- Page 1 Ture TV Ture TV MOBILE DIGITAL TV RECEIVER USER MANUAL...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Remote Control Product Exterior Front Panel Rear Panel Installation Diagram Front Installation Diagram Rear Installation Diagram Operating Guide Control Panlel Usage Channel Function Menu Settings and Machine Setup Search Function Menu EPG Setting Muli-Audio Selection Special Attention Items Specifcations NOTE... - Page 5 Digital Set-top Box Special Features Suitable for areas with DVB-T reception. Receives both UHF and VHF signals. antenna installation is easier than traditional type. Built-in digital decoder and receiver , therefore the images won't be snowy, ghosty, or lose fidelity and colour.
-
Page 7: Safety Guidelines
SAFETY GUIDELINES In order to ensure vehicle safety, the driver side screen must be connected to the "4 Video Out" connector. This will ensure the driver won't be able to watch TV while the vehicle is moving. The driver will be able to watch TV once the hand- brake is activated. -
Page 8: Remote Control
REMOTE CONTROL... -
Page 9: Product Exterior
PRODUCT OVERVIEW Front Panel VIDEO OUT POWER LED Video output to external device such as The green light is lit in power on mode LCD panel AUDIO OUT L/R MODE Viewing mode (On/On), Erase Audio output to external device such EEPROM (On/Off), software update as LCD panel (Off/On), PAL/NTSC/SECAM mode switch... -
Page 10: Rear Panel
Rear Panel ANTENNA IN Connect to terrestrial TV aerial... -
Page 11: Installation Diagram
INSTALLATION Ture TV Front Installation Diagram GREEN HANDBRAKE CONTRO BLACK BLUE +5V OUTPUT BLACK YELLOW +12V~+24V HI-FI AMPLIFIER... -
Page 12: Rear Installation Diagram
Rear Installation Diagram... -
Page 13: Operating Guide
OPERATING GUIDE Control Panel Usage Press the Menu button to display the control panel. The default menu displayed will be the CHANNEL menu. (The text of the selected menu will change its colour from white to yellow). Use the CHANNEL menu to preview the program parameters, to display the signal status, and to set up a password lock. -
Page 14: Channel Function Menu
Channel Function Menu Press the Menu button to display the control panel. The default menu dis- played will be the CHANNEL menu. The small screen on the left shows the program being broadcasted on the channel that is currently selected in the list below. -
Page 15: Settings And Machine Setup
Settings and Machine Setup Controlling the menu: Press the Menu button to display the control panel. While in the control panel, press the Menu button function menu and then the Setup button. Use the buttons to select a menu option (on the left). Press OK to enter the sub-menu (on the right). - Page 16 Change Password To change the password for the chan- nel lock, enter first the old 4-digit pass- word, then the new 4-digit password, and lastly the new password again as confirmation. The factory default for the old password is 0000. Aspect Ratio Use this menu option to select the aspect ratio that is most suitable for the...
- Page 17 Menu Transparency Use this menu option to change the transparency of the subtitle. The greater the number selected, the more transparent it is. Banner Time Use this menu option to change the amount of time the banner stays visible when no commands are issued. The greater the number selected, the longer the subtitle remains.
- Page 18 Controlling the menu: Press the Menu button to display the control panel. While in the control panel, press the Menu button function menu and then the Setup button. Use the buttons to select a scan method. Press OK to enter the Country menu option.
- Page 19 Delete a Carrier From Scan Mode select Delete Carrier. Select your country from Country. Select a carrier from the carrier window and press OK to delete.
-
Page 20: Search Function Menu
Search Function Menu Auto Scan Fast From Scan Mode select Fast. Once your country has been selected, press OK to run the scan (the scan is performed quickly). Complete From Scan Mode select Complete. Once your country has been selected, press OK to run the scan (the scan will run for a longer period of time). -
Page 21: Epg Setting
EPG(Electronic Program Guide) Press the EPG button to enter the EPG window. Press the Menu button to select the fol- lowing modes: NOW: Program guide for currently showing programs. Next: Program guide for upcoming programs. Weekly: Weekly program guide. Use the buttons to select a pro- gram to preview. -
Page 22: Muli-Audio Selection
Multichannel Audio Press the M/A to enter the multichannel audio menu. Use the buttons to select an audio channel, which could be Audio- 1,2,3..depending on the source of the signal. Use the buttons to enter the Audio Mode option. Use the buttons to select an audio Mode, which could be one of 3F,Left Channel ,Right Channel ,L+R... -
Page 23: Special Attention Items
Special Attention Please use the standard 75 Ohm antennas designed for digital TV. This machine provides a +5V DC power for use by the antenna. The power can be used by an active antenna. If the antenna used has an impedance lower than the standard 75 Ohm or has short-circuited, the screen will display an "antenna power overload"... -
Page 24: Specifcations
SPECIFICA TIONS HARDW ARE SPECIFICATIONS HARDWARE SPECIFICATIONS POWER SUPPLY Input voltage DC 12V~DC 24V Power consumption Max. 12W DEMODULATION Wavefor m COFDM Modes suppor ted 2K & 8K FEC combinations including hierarchical modes Constellation QPSK, 16-QAM, and 64-QAM TUNER Input connector F Type, Female Input frequency UHF and VHF... -
Page 25: Note
otes... - Page 26 otes...
- Page 27 otes...
- Page 28 M032U00400Y-...
