Page 1 User Manual AF5D-20 2D/3D Multi-Projector Stacking Processor...
Page 2 AF5D-20 Quick User Manual (Single channel Warp & High Resolution Edge blending) AF5D-20 is an advanced single channel video processor with patented warp technology, passive 3D decoding and edge blending function. It is designed to work with Matrox “M” series video card for high resolution edge blending and capable of image warp, stacking &...
Page 3 Outlook and Functions Help tips OSD Lock / Unlock: Continuously press [MENU] key in Front Panel or IR Remote Controller for 12 seconds, the OSD function will be locked to prevent from the changes of the settings by other people. To press MENU key for 12 seconds again, it will unlock OSD and user can manipulate the OSD again.
Page 4: Internal Grid Pattern For Geometry Adjustment
2. Internal Grid Pattern for Geometry Adjustment To press [PATTERN] key in Remote Controller or at front panel, it will show Cross Hatch grid pattern. To press [PATTERN] key again, different color of Grid patterns will appear cyclically from White  Red  Green  Blue ...
Page 5: Passive 3D Display
3D video sources, including Blue Ray DVD, STB, Media player, Game and PC… 3D signal will be decoded by AF5D-20 into signal for Right or Left eyes. One AF5D-20 can only provide signal for one projector. RH/LH 3D signals need be displayed through two projectors.
Page 6 7.3 Procedures for 3D Display Setting in AF5D 1. After image alignment, to activate [3D Properties] menu and select [Input Format]. 2. Select [Automatic] if the 3D signal is standard 3D formats from Blue Ray player or sources with 3D index inside the signal.
Page 7: Keystone Correction
Activate [Anyplace] Menu for Warp and Geometry correction of the image. [Warp] & [4 Corner] short cuts are available in remote controller. 8.1 [Keystone] Correction If the projection direction from projector is not perpendicular to the screen, the image on the screen will have keystone as below.
Page 8 [4 Corner] can adjust each corner position of the image independently and is the simplest way for the alignment in multiple projector applications, such as Edge Blending, stacking & 3D display. Use OSD MENU to activate [4 Corner] adjustment or Press [4 CORN] hot key in Remote Controller Maximum adjustment range for each corner is ±256 pixels horizontally (max.
Page 9: Application Case Study
Using Matrox M9148 display card for Dual projector Edge Blending: super high resolution Edge blending AF5D-21: video wall settings application: AF5D-20: Geometry adjustment and  Geometry adjustment and edge edge blending blending via AF5D-20  Image split and overlap by M9148 VGA card 8.5 Image Curved Display—[Warp]...
Page 10 Example: Curve adjustment in all Corners 8.5.2 [Edge] Curve adjustment User can adjust the curve in each edge of the image independently. OSD Menu under [Edge] Curve adjustment includes [Left Edge], [Right Edge], [Top Edge], [Bottom Edge] and [Reset] Example: After applying 4 Edges curve adjustment 8.5.3 [Center] Curve adjustment Under [Center] Menu user can adjust the...
Page 11 The axis center can be adjusted horizontally and vertically with the range of ±256 pixels in horizontal position and ±200 pixels in vertical position if the output resolution is under 1400x1050. In full HD output resolution, the adjusting range is H±200 & V±150 pixels. 8.5.4 [Shift] adjustment (4 Corner adjustment) [Shift] function is to adjust the corners of the image before or after Curved adjustment.
Page 12: Osd Miscellaneous Functions-[Options]
 [Front Edge Mask] is to mask the image edge before Warp.  [Rear Edge Mask] is to mask the image after Warp.  In most of edge blending application, [Rear Edge Mask] will be applied. Each edge of the image can be masked with black background up to 250 pixels.
Page 13: Button Repeat Rate]
9.3 [Reset]  [Exit] menu will exit from [Reset] menu and the system settings will not be changed.  [Reset All] menu will reset AF5D to its factory default settings.  [Anyplace] menu will reset the settings in [Anyplace] function to its factory default settings In [Reset] menu, there are two types of Reset can be done: Reset All and reset [Anyplace] function.
Page 14: Logo Time Out]
Menu.  Internal Grid Pattern will be also controlled by the time setting in [Menu Time Out] menu. 9.4.3 [Logo Time Out]  To set the time to show Splash screen when power on AF5D.  If “Off” is selected, then the splash screen will not appear during system booting up period.
Page 15: Profile Setting
9.5.3 [Profile Setting] [Profile] is to save and load AF5D settings including input port, output resolution and all the settings in AF5D. Five indexes can be chosen to save AF5D settings in each AF5D and can be recalled by IR remote controller or RS232 9.5.4 [Network] ...
Page 16 Air ex5D, LLC. info@air ex5D.com www.Air ex5D.com v1.3 11/12...
