6. Lay the cabinet on its side down on the floor.
Remove the three screws that hold the bottom
hinge to the cabinet using a 7/16" socket. Keep
these screws and washer for later use.
7. Insert the bottom hinge at the left side using the
two screws previously removed in step 6.
NOTE: Do not tighten screws.
8. Stand the cabinet.
9. Replace the door making sure the bottom
socket enters the bottom hinge pin. Be sure
washer is in place.
10. While holding the door in the closed position,
secure the top hinge at the left side using the
two screws previously
beginning in step 2. Do not tighten the screws
until the top of the door is leveled with the top
cabinet.
11. Replace the hinge cover.
12. Replace plugs.
13. Tools Required:
- 7/16" socket-ratchet.
- Putty knife or thin-blade screwdriver.
removed at the
