Summary of Contents for Gold Line MX4
- Page 1 OPERATOR'S MANUAL Model MX4 Four Channel Microphone Multiplexer...
- Page 2 2,3,4 should be set to the out/off position. 5. Turn the gain control for channel 1 of the MX4 to the straight up middle position on the control. In this position the MX4 should not provide significant boost or cut.
- Page 3 If you do not have time averaging, slow mode can be used, but some variation in the data will be seen as the MX4 switches between channels. 10. Take acoustical measurements as you would as if using a single microphone.
- Page 4 SPECIFICATIONS Inputs: Channels: Max. level: 117dB SPL Typical input impedance: 1.2kΩ Noise floor: 35dB SPL CMRR: 60Hz - 1kHz: 70 dB 20Hz - 20kHz: 65 dB Phantom power supplied: each mic input, 12Vdc, 1.2kΩ x 2 Connectors: XLR, 3 pin jack, 1 Shield, 2+, 3- Outputs: Channels:...
