Operating Instructions
LED TV
Thank you for purchasing this Panasonic product.
Please read these instructions carefully before operating this product and
retain them for future reference.
The images shown in this manual are for illustrative purposes only.
M0514-1054
For more detailed instructions, refer to [eHELP]
(Built-in Operating Instructions).
●
How to use [eHELP]
AS670H series
AS700H series
(p. 16)
CQD
TQB4GC1140-1
English
Advertisement
Table of Contents
Related Manuals for Panasonic VIERA AS670H series
Summary of Contents for Panasonic VIERA AS670H series
-
Page 1: Operating Instructions
● How to use [eHELP] (p. 16) Thank you for purchasing this Panasonic product. Please read these instructions carefully before operating this product and retain them for future reference. The images shown in this manual are for illustrative purposes only. -
Page 2: Table Of Contents
Contents Be Sure to Read Important Notice··················································· 3 Safety Precautions ··············································· 4 Quick Start Guide Accessories ························································ 6 Connections ························································ 8 Identifying Controls ··············································11 First time Auto Tuning···········································14 Using your VIERA Operations ·························································15 ● For the information of the trademarks, refer to How to Use eHELP ··············································16 [eHELP] (Support >... -
Page 3: Important Notice
Panasonic has no authority to and does not grant you that permission and explicitly disclaims any right, ability or intention to obtain such permission on your behalf. -
Page 4: Safety Precautions
Safety Precautions ● Do not use an unapproved pedestal / mounting equipment. Be sure to ask your local Panasonic dealer to perform the setup or installation of approved wall-hanging brackets. To help avoid risk of electrical shock, fire, damage or ●... -
Page 5: Touch Pad Controller
● Replace only with the same or equivalent type. (English only) ● Do not mix old and new batteries. http://panasonic.net/viera/support ● Do not mix different battery types (such as alkaline ■ and manganese batteries). Bluetooth wireless technology ®... -
Page 6: Accessories
■ Accessories 3D Eyewear Use Caution ● Use the 3D Eyewear only for the intended purpose Remote Control and nothing else. ● (p. 11) Do not move around while wearing the 3D Eyewear to avoid falling or accidental injury. ● N2QAYB000933 ●... - Page 7 Assembling / Removing the pedestal Assembly screw (4) M5 × 15 Assembly screw (4) M4 × 12 Bracket (2) Base 42-inch model 50-inch model 55-inch model 60-inch model Removing the pedestal from the TV Be sure to remove the pedestal in the following way when using the wall-hanging bracket or repacking the 1 Remove the assembly screws from the TV.
-
Page 8: Connections
Connections Basic connections ■ Mains lead ● External equipment and cables shown are not supplied with this TV. ● Please ensure that the unit is disconnected from the mains socket before attaching or disconnecting any cables. AC 220-240 V ● Check the terminal type and cable plugs are correct 50 / 60 Hz when connecting. - Page 9 ■ Wireless connection AV devices ■ DVD Recorder / VCR Internet environment Built-in wireless LAN Access point Other connections ■ DVD Player (COMPONENT equipment) RF cable HDMI cable DVD Recorder / VCR (Viewing) Aerial ■ Set top box (Listening) DVD Player HDMI cable ■...
- Page 10 ■ Amplifier (to listen with speakers) ● Use HDMI2 for connecting an amplifier. This connection is applicable when using an amplifier that has ARC (Audio Return Channel) function. As for an amplifier without ARC function, use DIGITAL AUDIO OUT. ● To enjoy multi-channel sound from external equipment (e.g.
-
Page 11: Identifying Controls
Identifying Controls 7 OK ● Confirms selections and choices. ● Press after selecting channel positions to quickly change channel. ● Displays channel list. Remote Control 8 [Option Menu] ● Easy optional setting for viewing, sound, etc. 9 Coloured buttons (red-green-yellow-blue) ●... - Page 12 ■ Installing / Removing batteries 1 Standby On / Off switch 2 Volume Up / Down 3 [Main Menu] Pull open 4 Touch pad (p. 12) 5 [Option Menu] Hook 6 My button ● Press to register the content as your favourite. ●...
- Page 13 ■ Installing / Removing batteries 3 Volume Up / Down Cursor Left / Right (when in the menu system) 4 Mains power On / Off switch Slide open ● Use to switch the mains power. 5 Remote control signal receiver ●...
-
Page 14: First Time Auto Tuning
First time Auto Tick the TV signal mode to tune, and then select [Start Auto Tuning] Tuning : tune (search for the available channels) : skip tuning ■ When you select the analogue TV signal, Automatically sets up the TV and searches for available select your area. -
Page 15: Operations
Operations Select a channel down Turn power on (TV) ● To select a channel position with 2 or more-digit, e.g. (Remote Control) ● Mains power On / Off switch should be on. (p. 13) The last viewed [Home Screen] is displayed. To access each feature Example: [TV Home Screen] Access [APPS List] and select a feature... -
Page 16: How To Use Ehelp
● Please consult the suppliers of contents or programmes for availability of this service. ■ select item 3D photos and 3D videos taken by 3D-compatible Panasonic products access ● Available in Media Player and Network services. ■ Sub item field... -
Page 17: Faqs
FAQs Maintenance Before requesting service or assistance, please follow First, remove the mains plug from the these simple guides to solve the problem. socket outlet. ● For more information, refer to [eHELP] (Support > FAQs). Display panel, Cabinet, Pedestal The TV does not switch on Regular care: ●... -
Page 18: Specifications
Specifications Rated power consumption 42-inch model 94 W ■ 50-inch model 115 W Model No. 55-inch model 131 W AS670 series : TH-42AS670H 60-inch model 42-inch model : TH-50AS670H 146 W 50-inch model : TH-55AS670H 55-inch model Standby power consumption AS700 series 0.20 W : TH-60AS700H... - Page 19 CATV USB 1 / 2 S1-S20 (OSCAR) DC 5 V, Max. 500 mA [Hi-Speed USB (USB 2.0)] 1-125 (USA CATV) C13-C49 (JAPAN) DIGITAL AUDIO OUT S21-S41 (HYPER) PCM / Dolby Digital / DTS, Fibre optic Z1-Z37 (CHINA) 5A, 9A (AUST.) Receiving systems / Band name Aerial input 17 Systems...
-
