Summary of Contents for Spy Camera CCTV 1DVRDIG502
- Page 1 Digital Wireless Security System Models: 1DVRDIG502 / 1DVRDIG1502 EU Environmental Protection Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your local authority or retailer for recycling advice. Version 1.8...
-
Page 2: Table Of Contents
Welcome Contents This product is a home/small office monitoring and recording device. It consists of Welcome Features four cameras and one DVR (Digital Video Recorder) built in to a 7 inch LCD Packing List monitor, which allows for split-screen view of all 4 cameras simultaneously. Structure Installation Operations... -
Page 3: Structure
Structure Installation Install the camera at the desired location. The camera can be installed in one of 2 ways: Connect the receiver at a central location if using multiple cameras, or in the case of a single camera setup connect it as close to the camera as possible. -
Page 4: Operations
After successful pairing, the monitor should display an image similar to Operations the below: Basic Operation Connect the camera to a power supply. The power indicator should light up: Press the button to select between one of three display modes: Connect the receiver to a power supply: Press the power button on the receiver (or remote if you purchased one) for 2 seconds. -
Page 5: Video Recording
Video Recording After setting the record times the device will automatically record accordingly. You can press the record button to stop the scheduled recording if you choose. Manual Recording: From the default monitoring screen (where you see the image coming PIR Recording: in from the cameras), press the left and right buttons to select the camera you wish to record. -
Page 6: Playback
Playback Video Output From the main viewing screen, press the Playback button on the The monitor can be connected to a larger TV/Monitor using the supplied AV cable: monitor to access the playback interface. Press up or down to select the folder (footage is stored by date, with a separate folder for each day). -
Page 7: Language
System Language Press OK to enter. Date/Time Sets the system date and time. Press the Up or Down buttons to select language, then OK to confirm. Language Sets the system language. Record Mode Sets whether recording continues to record over old footage when storage device is full, or stops. -
Page 8: System Information
Storage for Recording Scan Mode Period Press OK to enter. Press OK to enter. Press the Up or Down buttons to select “SD Card” or “USB Device”. Press Left or Right to change the setting. Press the OK button to confirm and exit. Press OK to confirm and exit. -
Page 9: Alarm Volume
Alarm Volume Motion Detection Press OK to enter. Enable this mode to trigger recording based on movement. Please note that this Press Left or Right to decrease or increase the alarm output volume. mode should not be used at the same time as PIR or Timer based recordings. For Press OK to confirm and exit. -
Page 10: Pairing
Pairing Activation Press the Up or Down buttons to select “Pairing” and press the OK Press the OK button to enter: button to enter: Press the Up or Down buttons to select a camera. Press Up or Down to select a camera, and press OK to begin pairing. Press the Left or Right button to select On or Off (Off will disable the Within 60 seconds, push the pairing button on the camera in for 2 camera view/recording/alarms on the system for that camera) -
Page 11: Specifications
Specifications Frequently Asked Questions 1DVRDIG502 1DVRDIG1502 “Why doesn’t the screen display an image from my camera after it is paired?” Imaging Sensor 1/5 inch colour CMOS Please ensure the camera channel is set to “Active”, see page 18. Video Resolution 656 x 488 ...
