Summary of Contents for ImproX XDT900-0-0-GB-XX
- Page 1 ImproX Door Terminal INSTALLATION MODEL: XDT900-0-0-GB-XX MANUAL Manual ref number: XDT300-0-0-GB-01 Issue 2 July 2001...
-
Page 2: Important Notice
IMPORTANT NOTICE Although all efforts have been made to make this manual as accurate as possible, Impro Technologies (Pty) Ltd does NOT accept any liability for errors or omissions. The data contained in this manual supersedes any other information published on the product. We further reserve the right to amend or improve the equipment and manual without notice. -
Page 3: Table Of Contents
INTRODUCTION ..................... 4 SPECIFICATIONS....................4 PHYSICAL SPECIFICATIONS ................. 4 ENVIRONMENTAL SPECIFICATIONS..............4 ELECTRICAL SPECIFICATIONS................5 OPERATOR INTERFACES ..................6 IMPROX PROTOCOL..................... 6 INSTALLATION INFORMATION................6 REQUIREMENTS ....................6 POSITIONING THE UNIT ..................6 INSTALLATION PROCEDURE ................7 CONNECTING THE UNIT ..................8 General ...................... -
Page 4: Introduction
The unit provides two input sensors for door open/close sensing, and one relay for controlling door strikes or other equipment. The unit also provides 5 VDC and TTL communications for a Remote Reader such as the ImproX CR, KR, MR, KHR, MHR or connects to an Impro 4-Channel UHF Receiver. -
Page 5: Electrical Specifications
8 data bits, no parity, 1 stop bit. • Electrical Interface RS485, ASCII with 16-bit CRC checking. • Communications protocol ImproX Secure Communications Protocol. Receive (Slave Mode). • Default mode Data subject to change without notice © July 2001 Impro Technologies... -
Page 6: Operator Interfaces
• Outgoing RS485 Data Red LED (flashing) (internally visible). IMPROX PROTOCOL The unit communicates with other ImproX units via the RS485 Terminal Bus using the ImproX Secure Communications Protocol. INSTALLATION INFORMATION REQUIREMENTS To install the unit the following tools are required : (a) A suitable electric drill and drill bits. -
Page 7: Installation Procedure
Line Power On Termination Jumper PTC1 PTC2 Side 1 Side 2 LINK1 Remote Type LINK2 Selection Jumpers 5V OUT COMMS Anti-tamper REMOTE UNIT switch pcb.wmf Figure 1 : Relative location of significant components INSTALLATION PROCEDURE [1] Using the housing as a template, mark the position of the mounting holes on the mounting surface. -
Page 8: Connecting The Unit
When connecting the ImproX DT Terminal to a Remote Reader of types MR, KR, MHR, KHR and CR, it must be remembered that the "Tx" terminal on the ImproX DT Terminal must be connected to the "Rx" terminal on the Remote Reader, and vice versa. It is recommended that the cable screen be connected to the "Remote Unit 5V Out -"... -
Page 9: Relay Outputs
IL LCD Keypad Computer. TYPES OF ADDRESSES Each ImproX unit is allocated a unique Fixed Address at the factory. This address is stored in its memory. When the unit is installed in a system, the system allocates a separate Logical Address to the unit for communication purposes. -
Page 10: Recording Of Installation Information
RECORDING OF INSTALLATION INFORMATION Installation Information When any ImproX unit is received from the factory, the Fixed Address associated with that unit must be recorded by the installation personnel. This is done using a label supplied with the unit, and an ImproX Unit Location Chart (provided with every ImproX IC Controller or ImproX IL Computer). - Page 11 REMOTE TERMINAL CAUTION: Maximum distance of the These terminals are POWER Remote Terminal from OUTPUT terminals. the ImproX DT is 20 meters. DO NOT connect incoming power to these terminals, as this can damage the unit, and nullify the guarantee. connections2.wmf...
-
Page 12: Entering Installation Information In The Host Pc
Fixed Address, its Logical Address and a unique description of the physical location of the unit. RELATED PRODUCTS The ImproX DT Terminal is designed to be used in conjunction with the ImproX IL Computer and ImproX IC Controller. Data subject to change without notice ©... -
Page 13: Ordering Information
This range is continually being updated. Please consult your Impro dealer for details of any additions to the range. ORDERING INFORMATION The ImproX DT Terminal can only be ordered paired with a Remote Reader. The ordering codes are as follows : COMBINATION... - Page 14 NOTES Data subject to change without notice © July 2001 Impro Technologies Page 14...
- Page 15 NOTES Data subject to change without notice © July 2001 Impro Technologies Page 15...
-
Page 16: Applicability Of This Manual
