- Page 1 2.0.1 Minisensor User guide...
-
Page 2: Table Of Contents
Presence detector (PIR)......9 PIR delay time setting / last level function. 11 Recommendations ......12 Fault finding ........12 Technical spesifications ....13 Appendixes Recommended programming sequence...A Programming examples....B Data subject to change without notice. For more information visit our website: www.helvar.com... -
Page 3: Introduction
A, where-as presence detection & infrared control affect both channels. The Minisensor is only compatible with the Helvar EL-si electronic DALI ballast range. Sensor set-up & programming is achieved using the Helvar Digidim infrared remote control. -
Page 4: Connection
Connection • Maximum connection: Up to 4 ballasts per Minisensor. Combinations are found from the following table. Example connection Ch A: 2pcs, Ch B: 1pcs Channel Lead color Bl Gr Rd Polarity No. of ballasts Reception areas Presence detector (PIR) Orientation (PIR) 3.0m... -
Page 5: Quick Functionality Guide
Quick functionality guide * Practical configuration example enclosed in appendix B (example 2) Data subject to change without notice. For more information visit our website: www.helvar.com... -
Page 6: "Out-Of-Box" Operation
“Out-of-box” operation Upon first application of power the Minisensor operates according to the programmed memory of the EL-si ballast. If the ballast has no program then the IR buttons “ ” , “ ” and “0/1”(On/Off) will be active. Channel control is also active. This allows the control of channels A&B (please see section “IR- control”... -
Page 7: Infrared (Ir) Control
• Dims down channel A & B from last level (if lights were on). *) If Constant light has been enabled and programmed the Minisensor will set the lights to the Constant light level after a short period of time. -
Page 8: Constant Light (Channel A)
Constant light (channel A) Enable constant light function (only possible through initial configuration / minisensor reset). • Simultaneously press & hold "3" & "4" for 10 seconds. • The operation is confirmed by flashing the lamps. Note: 10 seconds This also resets all scenes. -
Page 9: Presence Detector (Pir)
10 seconds 10 seconds Disable “Manual ON, Automatic OFF” feature(only possible through initial configuration / minisensor reset) • Simultaneously press & hold “3” & “4” for 10 seconds. • The operation is confirmed by flashing the lamps. Note: This also resets all scenes. - Page 10 PIR will switch the lights to the PIR OFF scene if no movement is detected within its programmed delay time. • PIR scenes can be any combination of light levels of channels A & B. Data subject to change without notice. For more information visit our website: www.helvar.com...
-
Page 11: Pir Delay Time Setting / Last Level Function
If the lights were already OFF when the mains was switched off they will remain off after the mains is switched on. Last level function can be turned off by carrying out Initial configuration / Minisensor reset. •... -
Page 12: Recommendations
Recommendations Plan programming carefully to avoid having to unnecessarily reset the Minisensor. (See appendix A) • Ensure that the Minisensor is located out of view of direct light to ensure correct operation of the • constant light sensor and IR. -
Page 13: Technical Specifications
Finish: White thermoplastic Protection: Single insulation Wire length: Max. from Minisensor to furthest ballast Note: The Minisensor is not designed for installation outside of a luminaire. • Data subject to change without notice. For more information visit our website: www.helvar.com... -
Page 14: Recommended Programming Sequence
Appendix A Recommended programming sequence Always start the programming by carrying out the Minisensor Initial configuration. Then select “Yes” or “No” for each step and follow the instructions on referred pages. Step 0/ start Initial configuration Finished Page 6 Step 1... -
Page 15: Programming Examples
Simultaneously press & hold “0/1” & “3” for 10 seconds. ii) Simultaneously press & hold “0/1” & “4” for 10 seconds. iii) Simultaneously press & hold “0/1” & “4” for 10 seconds. Data subject to change without notice. For more information visit our website: www.helvar.com... -
Page 16: Contact Information
F13 102 1D 13.01.05 HELVAR Oy Ab Yrittäjäntie 23 FIN-03600 Helsinki Tel: +358 9 56541 Fax: + 358 9 5654 9600 www.helvar.com Germany Italy Helvar Merca GmbH Helvar Merca S.r.l Carl-Zeiss-Strasse 12 Via W-Tobagi 26/1 D-63322 Rödermark I-20068 Peschiera Borromeo...
