Summary of Contents for APW Wyott CMC-24
Page 1
INSTALLATION OPERATING INSTRUCTIONS CHEESE MELTERS MODELS: CMC-24, -36, -48 CMP-24, -36, -48 CMW-24, -36, -48 24 Hour Toll Free Service Hot Line: 1-800-733-2203 IMPORTANT FOR FUTURE REFERENCE APW WYOTT Foodservice Equipment Company...
Page 2: General Information
Notes: GENERAL INFORMATION...
Page 3
TABLE OF CONTENTS...
Page 4: Safety Precautions
CMC-24 (Counter Top) 2.4kw CMW-24 (Wall Mount) 2.4kw CMP-24 (Pass Thru) 2.4kw CMC-36 (Counter Top) 3.6kw CMW-36 (Wall Mount) 3.6kw CMP-36 (Pass Thru) 3.6kw SAFETY PRECAUTIONS SPECIFICATIONS CMC-48 (Counter Top) 2 @ 1200W 2 @ 1200W CMW-48 (Wall Mount) CMP-48 (Pass Thru)
Page 5: Installation
CMC-24 17 ¼ CMW-24 17 ¼ CMP-24 CMC-36 36 ½ 17 ¼ CMW-36 36 ½ 17 ¼ ¼ CMP-36 36 ½ CMC-48 ¼ ¼ CMW-48 CMP-48 19 ¼ 15 ¼ INSTALLATION 19 ¼ 17 ¼ ¼ 17 ¼ ¼ 19 ¼...
Page 6
Sketch 1 Sketch 3 Sketch 2 Sketch 4...
Page 7: Maintenance
OPERATION CLEANING MAINTENANCE GENERAL TROUBLESHOOTING...
Page 8: Replacement Parts List
11072-03 Terminal block 12154-00 Cooling fan 11372-02 Voltage regulator 13016-09 Rack switch, 24" & 36" models 13016-13 Rack switch, 48" models 13016-06 Main power switch 15208-00 Pilot light 31008-01 Heater socket 11195-22 Contactor 31007-56 Wire rack, 48" models REPLACEMENT PARTS LIST 31007-80 31007-55 825301-00...
Page 9
Electrical Schematic (24” and 36” models) Electrical Schematic (48” model)
Page 11
Notes:...
Page 12
APW WYOTT Foodservice Equipment Company...
