M e c h a n i c a l T i M e r , 2 4 h o u r - u s e r g u i d e
Vogue combi c26, c32, c40
When replacing any part on this appliance, use only spare parts that you can be assured conform to the safety and
performance specification that we require.
Do not use reconditioned or copy parts that have not been clearly authorised by Ideal.
Advertisement
Summary of Contents for Ideal Stelrad Group Vogue Combi c26
- Page 1 M e c h a n i c a l T i M e r , 2 4 h o u r - u s e r g u i d e Vogue combi c26, c32, c40 When replacing any part on this appliance, use only spare parts that you can be assured conform to the safety and performance specification that we require.
- Page 2 back Mechanical Timer, 24 Hour Suitable for the following boilers: Vogue Combi Outer dial SETTING UP The outer dial should be set to the current 24hr clock time. Rotate the dial slowly in a clockwise direction, until the correct hour is aligned with the arrow printed on the dial.
- Page 3 back PROGRAMMING SWITCHING TIMES Set tappets to outer edge for ON periods and set tappets to inner edge for OFF periods. The example shown has been set with 2 on OFF PERIOD periods. ON at 9.00am. OFF at 1.00pm. (13 hours) ON PERIOD ON at 6.00pm.
- Page 4 August 2012 UIN 208945 A01 Ideal Stelrad Group pursues a policy of continuing improvement in the design and performance of its products. The right is therefore reserved to vary specification without notice. Ideal Boilers Ltd., P.O. Box 103, National Ave, Kingston Upon Hull, HU5 4JN.
