click Refresh to get connected.
  • Page 78 Clientron PT6100 User Manual Version: 1.0 reader. Save Settings To save the settings to a file, click Save; specify the file name and location to be saved. Open Settings To load pre-saved settings, click Open, specify the settings file, and then click OK to load into program.
  • Page 79 Below steps guide you how to install the Utility program.  Insert the setup CD  Run the Clientron I Button Utility.exe setup file that is located in the Software folder of  Follow the wizard to complete the installation. 1. Setup IButton _V1.0.exe software...
  • Page 80 Clientron PT6100 User Manual Version: 1.0 80 | 111...
  • Page 81 Clientron PT6100 User Manual Version: 1.0 81 | 111...
  • Page 82 Clientron PT6100 User Manual Version: 1.0 2. To execute “IButton_V1.0.exe” for setup communication between software and IButton module. 82 | 111...
  • Page 83 Clientron PT6100 User Manual Version: 1.0 ● The utility program will detect the connected reader. If detected, all the input text boxes will be enabled. ● If the reader has not been connected to PC yet, please connect the reader and then click Refresh to get connected.
  • Page 84 Clientron PT6100 User Manual Version: 1.0 For the settings, there are: ● Prefix/Suffix: Defines the data string which you would like to append in front or end of the i-Button key string. ● Error Message: Indicates error message when i-Button key read fail.
  • Page 85 Clientron PT6100 User Manual Version: 1.0 DEMO SETUP&OUTPUT OUTPUT DATA : a!ab00000003bdfa01? b!ab00000003bdfa01? 85 | 111...
  • Page 86: Installation And Testing Of Smart Card Reader

    Clientron PT6100 User Manual Version: 1.0 6-7 Installation and Testing of Smart Card Reader Check smart card reader be detected by “Device manager”. 2. Install the SCR driver. 86 | 111...
  • Page 87 Clientron PT6100 User Manual Version: 1.0 3. Run Setup.exe. 4. Click “Yes”. 87 | 111...
  • Page 88 Clientron PT6100 User Manual Version: 1.0 5. Restart systems. 6. Check SCR reader in Device Manager. 88 | 111...
  • Page 89 Clientron PT6100 User Manual Version: 1.0 7. Run the testing program – EZ100test. 8. Conferm that SCR can be detected by the testing program, then run the program - the Start Testing. 89 | 111...
  • Page 90 Clientron PT6100 User Manual Version: 1.0 9. Follow dialog boxes displayed to remove and insert card. 10. After finishing the testing, the dialog box will show “oK”. 90 | 111...
  • Page 91: Wifi

    Clientron PT6100 User Manual Version: 1.0 6-8 WiFi 1. Install the WiFi driver. 2. Select “I accept the terms of the license agreement” and click “Next” 91 | 111...
  • Page 92 Clientron PT6100 User Manual Version: 1.0 3. Select “Install driver and Ralink WLAN Utility” and click “Next” 4. Click “Install” 92 | 111...
  • Page 93 Clientron PT6100 User Manual Version: 1.0 5. Starting install 6. Click “Finish” 93 | 111...
  • Page 94: Pole Type Vfd Vd1220

    Clientron PT6100 User Manual Version: 1.0 6-9 Pole type VFD VD1220 Power on VFD and waiting test page of EEPROM test, Baud rate and Command page. Set up the customer display by " VFDset.exe” Setup VFDset.exe software. 94 | 111...
  • Page 95 VFD module (Note: You may check it when power on VFD module), then click “Open COM” button. “Get Setting from VFD” button to get all the settings from Clientron and it’ll refresh the “VFDset.exe” software. Select “Character Type”/ “Command Mode”/ “Baud Rate Select”/ “passthru Mode”.
  • Page 96 Clientron PT6100 User Manual Version: 1.0 Click “Set All Default” button To show default setting, the Default table is :USA Character Type :EPSON/EURPOPE Command Type Baud Rate Setting :9600/n/8/1 :None Pass-through Mode Welcome msg line1 :*** VFD DISPLAY *** Welcome msg line2 :**HAVE A NICE DAY AND THANK YOU 7.
  • Page 97 Clientron PT6100 User Manual Version: 1.0 8. Click “Download setting to VFD” button This button is to download the setting from VFDset.exe to VFD module. After success dialog “Download O.K! Please restart!” message popped up. Please restart display for enable new setting 9.
  • Page 98 Clientron PT6100 User Manual Version: 1.0 10. Click “Load’ button After saving, you must restart the utility here. Then load your setting rename-GOODLUCK.vfd. 98 | 111...
  • Page 99 Clientron PT6100 User Manual Version: 1.0 BIOS/Utility setup BIOS/Utility setup Press <DEL > / <F2> key to enter BIOS SETUP UTILITY when system boot up. ☆ Please press <DEL > / <F2> key tenderly and slowly. 99 | 111...
  • Page 100 Clientron PT6100 User Manual Version: 1.0 Press <F9> to view the system information Date and Time The Date and Time items show the current date and time on the computer. If you are running a Windows OS, these items are automatically updated whenever you make changes to the Windows Date and Time Properties utility.
  • Page 101 Clientron PT6100 User Manual Version: 1.0 7-1 Advanced Use the Advanced menu to configure the system for basic operation through the following sub-menus: 101 | 111...
  • Page 102 Clientron PT6100 User Manual Version: 1.0 7-1-1 Boot Configuration Use the Boot Configuration menu to select power-on state for Numlock. 102 | 111...
  • Page 103 Clientron PT6100 User Manual Version: 1.0 7-1-2 Audio Configuration Use the Audio Configuration menu to read Audio configuration information and configure the Audio settings 103 | 111...
  • Page 104 Clientron PT6100 User Manual Version: 1.0 7-1-3 Video Configuration Use the Video Configuration menu to read Video configuration information and configure the Video settings 104 | 111...
  • Page 105 Clientron PT6100 User Manual Version: 1.0 7-1-4 SATA Configuration Use the SATA Configuration menu to read SATA configuration information and configure the SATA settings 105 | 111...
  • Page 106 Clientron PT6100 User Manual Version: 1.0 7-2 Security Use the Security menu to install or change the password 106 | 111...
  • Page 107 Clientron PT6100 User Manual Version: 1.0 7-3 Power Use the Power menu to install or change the password AC Loss Auto Restart Enable or disable system power on automatically after AC power restored RTC Wake Up When enabled, System will wake on the hr;;min;;sec specified...
  • Page 108 Clientron PT6100 User Manual Version: 1.0 7-4 Boot Use the Boot menu to select type to Dual type, Legacy type or UEFI type. 108 | 111...
  • Page 109 Clientron PT6100 User Manual Version: 1.0 7-5 Exit Use the Save & Exit menu to load default BIOS values, optimal failsafe values and to save configuration changes. 109 | 111...
  • Page 110 Clientron PT6100 User Manual Version: 1.0 LCD Surface Cleaning LCD Surface Cleaning Processo 1. How to clean the LCD surface properly? ☆ Do not spray any liquids on the LCD screen directly, and do not use paper towels, Chipsets: this can cause the LCD screen to become scratched.
  • Page 111 Clientron PT6100 User Manual Version: 1.0 CE Notice This device complies with the requirements of the CE directive. FCC Notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
