Summary of Contents for Street Machine 100Xi
- Page 1 2Channel High Performance Mobile Amplifier Model : 100Xi Owner’s Manual...
- Page 2 Dear customer, Selecting fine audio equipment, such as the unit you have just purchased, is only the beginning of your musical enjoyment. Now is the time to consider how to maximize the fun and excitement your equipment has to offer. AUTOTEK and the Electronic Industry Associations Consumer Electronic Group want you to get the most out of your equipment by playing it at a safe level, a level that lets the sound come through loud and clear without annoying blaring distortion;...
-
Page 3: Installation
Introduction Your Autotek STREET MACHINE amplifier has been designed to give you very high performance, and valuable features, at a reasonable price. Take the time to read over this brief set of instructions, and you will get full enjoyment from your system. -
Page 4: Power Supply Connections
Fig. 1 Installation of Ampifier Power Supply Connections The +12VDC and ground wires should be heavy gauge standard copper wires with heavy insulation. The wire gauge should be 4AWG for the AMX50.2 and AMX100.2 or larger. In addition, it has a 12V remote control wire and it should be 14AWG-18AWG. - Page 5 Caution First make +12V wire connection then the ground connection and finally the remote connection. Furthermore the +12V wire must always be fused at the battery for protection against possible damage. If you need to replace the power fuse, replace it with a fuse of the same value. Using a fuse of a different type or rating may result in a serious hazard.
-
Page 6: Input Connections
Input Connections Note: RCA Cable not supplied with unit: Caution: Do not use both low and high level inputs simultaneously... - Page 7 • The amplifier can be used in the STEREO and MONO mode as shown in Fig. 4, Fig 5. • The speaker wires should be connected to the speaker terminal on amplifier. • Notice that most speakers have a polarity marking such as "=" or a dot on speaker terminals and these markings denote the positive terminals of the speaker and are used as a guide to phase the speakers.
- Page 9 It indicates amplifier has turn on signal. Fuse It protects both the amplifier and the automobile electrical system from fault conditions. Use a standard automotive fuse, 100Xi: 15A Power connection Connects +12VDC power wire from the battery and also connects ground wire from a suitable ground point on the chassis.
-
Page 10: Specifications
SPECIFICATIONS STREET MACHINE 100Xi *Audio Power output per Channel, *both channels driven at 14.4VDC. - 4 Ohms 1kHz, THD 0.05% 35W x 2 - 4 Ohms Bridged, THD 0.2% 80Watts * Signal to Noise Ratio >90dB * Frequency Response, 10Hz-40kHz... - Page 11 We Want You Listening for a Lifetime Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment. Since hearing damage from loud noise is often undetectable until it is too late, this manufacturer and the Electronic Industries Association's Consumer Electronics Group recommend you avoid prolonged exposure to excessive noise.
