- Page 1 7npJ TP UP-PN Portable Dot Matrix Printer Operation Guide...
- Page 2 The contents of this guide are subject to change without notice!
- Page 3 Before use Please be sure to read the operation guide carefully before using your printer. Store this guide in an accessible location for read it conveniently and troubleshooting. @> Safety Precautions Please take precautions to the followings. Otherwise, damage to the product may occur.
- Page 4 Figure 1-4 adaptor Figure 1-2 charger Figure 1-3 cable Figure 1-5 paper scroll 2. Appearance and explanation UP-PN is a portable 8 dot matrix miniature printer. Paper out slot Button ON Charge indicator Power indicator IrDA window Button LF Status indicator...
- Page 5 Electrical outlet of charge Scutcheon Communication port Cell case Electrode Figure 2-2 Printer back elevation 3. Load and unload the batteries The battery set into the bottom of the printer. See the below figure. Loading: Insert the batteries to the battery case (make the battery electrodes aim at the case electrodes) then press the batteries towards the bottom to make it insert tightly in the case.
- Page 6 Figure 3-2 Unload the batteries 4. Loading paper UP-PN has the easy paper loading mechanism; the step of loading paper is as follows: Press the central section of the upper cover with the thumbs, turn the outshoot then open the cover. see figure 4-1.
- Page 7 Figure 4-3 5. Replace the ribbon cassette UP-PN printers have a ribbon cassette loaded at ex-factory but cassette needs to replace since it has been used for a period of time. The replacing steps is described as follow: Open the upper cover of the printer Take out the old cassette Push the button mark with "push"...
- Page 8 d. Turn the knob again when find the ribbon on the outside of tl cassette. Close the upper cover Figure 5-1 ribbon cassette 6. Connecting: Interface connecting Figure 6-1 IrDA infrared interface IrDA infrared interface see the figure Figure 6-2...
-
Page 9: Power Supply Connecting
Power supply connecting It can realize battery slowly charging on printer with external adaptor. See the figure below Figure 6-3 7. Self-test We recommend you use the self-test to confirm the printer is installed properly. 0 First, push the button LF then push the button ON. The printer will be turn on. -
Page 10: Troubleshooting
When printer in this states, the red indicator light: (I) The printer comes into discharge state (in power off state, press button ON more than 10 seconds the printer come into discharge state ). (2) Power off (when printer in working or discharge state, press button ON for more than 5 seconds then release, the printer power off).
