OmniPod Insulin Management System Quick Start Manual

11368-AW Rev E © 2008 Insulet Corporation
How to navigate through
the Setup Wizard
1. Use the Up/Down Controller button to increase or decrease
a number or to move up or down a list.
2. Press the soft key labeled Next, Select, Save, or Done to
continue to the next screen.
3. Press the soft key labeled Back or Cancel to return to the
previous screen.
The function of each soft key will appear on the LCD screen
above each button. The screens shown above display a small
sample of these functions.

Contact Information

Insulet Corporation
Customer Support: 800.591.3455 (24 hours/7days)
When calling from outside the United States: 781.457.5098
Web Site: MyOmniPod.com
Quick Start
Guide
The OmniPod Insulin Management System
Personal Diabetes Manager (PDM)
Soft key
label
Soft keys
Home
Food library
Blood glucose
records
Up/down controller
Power/Backlight
Test strip port
Set up
1
1
your Personal Diabetes Manager (PDM)
using the OmniPod Setup Wizard
1. Insert the AAA batteries included with
your PDM. Icons located in the battery
compartment indicate the direction they
need to be inserted.
2. Working with your healthcare provider, the
Setup Wizard will guide you through the
setup process. Follow the prompts on the
screen to set:
• Time and date
• Maximum basal rate
• Initial basal rate and/or program
• Temporary basal
• Blood glucose sound setting and BG goal
• Suggested bolus calculations and
associated targets, ratios, and factors
(if applicable)
• Bolus increment
• Maximum bolus
• Extended bolus
• Low reservoir volume alert
* These steps should be performed under the
supervision of your healthcare provider.
OmniPod
IR port
Top
LCD Screen
Viewing window
Bottom
User
info/support
Fill port
Needle cap
Adhesive
backing
*
Continued
on other side
