Ikebana™ IEEE 1394 External DVD-R/RW Drive
Quick Start Installation Guide for Windows PC
Thank you for purchasing Ikebana™ IEEE 1394 External DVD-R/RW product. Please follow these installation instructions
carefully.
Minimum Hardware and Operating System Requirements
•
Pentium III running at 500Mhz or higher processor
•
128MB of RAM or more
•
Available IEEE 1394 (FireWire) port. This may be a built-in (on-board) type or provided by a PCI card or a
PCMCIA CardBus card. If you are newly installing an IEEE 1394 PCI or CardBus interface card, your computer
should have an empty PCI expansion slot or a PCMCIA CardBus slot.
•
CD-ROM Drive
•
Windows 98 Second Edition
•
Windows Millennium Edition
•
Windows 2000
•
Windows XP
•
0ver 100MB of free hard disk space
NOTE: Your interface card MUST be OHCI (Open Host Controller Interface) Compliant.
NOTE: This IEEE 1394 / FireWire Multimedia drive is not recommended to be use on any Servers or any type of
Enterprise machines and it is only recommended for Computer Desktops use.
Handling Precautions
If these handling instructions are not followed, damage to the IEEE 1394 (FireWire) External DVD-R/RW product may
result – which may void your product warranty.
•
DO NOT attempt to open the product. It will void the warranty.
•
DO NOT bump or drop this device as it may result of internal damage.
•
DO NOT set the product on its side as it may fall over and it may result of internal damage.
•
DO NOT disconnect any cables or power while copying files as this will result in data loss.
•
DO NOT set any liquids or drinks on the product. If spilled, it will damage the internal electronics and it will void
the warranty.
1
Advertisement
Table of Contents
Related Manuals for Ikebana IEEE 1394 External DVD-R/RW Drive
Summary of Contents for Ikebana IEEE 1394 External DVD-R/RW Drive
-
Page 1: Handling Precautions
Ikebana™ IEEE 1394 External DVD-R/RW Drive Quick Start Installation Guide for Windows PC Thank you for purchasing Ikebana™ IEEE 1394 External DVD-R/RW product. Please follow these installation instructions carefully. Minimum Hardware and Operating System Requirements • Pentium III running at 500Mhz or higher processor •... -
Page 2: Package Contents
Package Contents The Ikebana™ IEEE 1394 External DVD-R/RW Kit includes the components shown here. Please familiarize yourself with each of these items prior to installation. IEEE 1394 (FireWire) External DVD-R/RW Drive External Power Supply IEEE 1394 (FireWire) Cable One blank DVD-RW disc... - Page 3 3. Ground yourself by touching your computer’s chassis or power supply unit to drain any static that built up inside your body. NOTE: You can permanently damage equipment if you touch it while there is any static charge in your body.
- Page 4 6. Attach the outer casing of the computer and any screws that were removed. Then reconnect your monitor, mouse, keyboard and the computer to the electrical outlet. IEEE 1394 (FireWire) Driver Installation Please follow these simple procedures to complete the driver installation. 1.
- Page 5 3. Select “CD-ROM driver” (or “Specify a location”, if you know where the driver is located). Then insert the Windows 98 Second Edition (or Windows ME/2000/XP) CD-ROM into the computer and click “Next”. 4. Once the wizard has found the location of the driver, it is ready to install. Click “Next” to begin the installation. 5.
-
Page 6: Verifying The Hardware Installation
Please refer to IEEE 1394 (FireWire) PCI card Installation. You need to connect your new Ikebana™ IEEE 1394 External DVD-R/RW product to your computer prior to running the installation software. Please follow these simple steps to setup your new product: 1) Power down your computer and unplug it from the AC outlet. -
Page 7: Installing The Software
Note: For more information about how to use the operating system, refer to the documentation that came with it. Note: If there is a mark next to the icon for the Ikebana™ IEEE 1394 External DVD-R/RW or the IEEE 1394/FireWire®... - Page 8 3. The User Registration screen appears. Input your name and corporation name. Software installation will not continue without inputting required information. Input the 18-digit serial number included in the B's Recorder GOLD package and click “Next.” Confirm user registration by clicking “Yes.” 4.
- Page 9 B's Clip UDF Packet Writing software can be easily installed by inserting the CD-ROM and following the instructions on the screen. 1. Insert Ikebana™ Software Bundle CD into your CD-ROM or CD-RW drive. Autorun will automatically run setup or to install the program manually, browse this CD in [My Computer] and double click the appropriate setup.exe file.
- Page 10 3. The User Registration screen appears. Input your name and corporation name. Software installation will not continue without inputting required information. Input the 18-digit serial number included in the Ikebana™ Software Bundle package and click “Next.” Confirm user registration by clicking “Yes.”...
-
Page 11: Other Software
Start, Programs, BHA, B’s Clip and select Users Manual. Other Software There may be other promotional software supplied in your new Ikebana™ IEEE 1394 DVD-R/RW Kit. If so, please follow instructions on the software discs and/or screen prompts (directions) to install the additional software. - Page 12 Product support and Customer Service Agents are available from 9 a.m. to 5 p.m. (Pacific Standard Time) Monday – Friday. All material contained herein Copyright © 2002 Shecom Corporation. Ikebana and Ikebana logos are trademarks of Shecom Corporations. Other trademarks are the property of their respective holders. Contents subject to change without notice.
- Page 13 Ikebana™ Multimedia Products 1 Year Limited Warranty Shecom Corporation warrants to the original purchaser, only, that it’s Ikebana™ Multimedia products will be free from defects in material and workmanship for a period of 1 Year from the date of original purchase.
