- Page 1 ®...
- Page 2 Higher. Complete and ready to install, ™ The E Z Q u e st Cobra USB 2.0 drives include: Hard Disk S p e e d t o o l s ® s o f t w a r e and all necessary cables.
- Page 3 10-11...
-
Page 4: Package C O N Ta I N S
PACKAGE C O N TA I N S : COBRA USB HARD DRIVE USB cable Power Cable Hard Disk Speedtools Quick Setup Manual EZ-Startup CD- Includes: Multimedia Manual, PDF Manual, Warranty Card and Registration Form. - Page 6 Capacities:............40,60,80,100,120GB Buffer Size:................2MB Media Transfer Rate:............297Mb/s Data Transfer Rate:....30-35 (USB 2.0), 5-7 MB/sUSB 1.1 Sector Size:..............512 bytes Latency:................4.17 ms Seek time (average):.............8.5ms Internal Drive Interface:.............ATA 100 Cable Transfer Rate..50MB/s (usb 2.0), 7MB/s (USB1.0, 1.1) Dimensions............8.875”x7”x2.25” Weight..................4.5lbs Please note that USB 2.0 requires the use of a USB 2.0 Adapter card.
- Page 7 Dusty environment Excessive vibration/sudden shock DO NOT! Try and service unit yourself! (Doing this will void COBRA warranty.) Do not open or remove covers! MISC: If you have a blue and white G3 make sure you update your firmware and have...
- Page 8 1 Insert the Hard Disk Speedtools software CD 2 Open the installer 3 Make sure the USB drivers are selected and click install 4 Restart your computer. To install the usb drivers, place the EZ-startup Kit CD in your computer’s CD-ROM drive and restart your computer. When Windows asks for a driver, direct it to your EZ-startup Kit CD.
- Page 9 1 Plug the power cable into the drive 2 Connect the other end to an outlet 3 Connect the USB cable in to the USB port behind the drive 4 Connect the other cable end to the computer’s USB port or a USB port on your USB 2.0 Card 5 Turn the drive on and start the computer 1 Plug the power cable into the drive...
- Page 10 Hard Drive icon in the trash before removing the hard drive. My data is being corrupted when I transfer it to my Cobra USB hard Drive. Your drive may need to be reformatted. Try to do a low level form at on your drive. PC users, run scandisk to check for errors.
- Page 11 If you are having trouble with drive integrity, you may need to do a low level format on your drive. PC users may need to run scandisk. Go to the EZQuest website (www.ezq.com) and download the latest drivers. Contact tech@ezq.com if you still have problems.
- Page 12 Move your Cobra from computer to computer without having to restart your computer. Turn your Cobra on and off at any time without having to r e s t a r t your computer. Transfer files from Macintosh computers to PC computers (must format drive on PC) : USB 2.0 is the new standard in USB technology.
- Page 13 MACINTOSH INSTALLED EXTENSIONS: Make sure you have installed HDST U S B Support Shim, and HDST U S B Support Driver. These drivers will allow your drive to be seen in hard disk s p e e d t o o l s .
- Page 14 SPECIFICATION OF SWITCHING POWER SUPPLY 50W UL,CSA,TUV,FCC AC INPUT VOLTAGE..................: 90-264VAC AC INPUT FREQUENCY.................: 47-63Hz AC INPUT CURRENT......: 1.2A MAX. AT 115VAC INPUT, FULL LOAD 0.6A MAX.
- Page 15 RISE TIME....................: 50mS MAX. TURN-ON DELAY TIME...............: 2000 mS MAX. HOLD-UP TIME..................: 16 mS MIN. SWITCHING FREQUENCY................: 100 KHz OVER POWER PROTECTION: WHEN OUTPUT POWER IS OVER TO 70W , THE OUTPUT VOLTAGE WILL DECREASE. OVER VOLTAGE PROTECTION : WHEN +5V OUTPUT IS OVER TO 5.6V-6.5V POWER SUPPLY WILL SHUTDOWN. SHORT CIRCUIT PROTECTION: FOR +5V AND +12V OUTPUTS.
