Thank you for purchasing this Vollrath food preparation equipment. Before operating the equipment, read and familiarize yourself with
the following operating and safety instructions. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. Save the original box and
packaging. Use this packaging to ship the equipment if repairs are needed.
description
HP
Grinder No. 12
1 hp
Grinder No. 22
1-1/2 hp
Operator's Manual
Amps Voltage
8
110
16
110
English
Grinder
Plug
5-15P
5-20P
Item No. 2350138-1 en Rev 11/11
Advertisement
Related Manuals for Vollrath MIN0012
Summary of Contents for Vollrath MIN0012
- Page 1 1-1/2 hp 5-20P Thank you for purchasing this Vollrath food preparation equipment. Before operating the equipment, read and familiarize yourself with the following operating and safety instructions. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. Save the original box and packaging. Use this packaging to ship the equipment if repairs are needed.
-
Page 2: Features And Controls
reParation quiPment aFety reCautions eatures and ontrols To ensure safe operation, read the following statements and understand their meaning. Please read carefully. WArninG Warning is used to indicate the presence of a hazard that can cause severe personal injury, death, or substantial property damage if the warning is ignored. - Page 3 reParation quiPment 1. Before grinding, verify the grinder chamber (D) is seated correctly on the main body (C) and tighten the thumbscrew (B) counter-clockwise until secure. See Figure 1. nOTe: do not use a tool to tighten the thumbscrew. Hand tighten only.
- Page 4 There are no user serviceable parts within this appliance. To avoid serious injury or damage, never attempt to repair the equipment or replace a damaged power cord yourself. Do not send equipment directly to the Vollrath Company. Please contact the qualified professional repair service listed below.
- Page 5 reParation quiPment eleCtriCal draWing - g ~ 40743 rinder eleCtriCal draWing - g ~ 40744 rinder ’ peratOr anual...
- Page 6 reParation quiPment eXploded vieW draWing - g ~ 40743 rinder ’ peratOr anual...
- Page 7 reParation quiPment spare parts list - g ~ 40743 rinder Callout Part number Description FEEDER PAN XMIN1224 XMIN2202 MEAT PUSHER XMIN1226 BRASS BUSH FOR CHAMBER XMIN1204 GRINDING CHAMBER HEAD XMIN1203 COUPLING COVER NUT PLATE 1/8" XMIN1207 XMIN1208 PLATE 1/4" XMIN1209 PLATE 1/2"...
- Page 8 reParation quiPment eXploded vieW draWing - g ~ 40744 rinder ’ peratOr anual...
- Page 9 reParation quiPment spare parts list - g ~ 40744 rinder Callout Part number Description XMIN2223 FEEDER PAN XMIN2202 MEAT PUSHER XMIN2204 GRINDING CHAMBER XMIN2203 COUPLING COVER NUT XMIN2207 PLATE 1/8" XMIN2208 PLATE 1/4" XMIN2209 PLATE 1/2" XMIN2206 GRINDER KNIFE 8/9/10 XMIN2205 WORM/ SPIRAL PROPELLER XMIN2210...
- Page 10 MErChAnTABiliTY Or FiTnEss FOr A PArTiCUlAr PUrPOsE As The Vollrath Company LLC’s only responsibility and the purchaser’s only remedy, for any breach of warranty, The Vollrath Company LLC will repair or, at its option, replace the defective product or part without charge, except as otherwise provided below: •...
-
Page 11: Warranty Procedure
ONLINE: Register your warranty on-line now at www.Vollrathco.com NO WEB ACCESS: If you do not have access to the web, kindly register by completing the warranty registration form and faxing it to The Vollrath Co. LLC office in the country of purchase. - Page 12 The Vollrath Company, L.L.C. Technical Services: 800.628.0832 1236 North 18th Street Service Fax: 920.459.5462 Sheboygan, WI 53081-3201 U.S.A. Canada Service: 800.695.8560 www.vollrathco.com Main Tel: 800.628.0830 Fax: 800.752.5620 © 2010 The Vollrath Company, L.L.C.
