Page 2: Table Of Contents
Step 3 – Video Connector…………………………………………………………………………………….……..14 Step 3.1 - Connecting to HDMI input…………………….………………………………………….…..14 Step 3.4 - Connecting to Composite (also known as RCA) input………..…………..………16 Step 3.5 - Connecting Audio Inputs to the 550HD+WiFi ………………..…………….……..16 Step 4 - Display Mode…….……………………………………………………………………………….………….16 Step 5 - Scan Mode………………………………………………………………………………………..…………..17 Step 6 - Aspect Ratio………………………………………………………………………………………………..…17... -
Page 3: Important Safeguards
General Guidelines & Precautions This symbol is intended to alert the user to the presence of un- insulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute risk of fire or electrical shock This symbol is also intended to alert the user to the presence of important operating and maintenance instructions in the literature accompanying this product. -
Page 4: General Guidelines & Precautions
eneral Guidelines & Precautions WARNING To reduce the risk of fire or shock hazard, do not expose the product to rain or moisture. To guard against injury, the following basic safety precautions should be observed in the installation, use, and servicing of the product. Power Sources This product should be operated only from the type of power source indicated on the marking label. - Page 5 Power-Cord Protection Do not allow anything to rest on or roll over the power cord, and do not place the product where the power cord is subject to wear or abuse. Servicing Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other hazards.
-
Page 6: Outlook
1. 550HD+WiFi Outlook Peer TV‘s 550HD+WiFi is an advanced Internet TV STB supporting a range of streaming protocols and codec formats , allowing close replication of the broadcast experience over the Internet at the highest quality possible. The 550HD+WiFi STB is designed to run a wide range of Internet TV applications, developed either through use of its optional SDK, or provided by Peer TV (the MX Internet TV Client-Server software solution). - Page 7 Page...
-
Page 8: The Remote Control
4. The Remote Control (Note that some keys usage is application dependent. Please refer to the application user manual for further instructions) 01 Power On / Off 02 STB set-up 03 Subtitles (currently not in use) 04 Zoom 05 Display (Aspect Ratio) 06 Play Mode 07 Visualization 08 Channel Up / Dow... -
Page 9: The Set Top Box
5. The Set Top Box The following images illustrate the main parts of the 550HD+WiFi STB (front view and back panel view). Front Panel back-panel connectors Rear panel 6. Initial Connections Initial Connection of the STB to the TV - Initially you should use the yellow (Composite) connector of the bundled A/V cable to connect the STB to the TV, Please follow the following image to identify the proper connector. -
Page 10: Connecting To Power
7. Connecting to Power Please turn on the TV, before powering up the 550HD+WiFi, and switch to the Composite video channel. Plug one end of the power adapter into the +12v socket at the rear of the device and the other end into the electrical socket. -
Page 11: Step 1 - Setup Language
Step – setup language Please select the preferred setup language. To navigate through options, use the right/left arrows on the remote control and click OK to select. Step – Quick Start Guide Manual Step – Video Standard Most current TVs can play both types NTSC (US) or PAL (Europe), Please check your TV vendor‘s specifications to find out the video standard it supports. -
Page 12: Step 3 - Video Connector
Step – Video Connector Please check your TV vendor‘s specifications to find out the available video inputs. The preferred choice should be HDMI (best quality), then (next preference) Component, S-Video and then Composite. To navigate through options use the right/left arrows on the remote control and click OK to select. Page... -
Page 13: Step 3.1 - Connecting To Hdmi Input
Step 4.1 - Connecting to HDMI input Connect the HDMI cable to the HDMI connector at the rear of the device. HDMI Connector Connect the other side of the cable to the matching HDMI input on your TV set. Step 4.2 - Connecting to Composite (also known as RCA) input ... -
Page 14: Step 3.5 - Connecting Audio Inputs To The 550Hd+Wifi
HDMI: includes audio connection, so no need to connect additional cables (unless your intend to use audio system not part of your TV, for which you should use the following options) RCA Stereo: White and Red cables connecting stereo out of the 550HD+WiFi to the Stereo in of your audio system ... -
Page 15: Step 7/8 - Video Settings Test
Step – Video Settings Test In this step the selected video settings will be tested. Click OK when ready for the test. Use your TV remote control to select the chosen input to your TV set. If you see the wizard‘s countdown after switching to the chosen input click OK to finish the test, if nothing displays on screen switch back to the previous TV input and wait till the countdown is finished then click Back ,check the settings and connections and run the test again. -
Page 16: Step 9 - Network Connection
Step – Video Settings Test Press OK to continue. Step – Network Connection To navigate through options use the right/left arrows on the remote control and click OK to select. Step 10.1 - LAN - Wired Home Network Connect the local network cable (supplied in the package) to the Data socket at the rear of the device, and plug the other end to a free network LAN port. -
Page 17: Step 9.2 - Wi-Fi - Wireless Home Network
Step 10.3 - PPPoE - Point-to-Point Protocol over Ethernet In case of direct connection of 550HD+WiFi to the ADSL router, PPPoE mode is needed. Connect the local network cable (supplied in the package) to the Data socket at the rear of the device, and plug the other end to a free network PPPoE port. -
Page 18: Step 12 - Network Security (Wi-Fi Network)
Next: Step – Select Your Network (Wi-Fi Network) To navigate through available networks use the right/left arrows on the remote control and click OK when you find your network (check your router‘s network settings to find out the name). If not found (can happen when network is in hidden mode) use the right arrow till ―manual‖ appears and click OK. 12/13 Step - Network Security (Wi-Fi Network) -
Page 19: Step 13 - Network Security Key (Wi-Fi Network)
Step - Network Security Key (Wi-Fi Network) Use the remote control‘s keypad to insert your Network Security Name (check your router‘s network settings to find out the key).click OK when finished. →You will now be transferred to step 15 (network test) Step - PPPoE User name &... -
Page 20: Step 15 - Network Test
Use the remote control‘s keypad to insert your Password (check your router‘s network settings to find out the password).click OK when finished. Step - Network Test In this step the selected network settings will be tested. Click OK when ready for the test, the test will provide you with Pass or fail result. Step - Network Test fail If one of the tests fails please click NO, check the settings and connections and run the test again. -
Page 21: Step 17 - Setup Completed
- Setup Completed The setup up is completed, when choosing YES the settings will be saved. If NO is chosen the settings will not be saved and in the next reboot the 550HD+WiFi will be running with the previous settings. Page...
